Technical specification

The following information represents the dimensions and indications of weight and the
manufacturer's approved machine data.
2.1

Electrical connection

2.2

Drive motor power

2.3

Work areas

Center height [ mm ]
Distance between centres [ mm ]
Swing diameter over machine bed [ mm ]
Swing diameter over cross slide [ mm ]
Main spindle bore [ mm ]
Lathe chuck K11-160/D4 bore [ mm]
2.4

Headstock

Main spindle nose
Main spindle morse taper
Spindle speeds ± 5% [ rpm ]
when connecting to ~50Hz
Spindle speeds ± 5% [ rpm ]
when connecting to ~60Hz
Speed levels
2.5

Feeds and pitches

Longitudinal feed [mm/rev]
Cross feed [mm/rev]
Metric thread [mm/rev]
Inch threads [threads/inch]
GB TU3008G
16 Translation of original instruction
3x400V ~ 50Hz ( ~ 60 Hz )
1.1 KW
158
720
310
190
38
40
Camlock DIN ISO 702-2 no. 4
MT5
165 │300│530│750│1400│2400
200 │360│640│900│1700│2900
6 gear stages
Version 1.1.6 - 2021-9-17
