CEILING ADAPTER KIT (CODES ECLDISPCEILKIT, ECLDISPCEILFLG - OPTIONAL)

1
152 mm
[6.0 in]
35 mm 100 mm
[1.4 in]
35 mm 100 mm
[1.4 in]
152 mm
[6.0 in]
35 mm 100 mm
[1.4 in]
2
Measurements for cuts on the panels (1) and of the ECLDISPCEILFLG (2).
PROLIGHTS - EclDisplay CC / EclDisplay CCFC
[3.9 in]
[3.9 in]
[3.9 in]
230 mm
[9.1 in]
30 mm
[1.2 in]
230 mm
[9.1 in]
30 mm
[1.2 in]
230 mm
[9.1 in]
110 mm
[4.3 in]
Ø200 mm
[7.9 in]
Ø180 mm
[Ø7.1 in]
100 mm 35 mm
[3.9 in] [1.4 in]
100 mm 35 mm
[3.9 in] [1.4 in]
Ø180 mm
[Ø7.1 in]
100 mm 35 mm
[3.9 in] [1.4 in]
125 mm
[4.9 in]
125 mm
[4.9 in]
