Mechanical dimensions
4 x PG9
Figure 5.1: Mechanical dimensions of valve coupler FD0-VC-Ex4.FF
Subject to reasonable modifications due to technical advances.
18
Pepperl+Fuchs Group • Tel.: Germany +49 621 776-0 • USA +1 330 4253555 • Singapore +65 67799091 • Internet http://www.pepperl-fuchs.com
187
173
7.4
Fieldbus Valve Coupler FD0-VC-Ex4.FF
1 x PG11
Copyright Pepperl+Fuchs, Printed in Germany
Installation
46
11.5
