3.1.34 Moving an individual curve

Click on the waveform's handle to drag the curve up and down.

3.1.35 Display differential curves

Right click on the selected waveform handle to display the A minus B (A-B) or Ipsi minus Contra (Ipsi-Contra)
differential waveforms.

3.1.36 Adding a note to the waveform

Right click on the curve handle and click on the option "Note"
Type here the waveform note/comment.
The note has a maximum of 20 characters, to keep space for the left intensity
handles in split screen.
E.g. in relation to eABR, e.g. CI electrode number 10 is stimulated with a current
level of 80.
This appears next to the waveform and is included in the print.
The notes can be changed later in the historic session if needed.
Other good notes can also be "Clamped" in e.g. Cochlear microphonic testing.
