CMOS single-chip 8-bit MCU
with 12-bit A/D converter and
LCD driver
Main features
8-bit Microcontroller With High Speed 8051 CPU
Basic MCU Function
– 32 Kbytes Flash Code Memory
– 1024 bytes SRAM
Built-in Analog Function
– Power-On Reset and Low Voltage Detect Reset
– Internal 16MHz RC Oscillator (±1.5%, T
– Watchdog Timer RC Oscillator (5kHz)
Peripheral Features
– 12-bit Analog to Digital Converter (16 inputs)
– USI (USART + SPI + I2C) 2 sets
– LCD Driver (21 segments x 8 commons)
I/O and Packages
– Up to 42 programmable I/O lines with 48/44-pin package
– 48 QFN, 44 MQFP, 32 LQFP, 32/28 SOP
Operating Conditions
– 2.2V to 5.5V Wide Voltage Range
– -40°C to 85°C Temperature Range
Application
– Small Home Appliance
– BLDC Motor Controller
= 0 ~ +50°C)
A
MC96F6432A
MC96F6332A
User's manual
V 1.6
Revised 09 February, 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MC96F6432A and is the answer not in the manual?

Questions and answers

Summary of Contents for Abov MC96F6432A

  • Page 1 CMOS single-chip 8-bit MCU with 12-bit A/D converter and LCD driver MC96F6432A Main features MC96F6332A 8-bit Microcontroller With High Speed 8051 CPU  Basic MCU Function  User’s manual – 32 Kbytes Flash Code Memory – 1024 bytes SRAM V 1.6 Built-in Analog Function ...
  • Page 2: Revision History

    The information, diagrams and other data in this manual are correct and reliable; however, ABOV Semiconductor is in no way responsible for any violations of patents or other rights of the third party generated by the use of this manual.
  • Page 3: Overview

    Overview Description The MC96F6432A is an advanced CMOS 8-bit microcontroller with 32 Kbytes of FLASH. This is powerful microcontroller which provides a highly flexible and cost effective solution to many embedded control applications. This offers the following features: 32 Kbytes of FLASH, 256 bytes of IRAM, 768 bytes of XRAM, general purpose I/O, basic...
  • Page 4: Features

    ABOV Semiconductor Co., Ltd. MC96F6432A Features  – 8-bit CISC core (M8051, 2 clocks per cycle)  Low Voltage Reset – 12 levels detect  ROM (FLASH) Capacity (1.85/ 2.20/ 2.32/ 2.44/ 2.59/ 2.75/ 2.93/ 3.14/ 3.38/ – 32Kbytes Flash with self-read and write capability 3.67/ 4.00/ 4.40V)
  • Page 5: Development Tools

    ABOV Semiconductor does not provide compiler. It is recommended that you consult a compiler provider. The MC96F6432A core is Mentor 8051 and the ROM size is smaller than 64 Kbytes. Therefore, developer can use the standard 8051 compiler from other providers.
  • Page 6 VDD Voltage Rising Time VDD Voltage Rising Time Characteristics Min/Max : 0.05/30.0[V/ms] Min/Max : 0.05/30.0[V/ms] Min/Max : 0.05/5.0[V/ms] Full-flash erase Sector erase mode Sector erase mode Sector and byte erase mode mode method Difference among MC96F6432A, MC96F6432S and MC96F6432 Table 1.2...
  • Page 7: Programmer

    MC96F6432A ABOV Semiconductor Co., Ltd. 1.3.3 Programmer Single programmer: E-PGM+ : It programs MCU device directly. DSDA DSCL Figure 1.2 E-PGM+(Single writer)
  • Page 8 ABOV Semiconductor Co., Ltd. MC96F6432A Gang programmer: E-GANG4 and E-GANG6 It can run PC controlled mode. It can run standalone without PC control too. USB interface is supported. Easy to connect to the handler. Figure 1.3 E-GANG4 and E-GANG6 (for Mass Production)
  • Page 9: Mtp Programming

    ABOV Semiconductor Co., Ltd. MTP programming 1.4.1 Overview The program memory of MC96F6432A is MTP Type. This flash is accessed by serial data format. There are four pins(DSCL, DSDA, VDD and VSS) for programming/reading the flash. During programming Main chip...
  • Page 10 ABOV Semiconductor Co., Ltd. MC96F6432A E-PGM+, E-GANG4/E-GANG6 R1 (2kΩ ~ 5kΩ) DSCL(I) To application circuit R2 (2kΩ ~ 5kΩ) DSDA(I/O) To application circuit NOTE) In on-board programming mode, very high-speed signal will be provided to pin DSCL and DSDA. And it will cause some damages to the application circuits connected to DSCL or DSDA port if the application circuit is designed as high speed response such as relay control circuit.
  • Page 11: Block Diagram

    Timer / Counter 1 channel, 8-bit Buzzer 2 channels, 16-bit 1 channel, 8-bit 2 channels, 8-bit or 1 channel, 16-bit UART 2 channels, 8-bit 16 Input channels, 12-bit 3 channels, 8-bit 6 channels 2 channels, 8-bit Figure 2.1 Block diagram of MC96F6432A...
  • Page 12: Pin Assignment

    ABOV Semiconductor Co., Ltd. MC96F6432A Pin assignment P55/RESETB P40/VLC3/RXD0/SCL0/MISO0 P04/SEG25/AN2/EINT2/PWM4BA P41/VLC2/TXD0/SDA0/MOSI0 P05/SEG24/AN3/EINT3/PWM4BB P42/VLC1/SCK0 P06/SEG23/AN4/EINT4/PWM4CA P07/SEG22/AN5/EINT5/PWM4CB P43/VLC0/SS0 MC96F6432AU P17/SEG21/AN6/EINT6/SS2 P37/COM0 (48QFN) P16/SEG20/AN7/EINT7/SCK2 P36/COM1 P15/SEG19/AN8/MISO2 P35/COM2/SEG0 P14/SEG18/AN9/MOSI2 P34/COM3/SEG1 P13/SEG17/AN10/EC1/BUZO P33/COM4/SEG2 P12/SEG16/AN11/EINT11/T1O/PWM1O P32/COM5/SEG3 P11/SEG15/AN12/EINT12/T2O/PWM2O NOTE) The programmer (E-PGM+, E-Gang4/E-Gang6) uses P0[1:0] pin as DSCL, DSDA.
  • Page 13 MC96F6432A ABOV Semiconductor Co., Ltd. P55/RESETB P04/SEG25/AN2/EINT2/PWM4BA P40/VLC3/RXD0/SCL0/MISO0 P05/SEG24/AN3/EINT3/PWM4BB P41/VLC2/TXD0/SDA0/MOSI0 P06/SEG23/AN4/EINT4/PWM4CA P42/VLC1/SCK0 P07/SEG22/AN5/EINT5/PWM4CB P43/VLC0/SS0 MC96F6432AQ P17/SEG21/AN6/EINT6/SS2 P37/COM0 P16/SEG20/AN7/EINT7/SCK2 (44MQFP-1010) P36/COM1 P15/SEG19/AN8/MISO2 P35/COM2/SEG0 P14/SEG18/AN9/MOSI2 P34/COM3/SEG1 P13/SEG17/AN10/EC1/BUZO P33/COM4/SEG2 P12/SEG16/AN11/EINT11/T1O/PWM1O P32/COM5/SEG3 P11/SEG15/AN12/EINT12/T2O/PWM2O NOTE) The programmer (E-PGM+, E-Gang4/E-Gang6) uses P0[1:0] pin as DSCL, DSDA.
  • Page 14 ABOV Semiconductor Co., Ltd. MC96F6432A P53/SXIN/T0O/PWM0O P03/SEG26/AN1/EINT1/PWM4AB P54/SXOUT/EINT10 P04/SEG25/AN2/EINT2/PWM4BA P55/RESETB P05/SEG24/AN3/EINT3/PWM4BB P40/VLC3/RXD0/SCL0/MISO0 P06/SEG23/AN4/EINT4/PWM4CA MC96F6332AL P41/VLC2/TXD0/SDA0/MOSI0 P07/SEG22/AN5/EINT5/PWM4CB (32-LQFP) P42/VLC1/SCK0 P13/SEG17/AN10/EC1/BUZO P33/COM4/SEG2 P12/SEG16/AN11/EINT11/T1O/PWM1O P32/COM5/SEG3 P11/SEG15/AN12/EINT12/T2O/PWM2O NOTE) The programmer (E-PGM+, E-Gang4/E-Gang6) uses P0[1:0] pin as DSCL, DSDA. The P14-P17, P23-P25, P34-P37 and P43 pins should be selected as a push-pull output or an input with pull-up resistor by software control when the 32-pin package is used.
  • Page 15 MC96F6432A ABOV Semiconductor Co., Ltd. P50/XOUT P00/EC3/DSDA P51/XIN P01/T3O/DSCL P52/EINT8/EC0/BLNK P02/AN0/AVREF/EINT0/T4O/PWM4AA P53/SXIN/T0O/PWM0O P03/SEG26/AN1/EINT1/PWM4AB P54/SXOUT/EINT10 P04/SEG25/AN2/EINT2/PWM4BA P55/RESETB P05/SEG24/AN3/EINT3/PWM4BB MC96F6332AD P40/VLC3/RXD0/SCL0/MISO0 P06/SEG23/AN4/EINT4/PWM4CA (32-SOP) P41/VLC2/TXD0/SDA0/MOSI0 P07/SEG22/AN5/EINT5/PWM4CB P42/VLC1/SCK0 P13/SEG17/AN10/EC1/BUZO P33/COM4/SEG2 P12/SEG16/AN11/EINT11/T1O/PWM1O P32/COM5/SEG3 P11/SEG15/AN12/EINT12/T2O/PWM2O P31/COM6/SEG4 P10/SEG14/AN13/RXD1/SCL1/MISO1 P30/COM7/SEG5 P20/SEG13/AN14/TXD1/SDA1/MOSI1 P27/SEG6 P21/SEG12/AN15/SCK1 P26/SEG7 P22/SEG11/SS1 NOTE) The programmer (E-PGM+, E-Gang4/E-Gang6) uses P0[1:0] pin as DSCL, DSDA.
  • Page 16: Package Diagram

