Loosen the two marked knobs on the top and lower of the ECLDISPLAY to rotate the optics.
5
The marked lever in position A allows the locking of the blades.
Rotating the lever to position B or C allows the release of the blades.
This operation must be repeated for both levers on the frame system.
14
C
B
PROLIGHTS - EclDisplay CC / EclDisplayCCFC
A
Fig. 08
