2.2 Installing the XDS560R JTAG Emulator
This section contains the steps for installing the XDS560R JTAG Emulator.
Target Cable Connectors:
Be very careful with the target cable connectors. connect them gently; don't force
them into position, or you may damage the connectors.
Do not connect or disconnect the emulator tail while the target system is powered up.
2.2.1 XDS560R USB Installation Checklist
The following section provides instructions to install XDS560R using the USB interface.
To install the XDS560R JTAG emulator using the USB interface execute the following
checklist:
❏
Turn off the power to your target board.
❏
Connect the supplied USB cable to your PC or laptop. If you connect the USB cable
to a USB hub be sure the hub is connected to the PC or laptop and power is applied
to the hub.
❏
Connect the included +5V power adapter brick to your wall AC power source using
the AC power cord.
❏
Apply power to the XDS560R by connecting the power brick to the +5V input on the
XDS560R located at the rear of the emulator. when power is connected the "PWR"
led on the XDS560R should iulluminate. After about 3 seconds LED 0 should begin
blinking slowly and LED 1-3 should begin sequencing. At this point the XDS560R has
gone through it's power on self-test, entered boot mode and is ready for USB
enumeration.
❏
Make sure your driver CD-ROM is installed in your CD-ROM drive. Your system
configuration should now look like that in Figure 2-1or Figure 2-2. Now connect the
XDS560R to your PC using the supplied USB cable. At this point led 0 should begin
blinking at a faster rate and windows will launch its "Add New Hardware Wizard" and
prompt for the location of the XDS560R drivers. Follow the instructions in the Quick
Start Guide for the software tools you are using.
❏
Now connect the tail of the emulator to the header on your target board. Apply power
to the target board
WARNING !
Spectrum Digital, Inc
2-3