    ABOV Semiconductor Co., Ltd. MC96F6432A Package Diagram Figure 4.1 48-Pin QFN Package...
  • Page 17 MC96F6432A ABOV Semiconductor Co., Ltd. Figure 4.2 44-Pin MQFP Package...
  • Page 18 ABOV Semiconductor Co., Ltd. MC96F6432A Figure 4.3 32-Pin LQFP Package...
  • Page 19 MC96F6432A ABOV Semiconductor Co., Ltd. Figure 4.4 32-Pin SOP Package...
  • Page 20 ABOV Semiconductor Co., Ltd. MC96F6432A Figure 4.5 28-Pin SOP Package...
  • Page 21: Pin Description

    MC96F6432A ABOV Semiconductor Co., Ltd. Pin Description Function @RESET Shared with Name Port 0 is a bit-programmable I/O port which can be EC3/DSDA configured as a Schmitt-trigger input, a push-pull T3O/DSCL output or an open-drain output. A pull-up resistor can be specified in 1-bit unit.
  • Page 22 ABOV Semiconductor Co., Ltd. MC96F6432A Function @RESET Shared with Name Port 5 is a bit-programmable I/O port which can be XOUT configured as a Schmitt-trigger input or a push-pull output. A pull-up resistor can be specified in 1-bit unit. EINT8/EC0/BLNK...
  • Page 23 MC96F6432A ABOV Semiconductor Co., Ltd. Function @RESET Shared with Name BUZO Buzzer signal output Input P13/SEG17/AN10/EC1 SCK0 Serial 0 clock input/output Input P42/VLC1 SCK1 Serial 1 clock input/output Input P21/SEG12/AN15 SCK2 Serial 2 clock input/output Input P16/SEG20/AN7/EINT7 MOSI0 SPI 0 master output, slave input...
  • Page 24 ABOV Semiconductor Co., Ltd. MC96F6432A PIN Name Function @RESET Shared with VLC0 P43/SS0 VLC1 P42/SCK0 LCD bias voltage pins Input VLC2 P41/TXD0/SDA0/MOSI0 VLC3 P40/RXD0/SCL0/MISO0 COM0 P37–P36 COM1 COM2– LCD common signal outputs Input P35–P34/SEG0–SEG1 COM3 COM4– P33–P30/SEG2–SEG5 COM7 SEG0– P35–P34/COM2–COM3 SEG1 SEG2–...
  • Page 25 MC96F6432A ABOV Semiconductor Co., Ltd. Function @RESET Shared with Name System reset pin with a pull-up resistor when it is RESETB Input selected as the RESETB by CONFIGURE OPTION DSDA In-system programming data input/output Input P00/EC3 DSCL In-system programming clock input...
  • Page 26: Port Structures

    ABOV Semiconductor Co., Ltd. MC96F6432A Port Structures General Purpose I/O Port Level Shift (1.8V to ExtVDD) Level Shift (ExtVDD to 1.8V) PULL-UP REGISTER OPEN DRAIN REGISTER DATA REGISTER SUB-FUNC DATA OUTPUT SUB-FUNC ENABLE SUB-FUNC DIRECTION DIRECTION REGISTER CMOS or Schmitt Level...
  • Page 27: External Interrupt I/O Port

    MC96F6432A ABOV Semiconductor Co., Ltd. External Interrupt I/O Port Level Shift (1.8V to ExtVDD) Level Shift (ExtVDD to 1.8V) PULL-UP REGISTER OPEN DRAIN REGISTER DATA REGISTER SUB-FUNC DATA OUTPUT SUB-FUNC ENABLE SUB-FUNC DIRECTION DIRECTION REGISTER EXTERNAL INTERRUPT POLARITY REG. INTERRUPT...
  • Page 28: Electrical Characteristics

    ABOV Semiconductor Co., Ltd. MC96F6432A Electrical Characteristics Absolute Maximum Ratings Parameter Symbol Rating Unit Note – Supply Voltage -0.3~+6.5 -0.3~VDD+0.3 Voltage on any pin with respect to VSS -0.3~VDD+0.3 Maximum current output sourced by (I per I/O pin) Normal Voltage Pin ∑...
  • Page 29: A/D Converter Characteristics

    MC96F6432A ABOV Semiconductor Co., Ltd. A/D Converter Characteristics = -40°C ~ +85°C, VDD = 2.2V ~ 5.5V, VSS = 0V) Parameter Symbol Conditions Unit – – –- – Resolution – – Integral Non-Linear ±6 – – Differential Non-Linearity ±1 AVREF= 2.7V – 5.5V fx= 8MHz –...
  • Page 30: Low Voltage Reset And Low Voltage Indicator Characteristics

    ABOV Semiconductor Co., Ltd. MC96F6432A Low Voltage Reset and Low Voltage Indicator Characteristics = -40°C ~ +85°C, VDD = 2.2V ~ 5.5V, VSS = 0V) Parameter Symbol Conditions Unit – 1.85 2.15 2.05 2.20 2.35 2.17 2.32 2.47 2.29 2.44 2.59...
  • Page 31: Internal Watch-Dog Timer Rc Oscillator Characteristics

    MC96F6432A ABOV Semiconductor Co., Ltd. Internal Watch-Dog Timer RC Oscillator Characteristics = -40°C ~ +85°C, VDD = 2.2V ~ 5.5V, VSS = 0V) Parameter Symbol Conditions Unit – Frequency WDTRC – – – Stabilization Time WDTS – – Enable WDTRC Current WDTRC –...
  • Page 32: Dc Characteristics

    ABOV Semiconductor Co., Ltd. MC96F6432A DC Characteristics = -40°C ~ +85°C, VDD = 2.2V ~ 5.5V, VSS = 0V, f = 8.0MHz) Parameter Symbol Conditions Unit – P0, P1,P5, RESETB 0.8VDD Input High Voltage – All input pins except V 0.7VDD...
  • Page 33: Ac Characteristics

