Spectrum Digital, Inc
3.8 Target Cables
The XDS560R uses modular target cables that can interchanged for use with specific
target JTAG headers. The pin spacing in the cable header may vary from target cable to
target cable based on the mating connector on the target board. Refer to the
specification of the mating connector part numbers identified in Section 3.1 for the
exact spacing of the pins on the board header used in your system. The mechanical
information for two of these target cables is shown below.
3-18
Figure 3-11, 20 Pin CTI Target JTAG Cable
XDS560R JTAG Emulator Installation Guide
