3
CEILING
4
Mount the marked ceiling adapter kit on the ceiling by tightening the screws in the marked points (4).
Fit the M6 screw to fix the projector (placed upside down) in the holes provided in the back housing
(see detail). Fit the M4 screw to lock rotation.
20
PROLIGHTS - EclDisplay CC / EclDisplayCCFC
M4 screw
DETAIL
M6 screw