    MC96F6432A ABOV Semiconductor Co., Ltd. 7.10 AC Characteristics = -40°C ~ +85°C, VDD = 2.2V ~ 5.5V) Parameter Symbol Conditions Unit – – RESETB Input Low Width Input, VDD= 5V – – Interrupt Input High, Low Width All interrupt, VDD= 5V...
  • Page 34: Spi0/1/2 Characteristics

    ABOV Semiconductor Co., Ltd. MC96F6432A 7.11 SPI0/1/2 Characteristics = -40°C ~ +85°C, VDD = 2.2V ~ 5.5V) Parameter Symbol Conditions Unit – – Output Clock Pulse Period Internal SCK source – – Input Clock Pulse Period External SCK source –...
  • Page 35: Uart0/1 Characteristics

    MC96F6432A ABOV Semiconductor Co., Ltd. 7.12 UART0/1 Characteristics = -40°C ~ +85°C, VDD = 2.2V ~ 5.5V, f = 8MHz) Parameter Symbol Unit  16 Serial port clock cycle time 1800 2200  13 – Output data setup to clock rising edge –...
  • Page 36: I2C0/1 Characteristics

    ABOV Semiconductor Co., Ltd. MC96F6432A 7.13 I2C0/1 Characteristics = -40°C ~ +85°C, VDD = 2.2V ~ 5.5V) Standard Mode High-Speed Mode Parameter Symbol Unit Clock frequency – – Clock High Pulse Width SCLH – – Clock Low Pulse Width SCLL –...
  • Page 37: Data Retention Voltage In Stop Mode

    MC96F6432A ABOV Semiconductor Co., Ltd. 7.14 Data Retention Voltage in Stop Mode = -40°C ~ +85°C, VDD = 2.2V ~ 5.5V) Parameter Symbol Conditions Unit – – Data retention supply voltage DDDR = 2.2V(T = 25°C), – – Data retention supply current...
  • Page 38: Internal Flash Rom Characteristics

    ABOV Semiconductor Co., Ltd. MC96F6432A 7.15 Internal Flash Rom Characteristics = -40°C ~ +85°C, VDD = 2.2V ~ 5.5V, VSS = 0V) Parameter Symbol Condition Unit – – Sector Write Time – – Sector Erase Time – – Code Write Protection Time –...
  • Page 39: Main Clock Oscillator Characteristics

    MC96F6432A ABOV Semiconductor Co., Ltd. 7.17 Main Clock Oscillator Characteristics = -40°C ~ +85°C, VDD = 2.2V ~ 5.5V) Oscillator Parameter Condition Unit 2.2V – 5.5V – Crystal Main oscillation frequency 2.7V – 5.5V – 2.2V – 5.5V – Ceramic Oscillator Main oscillation frequency 2.7V –...
  • Page 40: Sub Clock Oscillator Characteristics

    ABOV Semiconductor Co., Ltd. MC96F6432A 7.18 Sub Clock Oscillator Characteristics = -40°C ~ +85°C, VDD = 2.2V ~ 5.5V) Oscillator Parameter Condition Unit Crystal Sub oscillation frequency 32.768 2.2V – 5.5V – External Clock SXIN input frequency Sub Clock Oscillator Characteristics Table 7.18...
  • Page 41: Main Oscillation Stabilization Characteristics

    MC96F6432A ABOV Semiconductor Co., Ltd. 7.19 Main Oscillation Stabilization Characteristics = -40°C ~ +85°C, VDD = 2.2V ~ 5.5V) Oscillator Parameter Unit fx > 4MHz, VDD = 2.7V ~ 5.5V, – – Crystal fx > 1MHz, VDD = 2.2V, T =-40°C...
  • Page 42: Operating Voltage Range

    ABOV Semiconductor Co., Ltd. MC96F6432A 7.21 Operating Voltage Range =0.4 to 8.5MHz) =32 to 38kHz) 8.5MHz 32.768kHz 4.2MHz 0.4MHz Supply voltage (V) Supply voltage (V) Figure 7.14 Operating Voltage Range...
  • Page 43: Recommended Circuit And Layout

    MC96F6432A ABOV Semiconductor Co., Ltd. 7.22 Recommended Circuit and Layout This 0.1uF capacitor should be within 1cm from the VDD pin of MCU on the VDD VCC PCB layout. DC Power 0.1uF 0.1uF The MCU power line (VDD and VSS)
  • Page 44: Recommended Circuit And Layout With Smps Power

    ABOV Semiconductor Co., Ltd. MC96F6432A 7.23 Recommended Circuit and Layout with SMPS Power SMPS Side MCU Side SMPS MC96F6432A 1. The C1 capacitor is to flatten out the voltage of the SMPS power, VCC. √ Recommended C1: 470uF/25V more. 2. The R1 and C2 are the RC filter for VDD and suppress the ripple of VCC.
  • Page 45: Typical Characteristics

    MC96F6432A ABOV Semiconductor Co., Ltd. 7.24 Typical Characteristics These graphs and tables provided in this section are only for design guidance and are not tested or guaranteed. In graphs or tables some data are out of specified operating range (e.g. out of specified VDD range). This is only for information and devices are guaranteed to operate properly only within the specified range.
  • Page 46 ABOV Semiconductor Co., Ltd. MC96F6432A 120.0 100.0 80.0 +25°C 60.0 +85°C -40°C 40.0 20.0 Figure 7.19 SUB RUN (IDD3) Current 30.0 25.0 20.0 +25°C 15.0 +85°C -40°C 10.0 Figure 7.20 SUB IDLE (IDD4) Current...
  • Page 47 MC96F6432A ABOV Semiconductor Co., Ltd. +25°C +85°C -40°C Figure 7.21 STOP (IDD5) Current...
  • Page 48: Memory

    DPTR register. MC96F6432A provides on-chip 32 Kbytes of the ISP type flash program memory, which can be read and written to. Internal data memory (IRAM) is 256 bytes and it includes the stack area. External data memory (XRAM) is 768 bytes and it includes 27 bytes of LCD display RAM.
  • Page 49 MC96F6432A ABOV Semiconductor Co., Ltd. FFFFH 7FFFH 32Kbytes 0000H Figure 8.1 Program Memory NOTE) 32Kbytes Including Interrupt Vector address...
  • Page 50: Data Memory

    ABOV Semiconductor Co., Ltd. MC96F6432A Data Memory Upper 128bytes Special Function Registers Internal RAM 128bytes (Indirect Addressing) (Direct Addressing) Lower 128bytes Internal RAM (Direct or Indirect Addressing) Figure 8.2 Data Memory Map The internal data memory space is divided into three blocks, which are generally referred to as the lower 128 bytes, upper 128 bytes and SFR space.
  • Page 51 MC96F6432A ABOV Semiconductor Co., Ltd. 7F 7E 7D 7C 7B 7A 79 78 77 76 75 74 73 72 71 70 6F 6E 6D 6C 6B 6A 69 68 67 66 65 64 63 62 61 60 5F 5E 5D 5C 5B 5A 59 58...
  • Page 52: External Data Memory

    ABOV Semiconductor Co., Ltd. MC96F6432A External Data Memory MC96F6432A has 768 bytes XRAM and XSFR. This area has no relation with RAM/FLASH. It can be read and written to through SFR with 8-bit unit. 107FH Extended Special Function Registers 128bytes...
  • Page 53: Sfr Map

    MC96F6432A ABOV Semiconductor Co., Ltd. SFR Map 8.4.1 SFR Map Summary Reserved M8051 compatible 00H/8H 01H/9H 02H/0AH 03H/0BH 04H/0CH 05H/0DH 06H/0EH 07H/0FH – 0F8H FSADRH FSADRM FSADRL FIDR FMCR P5FSR 0F0H USI1ST1 USI1ST2 USI1BD USI1SDHR USI1DR USI1SCLR USI1SCHR 0E8H RSTFR...
  • Page 54 ABOV Semiconductor Co., Ltd. MC96F6432A 00H/8H 01H/9H 02H/0AH 03H/0BH 04H/0CH 05H/0DH 06H/0EH 07H/0FH – – – – – – – – 1078H – – – – – – – – 1070H – – – – – – – – 1068H –...
  • Page 55: Sfr Map

