XDS560R USB JTAG Emulator for CCS 3.x
XDS560R
System Requirements
•
500MB of free hard disk space
•
Microsoft Windows™ 2000/XP
•
128MB of RAM
•
16-bit color display
•
CD-ROM Drive
Service and Support
Web
http://support.spectrumdigital.com
E-Mail
support@spectrumdigital.com
12502 Exchange Dr., Ste 440, Stafford, TX. 77477
Quick Start Installation Guide
Kit Contents
+5V Universal
Power Supply
Driver CD ROM
507356-4001A
T:281.494.4505, F:281.494.5310
USB Cable
The driver install supports the Spectrum Digital XDS560R
emulator in a CCS 3.x environment. Emulation drivers are
updated on a regular basis so check the Spectrum Digital web
site at support.spectrumdigital.com.
Installing Emulation Drivers
1.
Insert the installation CD into the CD-ROM Drive. An
install screen should appear; if not, go to Windows
Explorer and run launch.exe from the CD-ROM.
2.
Select the "Install Product" menu item and then select
the Code Composer Studio version you wish to install.
Follow the on-screen installation instructions. When
the driver install is complete do not remove the CD-
ROM.
AC Power
Cord
