8 - START UP

To apply and disconnect power to the product:

• Check that the product is installed and secured as indicated in the Safety Informations, and that

personal safety will not be put at risk when the fixture lights up.

• Connect the external led driver to the mains line.

• The product is then ready for its operations and can be controlled through the available input sig-

nals on led driver.

• To disconnect power from the product, disconnect the mains from the socket.

1. SAFETY EYE to attach safety cable;

2. KNOB for releasing and locking the optic;

3. KNOB for releasing and locking the optic and for zoom;

4. OPTIC (accessory not included, in the figure ECLDISPWASHL1530);

5. RUBBER RING (accessory included in the box optic);

6. PLASTIC ARM COVER;

7. LOCK TILT.

PROLIGHTS - EclDisplay CC / EclDisplayCCFC

Fig. 07