    MC96F6432A ABOV Semiconductor Co., Ltd. 8.4.2 SFR Map @Reset Address Function Symbol P0 Data Register Stack Pointer Data Pointer Register Low Data Pointer Register High Data Pointer Register Low 1 DPL1 Data Pointer Register High 1 DPH1 – – Low Voltage Indicator Control Register LVICR –...
  • Page 56 ABOV Semiconductor Co., Ltd. MC96F6432A @Reset Address Function Symbol – – – – P4 Data Register P0 Direction Register P0IO – – – – Extended Operation Register – – – – P4 Pull-up Resistor Selection Register P4PU External Interrupt Polarity 0 Low Register...
  • Page 57 MC96F6432A ABOV Semiconductor Co., Ltd. @Reset Address Function Symbol External Interrupt Flag 0 Register EIFLAG0 P3 Direction Register P3IO Timer 2 Control Low Register – – T2CRL Timer 2 Control High Register – – – – T2CRH Timer 2 A Data Low Register...
  • Page 58 ABOV Semiconductor Co., Ltd. MC96F6432A @Reset Address Function Symbol Accumulator Register – USI0 Status Register 1 USI0ST1 USI0 Status Register 2 USI0ST2 USI0 Baud Rate Generation Register USI0BD USI0 SDA Hold Time Register USI0SDHR USI0 Data Register USI0DR USI0 SCL Low Period Register...
  • Page 59 MC96F6432A ABOV Semiconductor Co., Ltd. @Reset Address Function Symbol – 1000H Timer 3 Control Register T3CR Timer 3 Counter Register T3CNT 1001H Timer 3 Data Register T3DR Timer 3 Capture Data Register T3CAPR 1002H Timer 4 Control Register T4CR 1003H...
  • Page 60: Sfr Map

    ABOV Semiconductor Co., Ltd. MC96F6432A 8.4.3 SFR Map ACC (Accumulator Register): E0H Initial value: 00H Accumulator B (B Register): F0H Initial value: 00H B Register SP (Stack Pointer): 81H Initial value: 07H Stack Pointer DPL (Data Pointer Register Low): 82H...
  • Page 61 MC96F6432A ABOV Semiconductor Co., Ltd. DPL1 (Data Pointer Register Low 1): 84H DPL1 Initial value: 00H DPL1 Data Pointer Low 1 DPH1 (Data Pointer Register High 1): 85H DPH1 Initial value: 00H DPH1 Data Pointer High 1 PSW (Program Status Word Register): D0H...
  • Page 62: O Ports

    I/O Ports The MC96F6432A has six groups of I/O ports (P0 ~ P5). Each port can be easily configured by software as I/O pin, internal pull up and open-drain pin to meet various system configurations and design requirements. Also P0 includes function that can generate interrupt according to change of state of the pin.
  • Page 63: Port Function Selection Register (Pxfsr)

    MC96F6432A ABOV Semiconductor Co., Ltd. 9.2.6 Port Function Selection Register (PxFSR) These registers define alternative functions of ports. Please remember that these registers should be set properly for alternative port function. A reset clears the PxFSR register to ‘00H’, which makes all pins to normal I/O ports.
  • Page 64: P0 Port

    ABOV Semiconductor Co., Ltd. MC96F6432A P0 Port 9.3.1 P0 Port Description P0 is 8-bit I/O port. P0 control registers consist of P0 data register (P0), P0 direction register (P0IO), debounce enable register (P0DB), P0 pull-up resistor selection register (P0PU) and P0 open-drain selection register (P0OD).
  • Page 65 MC96F6432A ABOV Semiconductor Co., Ltd. P0OD (P0 Open-drain Selection Register): 91H P07OD P06OD P05OD P04OD P03OD P02OD P01OD P00OD Initial value: 00H P0OD[7:0] Configure Open-drain of P0 Port Push-pull output Open-drain output P0DB (P0 De-bounce Enable Register): DEH DBCLK1 DBCLK0...
  • Page 66 ABOV Semiconductor Co., Ltd. MC96F6432A P0FSRH (Port 0 Function Selection High Register): D3H – – P0FSRH5 P0FSRH4 P0FSRH3 P0FSRH2 P0FSRH1 P0FSRH0 – – Initial value: 00H P0FSRH[5:4] P07 Function Select P0FSRH5 P0FSRH4 Description I/O Port (EINT5 function possible when input)
  • Page 67 MC96F6432A ABOV Semiconductor Co., Ltd. P0FSRL (Port 0 Function Selection Low Register): D2H – P0FSRL6 P0FSRL5 P0FSRL4 P0FSRL3 P0FSRL2 P0FSRL1 P0FSRL0 – Initial value: 00H P0FSRL[6:5] P04 Function Select P0FSRL6 P0FSRL5 Description I/O Port(EINT2 function possible when input) SEG25 Function...
  • Page 68: P1 Port

    ABOV Semiconductor Co., Ltd. MC96F6432A P1 Port 9.4.1 P1 Port Description P1 is 8-bit I/O port. P1 control registers consist of P1 data register (P1), P1 direction register (P1IO), debounce enable register (P15DB), P1 pull-up resistor selection register (P1PU) and P1 open-drain selection register (P1OD). Refer to the port function selection registers for the P1 function selection.
  • Page 69 MC96F6432A ABOV Semiconductor Co., Ltd. P1OD (P1 Open-drain Selection Register): 92H P17OD P16OD P15OD P14OD P13OD P12OD P11OD P10OD Initial value: 08H P1OD[7:0] Configure Open-drain of P1 Port Push-pull output Open-drain output P15DB (P1/P5 De-bounce Enable Register): DFH – –...
  • Page 70 ABOV Semiconductor Co., Ltd. MC96F6432A P1FSRH (Port 1 Function Selection High Register): D5H P1FSRH7 P1FSRH6 P1FSRH5 P1FSRH4 P1FSRH3 P1FSRH2 P1FSRH1 P1FSRH0 Initial value: 00H P1FSRH[7:6] P17 Function Select P1FSRH7 P1FSRH6 Description I/O Port(EINT6/SS2 function possible when input) SEG21 Function AN6 Function...
  • Page 71 MC96F6432A ABOV Semiconductor Co., Ltd. P1FSRL (Port 1 Function Selection Low Register): D4H P1FSRL7 P1FSRL6 P1FSRL5 P1FSRL4 P1FSRL3 P1FSRL2 P1FSRL1 P1FSRL0 Initial value: 00H P1FSRL[7:6] P13 Function Select P1FSRL7 P1FSRL6 Description I/O Port(EC1 function possible when input) SEG17 Function AN10 Function...
  • Page 72: P2 Port

    ABOV Semiconductor Co., Ltd. MC96F6432A P2 Port 9.5.1 P2 Port Description P2 is 8-bit I/O port. P2 control registers consist of P2 data register (P2), P2 direction register (P2IO), P2 pull-up resistor selection register (P2PU) and P2 open-drain selection register (P2OD).Refer to the port function selection registers for the P2 function selection.
  • Page 73 MC96F6432A ABOV Semiconductor Co., Ltd. P2PU (P2 Pull-up Resistor Selection Register): AEH P27PU P26PU P25PU P24PU P23PU P22PU P21PU P20PU Initial value: 00H P2PU[7:0] Configure Pull-up Resistor of P2 Port Disable Enable P2OD (P2 Open-drain Selection Register): 93H P27OD P26OD...
  • Page 74 ABOV Semiconductor Co., Ltd. MC96F6432A P2FSRH (Port 2 Function Selection High Register): D7H – – – – P2FSRH3 P2FSRH2 P2FSRH1 P2FSRH0 – – – – Initial value: 00H P2FSRH3 P27 Function select I/O Port SEG6 Function P2FSRH2 P26 Function Select...
  • Page 75: P3 Port

