Spectrum Digital, Inc
2.3 Connecting the XDS560R to the Target Board
The female JTAG connector attached to the end of the emulator tail plugs onto the
target's male pin header. The figure below shows how the XDS560R emulator
header plugs onto the target's JTAG header
2-6
Emulator Tail
DSP
Figure 2-3, Connecting the XDS560R
to the DSP Target Board
Female JTAG
Connector
Male Pin
Header
Target Board
XDS560R JTAG Emulator Installation Guide