    MC96F6432A ABOV Semiconductor Co., Ltd. P3 Port 9.6.1 P3 Port Description P3 is 8-bit I/O port. P3 control registers consist of P3 data register (P3), P3 direction register (P3IO) and P3 pull-up resistor selection register (P3PU). Refer to the port function selection registers for the P3 function selection.
  • Page 76 ABOV Semiconductor Co., Ltd. MC96F6432A P3FSR (Port 3 Function Selection Register): EEH P3FSR7 P3FSR6 P3FSR5 P3FSR4 P3FSR3 P3FSR2 P3FSR1 P3FSR0 Initial value: 00H P3FSR7 P37 Function select I/O Port COM0 Function P3FSR6 P36 Function Select I/O Port COM1 Function P3FSR5...
  • Page 77: P4 Port

    MC96F6432A ABOV Semiconductor Co., Ltd. P4 Port 9.7.1 P4 Port Description P4 is 4-bit I/O port. P4 control registers consist of P4 data register (P4), P4 direction register (P4IO), P4 pull-up resistor selection register (P4PU) and P4 open-drain selection register (P4OD).Refer to the port function selection registers for the P4 function selection.
  • Page 78 ABOV Semiconductor Co., Ltd. MC96F6432A P4OD (P4 Open-drain Selection Register): 94H – – – – P43OD P42OD P41OD P40OD – – – – Initial value: 00H P4OD[3:0] Configure Open-drain of P4 Port Push-pull output Open-drain output P4FSR (Port 4 Function Selection Register): EFH –...
  • Page 79: P5 Port

    MC96F6432A ABOV Semiconductor Co., Ltd. P5 Port 9.8.1 P5 Port Description P5 is 6-bit I/O port. P5 control registers consist of P5 data register (P5), P5 direction register (P5IO) and P5 pull-up resistor selection register (P5PU). Refer to the port function selection registers for the P5 function selection.
  • Page 80 ABOV Semiconductor Co., Ltd. MC96F6432A P5FSR (Port 5 Function Selection Register): FFH – – P5FSR5 P5FSR4 P5FSR3 P5FSR2 P5FSR1 P5FSR0 – – Initial value: 00H P5FSR5 P54 Function Select I/O Port(EINT10 function possible when input) SXOUT Function P5FSR[4:3] P53 Function Select...
  • Page 81: Interrupt Controller

    10.1 Overview The MC96F6432A supports up to 23 interrupt sources. The interrupts have separate enable register bits and allows software control. They can also have four levels of priority assigned to them. The non-maskable interrupt source is always enabled with a higher priority than any other interrupt source and is not controllable by software. The interrupt controller has following features: −...
  • Page 82 ABOV Semiconductor Co., Ltd. MC96F6432A Interrupt Highest Lowest Group 0 (Bit0) Interrupt 0 Interrupt 6 Interrupt 12 Interrupt 18 Highest 1 (Bit1) Interrupt 1 Interrupt 7 Interrupt 13 Interrupt 19 2 (Bit2) Interrupt 2 Interrupt 8 Interrupt 14 Interrupt 20...
  • Page 83: External Interrupt

    MC96F6432A ABOV Semiconductor Co., Ltd. 10.2 External Interrupt The external interrupt on INT0, INT1, INT5, INT6 and INT11 pins receive various interrupt request depending on the external interrupt polarity 0 high/low register (EIPOL0H/L) and external interrupt polarity 1 register (EIPOL1) as shown in Figure 10.1.
  • Page 84: Block Diagram

    ABOV Semiconductor Co., Ltd. MC96F6432A 10.3 Block Diagram EIPOL1 EIFLAG1.1 EINT10 FLAG10 EIFLAG1.2 Priority High EINT11 FLAG11 USI1 I2C I2C1IFR USI1 Rx USI1 Tx EIPOL0H/L EIFLAG0.0 EINT0 FLAG0 EIFLAG0.1 EINT1 FLAG1 EIFLAG0.2 EINT2 FLAG2 EIFLAG0.3 EINT3 FLAG3 EIFLAG0.4 EINT4 FLAG4 EIFLAG0.5...
  • Page 85: Interrupt Vector Table

    MC96F6432A ABOV Semiconductor Co., Ltd. 10.4 Interrupt Vector Table The interrupt controller supports 24 interrupt sources as shown in the Table 10.2. When interrupt is served, long call instruction (LCALL) is executed and program counter jumps to the vector address. All interrupt requests have a decided priority order.
  • Page 86: Interrupt Sequence

    ABOV Semiconductor Co., Ltd. MC96F6432A 10.5 Interrupt Sequence An interrupt request is held until the interrupt is accepted or the interrupt latch is cleared to ‘0’ by a reset or an instruction. Interrupt acceptance always generates at last cycle of the instruction. So instead of fetching the current instruction, CPU executes internally LCALL instruction and saves the PC at stack.
  • Page 87: Effective Timing After Controlling Interrupt Bit

    MC96F6432A ABOV Semiconductor Co., Ltd. 10.6 Effective Timing after Controlling Interrupt Bit Case a) Control Interrupt Enable Register (IE, IE1, IE2, IE3) Interrupt Enable Register command After executing IE set/clear, enable register is effective. Next Instruction Next Instruction Figure 10.4...
  • Page 88: Multi Interrupt

    ABOV Semiconductor Co., Ltd. MC96F6432A 10.7 Multi Interrupt If two different priority level requests are received simultaneously, the higher priority level request is serviced. If requests of the interrupt are received at the same time, an interrupt polling sequence determines by hardware which request is serviced.
  • Page 89: Interrupt Enable Accept Timing

    MC96F6432A ABOV Semiconductor Co., Ltd. 10.8 Interrupt Enable Accept Timing Max. 4 Machine Cycle 4 Machine Cycle System Clock Interrupt goes Active Interrupt Interrupt Processing Latched Interrupt Routine : LCALL & LJMP Figure 10.7 Interrupt Response Timing Diagram 10.9 Interrupt Service Routine Address...
  • Page 90: Interrupt Timing

    ABOV Semiconductor Co., Ltd. MC96F6432A 10.11 Interrupt Timing Interrupt sampled here CLP2 CLP1 CLP2 C1P1 C1P2 C2P1 C2P2 SCLK INT_SRC INTR_ACK LAST_CYC INTR_LCALL 8-bit interrupt Vector INT_VEC {8’h00, INT_VEC} PROGA Figure 10.10 Timing Chart of Interrupt Acceptance and Interrupt Return Instruction Interrupt sources are sampled at the last cycle of a command.
  • Page 91: External Interrupt Flag Register (Eiflag0, Eiflag1)

    MC96F6432A ABOV Semiconductor Co., Ltd. 10.12.3 External Interrupt Flag Register (EIFLAG0, EIFLAG1) The external interrupt flag 0 register (EIFLAG0) and external interrupt flag 1 register (EIFLAG1) are set to ‘1’ when the external interrupt generating condition is satisfied. The flag is cleared when the interrupt service routine is executed.
  • Page 92: Register Description For Interrupt

    ABOV Semiconductor Co., Ltd. MC96F6432A 10.12.7 Register Description for Interrupt IE (Interrupt Enable Register): A8H – INT5E INT4E INT3E INT2E INT1E INT0E – Initial value: 00H Enable or Disable All Interrupt bits All Interrupt disable All Interrupt enable INT5E Enable or Disable External Interrupt 0 ~ 7 (EINT0 ~ EINT7)
  • Page 93 MC96F6432A ABOV Semiconductor Co., Ltd. IE1 (Interrupt Enable Register 1): A9H – – – INT11E INT10E INT9E INT8E INT6E – – – Initial value: 00H INT11E Enable or Disable External Interrupt 12 (EINT12) Disable Enable INT10E Enable or Disable USI0 Tx Interrupt...
  • Page 94 ABOV Semiconductor Co., Ltd. MC96F6432A IE2 (Interrupt Enable Register 2): AAH –- – INT17E INT16E INT15E INT14E INT13E INT12E – – Initial value: 00H INT17E Enable or Disable Timer 4 Interrupt Disable Enable INT16E Enable or Disable Timer 3 Match Interrupt...
  • Page 95 MC96F6432A ABOV Semiconductor Co., Ltd. IP (Interrupt Priority Register): B8H – – – – Initial value: 00H IP1 (Interrupt Priority Register 1): F8H – – IP15 IP14 IP13 IP12 IP11 IP10 – – Initial value: 00H IP[5:0], Select Interrupt Group Priority...
  • Page 96 ABOV Semiconductor Co., Ltd. MC96F6432A EIFLAG0 (External Interrupt Flag 0 Register): C0H FLAG7 FLAG6 FLAG5 FLAG4 FLAG3 FLAG2 FLAG1 FLAG0 Initial value: 00H When an External Interrupt 0-7 is occurred, the flag becomes ‘1’. The flag is cleared EIFLAG0[7:0] only by writing ‘0’ to the bit. So, the flag should be cleared by software.
  • Page 97 MC96F6432A ABOV Semiconductor Co., Ltd. EIFLAG1 (External Interrupt Flag 1 Register): A6H – T0OVIFR T0IFR T3IFR FLAG12 FLAG11 FLAG10 FLAG8 – Initial value: 00H When T0 overflow interrupt occurs, this bit becomes ‘1’. For clearing bit, write ‘0’ to T0OVIFR this bit or automatically clear by INT_ACK signal.
  • Page 98: Peripheral Hardware

    ABOV Semiconductor Co., Ltd. MC96F6432A Peripheral Hardware 11.1 Clock Generator 11.1.1 Overview As shown in Figure 11.1, the clock generator produces the basic clock pulses which provide the system clock to be supplied to the CPU and the peripheral hardware. It contains main/sub-frequency clock oscillator. The main/sub clock operation can be easily obtained by attaching a crystal between the XIN/SXIN and XOUT/SXOUT pin, respectively.
  • Page 99: Block Diagram

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.1.2 Block Diagram Main OSC XOUT STOP Mode IRCS[2:0] XCLKE System SCLK Clock Gen. (Core, System, Clock Peripheral) Change Internal RC OSC (16MHz) 1/16 Stabilization Time 1/32 Generation BITCK[1:0] STOP Mode overflow IRCE WDT clock...
  • Page 100: Register Map

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.1.3 Register Map Name Address Direction Default Description SCCR System and Clock Control Register OSCCR Oscillator Control Register XTFLSR 1038H X-tal Filter Selection Register Clock Generator Register Map Table 11.1 11.1.4 Clock Generator Register Description The clock generator register uses clock control for system operation.
  • Page 101 MC96F6432A ABOV Semiconductor Co., Ltd. OSCCR (Oscillator Control Register): C8H – – IRCS2 IRCS1 IRCS0 IRCE XCLKE SCLKE – – Initial value: 08H IRCS[2:0] Internal RC Oscillator Post-divider Selection IRCS2 IRCS1 IRCS0 Description INT-RC/32 (0.5MHz) INT-RC/16 (1MHz) INT-RC/8 (2MHz) INT-RC/4 (4MHz)
  • Page 102 ABOV Semiconductor Co., Ltd. MC96F6432A XTFLSR (X-tal Filter Selection Register): 1038H (ESFR) – – WTP4 WTP3 WTP2 WTP1 WTP0 XRNS – – Initial value: 00H Write Identification bits. These bits are automatically cleared to “00000b” immediately WTP[4:0] after XTFLSR write. 0x00 on read.
  • Page 103: Basic Interval Timer

    11.2.1 Overview The MC96F6432A has one 8-bit basic interval timer that is free-run and can’t stop. Block diagram is shown in Figure 11.2. In addition, the basic interval timer generates the time base for watchdog timer counting. It also provides a basic interval timer interrupt (BITIFR).
  • Page 104: Basic Interval Timer Register Description

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.2.4 Basic Interval Timer Register Description The basic interval timer register consists of basic interval timer counter register (BITCNT) and basic interval timer control register (BITCR). If BCLR bit is set to ‘1’, BITCNT becomes ‘0’ and then counts up. After 1 machine cycle, BCLR bit is cleared to ‘0’...
  • Page 105: Watch Dog Timer

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.3 Watch Dog Timer 11.3.1 Overview The watchdog timer rapidly detects the CPU malfunction such as endless looping caused by noise or something like that and resumes the CPU to the normal state. The watchdog timer signal for malfunction detection can be used as either a CPU reset or an interrupt request.
  • Page 106: Block Diagram

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.3.3 Block Diagram clear WDT Clock To RESET WDTCNT Circuit WDTEN To interrupt WDTIFR block clear WDTDR INT_ACK WDTCL WDTRSON WDTCR Figure 11.4 Watch Dog Timer Block Diagram 11.3.4 Register Map Name Address Direction Default...
  • Page 107: Register Description For Watch Dog Timer

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.3.6 Register Description for Watch Dog Timer WDTCNT (Watch Dog Timer Counter Register: Read Case): 8EH WDTCNT 7 WDTCNT 6 WDTCNT 5 WDTCNT 4 WDTCNT3 WDTCNT 2 WDTCNT 1 WDTCNT 0 Initial value: 00H WDTCNT[7:0]...
  • Page 108: Watch Timer

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.4 Watch Timer 11.4.1 Overview The watch timer has the function for RTC (Real Time Clock) operation. It is generally used for RTC design. The internal structure of the watch timer consists of the clock source select circuit, timer counter circuit, output select circuit and watch timer control register.
  • Page 109: Register Map

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.4.3 Register Map Name Address Direction Default Description WTCNT Watch Timer Counter Register WTDR Watch Timer Data Register WTCR Watch Timer Control Register Watch Timer Register Map Table 11.4 11.4.4 Watch Timer Register Description The watch timer register consists of watch timer counter register (WTCNT), watch timer data register (WTDR) and watch timer control register (WTCR).
  • Page 110 ABOV Semiconductor Co., Ltd. MC96F6432A WTCR (Watch Timer Control Register): 96H – – WTEN WTIFR WTIN1 WTIN0 WTCK1 WTCK0 – – Initial value: 00H WTEN Control Watch Timer Disable Enable When WT Interrupt occurs, this bit becomes ‘1’. For clearing bit, write ‘0’ to this bit or WTIFR automatically clear by INT_ACK signal.
  • Page 111: Timer 0

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.5 Timer 0 11.5.1 Overview The 8-bit timer 0 consists of multiplexer, timer 0 counter register, timer 0 data register, timer 0 capture data register and timer 0 control register (T0CNT, T0DR, T0CDR, T0CR). It has three operating modes: −...
  • Page 112: 8-Bit Timer/Counter Mode

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.5.2 8-bit Timer/Counter Mode The 8-bit timer/counter mode is selected by control register as shown in Figure 11.6. The 8-bit timer has counter and data register. The counter register is increased by internal or external clock input. The timer 0 can use the input clock with one of 2, 4, 8, 32, 128, 512 and 2048 prescaler division rates (T0CK[2:0]).
  • Page 113: 8-Bit Pwm Mode

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.5.3 8-bit PWM Mode The timer 0 has a high speed PWM (Pulse Width Modulation) function. In PWM mode, T0O/PWM0O pin outputs up to 8-bit resolution PWM output. This pin should be configured as a PWM output by setting the T0O/PWM0O function by P5FSR[4:3] bits.
  • Page 114 ABOV Semiconductor Co., Ltd. MC96F6432A PWM Mode(T0MS = 01b) Set T0EN Timer 0 clock T0CNT T0DR T0 Overflow Interrupt 1. T0DR = 4AH T0PWM T0 Match Interrupt 2. T0DR = 00H T0PWM T0 Match Interrupt 3. T0DR = FFH T0PWM...
  • Page 115: 8-Bit Capture Mode

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.5.4 8-bit Capture Mode The timer 0 capture mode is evoked by setting T0MS[1:0] as ‘1x’. The clock source can use the internal/external clock. Basically, it has the same function as the 8-bit timer/counter mode and the interrupt occurs when T0CNT is equal to T0DR.
  • Page 116 ABOV Semiconductor Co., Ltd. MC96F6432A T0CDR Load T0CNT Value Count Pulse Period Up-count TIME Ext. EINT10 PIN Interrupt Request (FLAG10) Interrupt Interval Period Figure 11.11 Input Capture Mode Operation for Timer 0 T0CNT Interrupt Request (T0IFR) Ext. EINT10 PIN Interrupt...
  • Page 117: Block Diagram

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.5.5 Block Diagram INT_ACK Clear To interrupt T0OVIFR block fx/2 fx/4 8-bit Timer 0 Counter Match signal fx/8 Clear INT_ACK T0CNT (8Bit) fx/32 T0CC Clear fx/128 Clear fx/512 Match To interrupt T0EN T0IFR block fx/2048...
  • Page 118: Register Description For Timer/Counter 0

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.5.8 Register Description for Timer/Counter 0 T0CNT (Timer 0 Counter Register): B3H T0CNT7 T0CNT6 T0CNT5 T0CNT4 T0CNT3 T0CNT2 T0CNT1 T0CNT0 Initial value: 00H T0CNT[7:0] T0 Counter T0DR (Timer 0 Data Register): B4H T0DR7 T0DR6 T0DR5...
  • Page 119 MC96F6432A ABOV Semiconductor Co., Ltd. T0CR (Timer 0 Control Register): B2H – T0EN T0MS1 T0MS0 T0CK2 T0CK1 T0CK0 T0CC – Initial value: 00H T0EN Control Timer 0 Timer 0 disable Timer 0 enable T0MS[1:0] Control Timer 0 Operation Mode T0MS1...
  • Page 120: Timer 1

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.6 Timer 1 11.6.1 Overview The 16-bit timer 1 consists of multiplexer, timer 1 A data register high/low, timer 1 B data register high/low and timer 1 control register high/low (T1ADRH, T1ADRL, T1BDRH, T1BDRL, T1CRH, T1CRL).
  • Page 121 MC96F6432A ABOV Semiconductor Co., Ltd. ADDRESS:BBH – – – – T1EN T1MS1 T1MS0 T1CC T1CRH INITIAL VALUE : 0000_0000B – – – – ADDRESS:BAH – T1CK2 T1CK1 T1CK0 T1IFR T1POL T1ECE T1CNTR T1CRL INITIAL VALUE : 0000_0000B – 16-bit A Data Register...
  • Page 122: 16-Bit Capture Mode

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.6.3 16-bit Capture Mode The 16-bit timer 1 capture mode is evoked by setting T1MS[1:0] as ‘01’. The clock source can use the internal/external clock. Basically, it has the same function as the 16-bit timer/counter mode and the interrupt occurs when T1CNTH/T1CNTL is equal to T1ADRH/T1ADRL.
  • Page 123 MC96F6432A ABOV Semiconductor Co., Ltd. T1BDRH/L Load T1CNTH/L Value Count Pulse Period Up-count TIME Ext. EINT11 PIN Interrupt Request (FLAG11) Interrupt Interval Period Figure 11.17 Input Capture Mode Operation for Timer 1 FFFF FFFF T1CNTH/L Interrupt Request (T1IFR) Ext. EINT11 PIN...
  • Page 124: 16-Bit Ppg Mode

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.6.4 16-bit PPG Mode The timer 1 has a PPG (Programmable Pulse Generation) function. In PPG mode, T1O/PWM1O pin outputs up to 16- bit resolution PWM output. This pin should be configured as a PWM output by setting P1FSRL[5:4] to ‘11’. The period of the PWM output is determined by the T1ADRH/T1ADRL.
  • Page 125 MC96F6432A ABOV Semiconductor Co., Ltd. Repeat Mode(T1MS = 11b) and "Start High"(T1POL = 0b). Clear and Start Set T1EN Timer 1 clock Counter T1ADRH/L T1 Interrupt 1. T1BDRH/L(5) < T1ADRH/L PWM1O B Match A Match 2. T1BDRH/L >= T1ADRH/L PWM1O A Match 3.
  • Page 126: Block Diagram

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.6.5 Block Diagram 16-bit A Data Register T1ADRH/T1ADRL A Match Reload T1CC T1EN To Timer 2 T1CK[2:0] block T1ECE INT_ACK Buffer Register A Clear Edge A Match Detector To interrupt T1IFR block T1EN fx/1 Comparator...
  • Page 127: Timer/Counter 1 Register Description

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.6.7 Timer/Counter 1 Register Description The timer/counter 1 register consists of timer 1 A data high register (T1ADRH), timer 1 A data low register (T1ADRL), timer 1 B data high register (T1BDRH), timer 1 B data low register (T1BDRL), timer 1 control high register (T1CRH) and timer 1 control low register (T1CRL).
  • Page 128 ABOV Semiconductor Co., Ltd. MC96F6432A T1CRH (Timer 1 Control High Register): BBH – – – – T1EN T1MS1 T1MS0 T1CC – – – – Initial value: 00H T1EN Control Timer 1 Timer 1 disable Timer 1 enable (Counter clear and start)
  • Page 129 MC96F6432A ABOV Semiconductor Co., Ltd. T1CRL (Timer 1 Control Low Register): BAH – T1CK2 T1CK1 T1CK0 T1IFR T1POL T1ECE T1CNTR – Initial value: 00H T1CK[2:0] Select Timer 1 clock source. fx is main system clock frequency T1CK2 T1CK1 T1CK0 Description...
  • Page 130: Timer 2

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.7 Timer 2 11.7.1 Overview The 16-bit timer 2 consists of multiplexer, timer 2 A data high/low register, timer 2 B data high/low register and timer 2 control high/low register (T2ADRH, T2ADRL, T2BDRH, T2BDRL, T2CRH and T2CRL).
  • Page 131: 16-Bit Timer/Counter Mode

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.7.2 16-bit Timer/Counter Mode The 16-bit timer/counter mode is selected by control register as shown in Figure 11.22. The 16-bit timer have counter and data register. The counter register is increased by internal or timer 1 A match clock input.
  • Page 132 ABOV Semiconductor Co., Ltd. MC96F6432A Match with T2ADRH/L T2CNTH/L Value Count Pulse Period Up-count TIME Interrupt Period x (n+1) Timer 2 (T2IFR) Interrupt Occur Occur Occur Interrupt Interrupt Interrupt Figure 11.23 16-bit Timer/Counter 2 Example...
  • Page 133: 16-Bit Capture Mode

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.7.3 16-bit Capture Mode The timer 2 capture mode is evoked by setting T2MS[1:0] as ‘01’. The clock source can use the internal clock. Basically, it has the same function as the 16-bit timer/counter mode and the interrupt occurs when T2CNTH/T2CNTL is equal to T2ADRH/T2ADRL.
  • Page 134 ABOV Semiconductor Co., Ltd. MC96F6432A T2BDRH/L Load T2CNTH/L Value Count Pulse Period Up-count TIME Ext. EINT12 PIN Interrupt Request (FLAG12) Interrupt Interval Period Figure 11.25 Input Capture Mode Operation for Timer 2 FFFF FFFF T2CNTH/L Interrupt Request (T2IFR) Ext. EINT12 PIN...
  • Page 135: 16-Bit Ppg Mode

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.7.4 16-bit PPG Mode The timer 2 has a PPG (Programmable Pulse Generation) function. In PPG mode, the T2O/PWM2O pin outputs up to 16-bit resolution PWM output. This pin should be configured as a PWM output by set P1FSRL[3:2] to ‘11’. The period of the PWM output is determined by the T2ADRH/T2ADRL.
  • Page 136 ABOV Semiconductor Co., Ltd. MC96F6432A Repeat Mode(T2MS = 11b) and "Start High"(T2POL = 0b). Clear and Start Set T2EN Timer 2 clock Counter T2ADRH/L T2 Interrupt 1. T2BDRH/L(5) < T2ADRH/L PWM2O B Match A Match 2. T2BDRH/L >= T2ADRH/L PWM2O A Match 3.
  • Page 137: Block Diagram

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.7.5 Block Diagram 16-bit A Data Register T2ADRH/T2ADRL A Match Reload T2CC T2CK[2:0] T2EN INT_ACK Buffer Register A Clear T1 A Match A Match To interrupt T2IFR block T2EN fx/1 Comparator fx/2 A Match Clear...
  • Page 138: Timer/Counter 2 Register Description

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.7.7 Timer/Counter 2 Register Description The timer/counter 2 register consists of timer 2 A data high register (T2ADRH), timer 2 A data low register (T2ADRL), timer 2 B data high register (T2BDRH), timer 2 B data low register (T2BDRL), timer 2 control high register (T2CRH) and timer 2 control low register (T2CRL).
  • Page 139 MC96F6432A ABOV Semiconductor Co., Ltd. T2CRH (Timer 2 Control High Register): C3H – – – – T2EN T2MS1 T2MS0 T2CC – – – – Initial value: 00H T2EN Control Timer 2 Timer 2 disable Timer 2 enable (Counter clear and start)
  • Page 140 ABOV Semiconductor Co., Ltd. MC96F6432A T2CRL (Timer 2 Control Low Register): CAH – – T2CK2 T2CK1 T2CK0 T2IFR T2POL T2CNTR – – Initial value: 00H T2CK[2:0] Select Timer 2 clock source. fx is main system clock frequency T2CK2 T2CK1 T2CK0 Description...
  • Page 141: Timer 3, 4

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.8 Timer 3, 4 11.8.1 Overview Timer 3 and timer 4 can be used as either two 8-bit timer/counter or one 16-bit timer/counter with combine them. Each 8-bit timer/event counter module has multiplexer, comparator, 8-bit timer data register, 8-bit counter register, control register and capture data register(T3CNT, T3DR, T3CAPR, T3CR, T4CNT, T4DR, T4CAPR and T4CR).
  • Page 142: 8-Bit Timer/Counter 3, 4 Mode

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.8.2 8-bit Timer/Counter 3, 4 Mode The 8-bit timer/counter mode is selected by control register as shown in Figure 11.30. The two 8-bit timers have each counter and data register. The counter register is increased by internal or external clock input.
  • Page 143: 16-Bit Timer/Counter 3 Mode

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.8.3 16-bit Timer/Counter 3 Mode The 16-bit timer/counter mode is selected by control register as shown in Figure 11.31. The 16-bit timer has counter and data register. The counter register is increased by internal or external clock input.
  • Page 144: 8-Bit Timer 3, 4 Capture Mode

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.8.4 8-bit Timer 3, 4 Capture Mode The 8-bit Capture 3 and 4 mode is selected by control register as shown in Figure 11.32. The timer 3, 4 capture mode is set by T3MS, T4MS as ‘1’. The clock source can use the internal/external clock.
  • Page 145 MC96F6432A ABOV Semiconductor Co., Ltd. ADDRESS:1000H (ESFR) – T3EN T3MS T3CK2 T3CK1 T3CK0 T3CN T3ST T3CR INITIAL VALUE : 0000_0000B – ADDRESS:1002H (ESFR) 16BIT T4MS T4CN T4ST T4CK3 T4CK2 T4CK1 T4CK0 T4CR INITIAL VALUE : 0000_0000B FLAG0 To interrupt (EIFLAG0.1)
  • Page 146: 16-Bit Timer 3 Capture Mode

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.8.5 16-bit Timer 3 Capture Mode The 16-bit Capture mode is selected by control register as shown in Figure 11.33. The 16-bit capture mode is the same operation as 8-bit capture mode, except that the timer register uses 16 bits. The ‘1’.
  • Page 147: 10-Bit Timer 4 Pwm Mode

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.8.6 10-bit Timer 4 PWM Mode The timer 4 has a high speed PWM (Pulse Width Modulation) function. In PWM mode, the 6-channel pins output up to 10-bit resolution PWM output. This pin should be configured as a PWM output by set PWM4E to ‘1’. When the value of 2-bit +T4CNT and T4PPRH/L are identical in timer 4, a period match signal is generated and the interrupt of timer 4 occurs.
  • Page 148 ABOV Semiconductor Co., Ltd. MC96F6432A ADDRESS:1002H (ESFR) 16BIT T4MS T4CN T4ST T4CK3 T4CK2 T4CK1 T4CK0 T4CR INITIAL VALUE : 0000_0000B ADDRESS:1003H (ESFR) PWM4E ESYNC BMOD PHLT UPDT UALL NOPS1 NOPS0 T4PCR1 INITIAL VALUE : 0000_0000B ADDRESS:1004H (ESFR) – FORCA PAAOE PABOE PBAOE PBBOE PCAOE PCBOE...
  • Page 149 MC96F6432A ABOV Semiconductor Co., Ltd. ADDRESS:1002H (ESFR) 16BIT T4MS T4CN T4ST T4CK3 T4CK2 T4CK1 T4CK0 T4CR INITIAL VALUE : 0000_0000B ADDRESS:1003H (ESFR) PWM4E ESYNC BMOD PHLT UPDT UALL NOPS1 NOPS0 T4PCR1 INITIAL VALUE : 0000_0000B ADDRESS:1004H (ESFR) – FORCA PAAOE PABOE PBAOE PBBOE PCAOE PCBOE...
  • Page 150 ABOV Semiconductor Co., Ltd. MC96F6432A Source Clock T4CNT P02/PWM4AA POLAA = 1 P02/PWM4AA POLAA = 0 Duty Cycle(1+80 )X250ns = 32.25us )X250ns = 256us  3.9kHz Period Cycle(1+3FF T4PPRH(2-bit) T4PPRL(8-bit) T4CR = 00 T4PPRH = 03 T4PPRL = FF T4ADRH = 00...
  • Page 151 MC96F6432A ABOV Semiconductor Co., Ltd. Phase correction & Frequency correction On operating PWM, the phase and the frequency can be changed by using BMOD bit (back-to-back mode) in T4PCR1 register. (Figure 1.38, Figure 11.39, Figure 11.40 referred) In the back-to-back mode, the counter of PWM repeats up/down count. In fact, the effective duty and period becomes twofold of the register set values.
  • Page 152 ABOV Semiconductor Co., Ltd. MC96F6432A Duty, Period Update T4CNT Back-to-Back mode Duty1 Duty2 Duty3 Output Period1 Period2 Period3 Interrupt Timing Overflow INT. Overflow INT. Bottom INT. Overflow INT. Figure 11.40 Example of Phase Correction and Frequency correction of PWM External Sync If using ESYNC bit of T4PCR1 register, it is possible to synchronize the output of PWM from external signal.
  • Page 153 MC96F6432A ABOV Semiconductor Co., Ltd. FORCE Drive ALL Channel with A-ch mode If FORCA bit sets to ‘1’, it is possible to enable or disable all PWM output pins through PWM outputs which occur from A-ch duty counter. It is noted that the inversion outputs of A, B, C channel have the same A-ch output waveform.
  • Page 154 ABOV Semiconductor Co., Ltd. MC96F6432A FORCE 6-Ch Drive If FORCA bit sets to ‘0’, it is possible to enable or disable PWM output pin and inversion output pin generated through the duty counter of each channel. The inversion output is the reverse phase of the PWM output. A AA/AB output of the A-channel duty register, a BA/BB output of the B-channel duty register, a CA/CB output of the C-channel duty register are controlled respectively.
  • Page 155 MC96F6432A ABOV Semiconductor Co., Ltd. PWM output Delay If using the T4DLYA, T4DLYB and T4DLYC register, it can delay PWM output based on the rising edge. At that time, it does not change the falling edge, so the duty is reduced as the time delay. In POLAA/BA/CA setting to ‘0’, the delay is applied to the falling edge.
  • Page 156 ABOV Semiconductor Co., Ltd. MC96F6432A ADDRESS :1004H (ESFR) T4PCR2 FORCA PAAOE PABOE PBAOE PBBOE PCAOE PCBOE INITIAL VALUE : 0-00_0000B ADDRESS : 1005H (ESFR) T4PCR3 HZCLR POLBO POLAA POLAB POLBA POLBB POLCA POLCB INITIAL VALUE : 0000_0000B ADDRESS : 1010H (ESFR)
  • Page 157: Block Diagram

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.8.7 Block Diagram FLAG0 To interrupt (EIFLAG0.1) block T4MS Clear 8-bit Timer 4 Capture Register INT_ACK EINT1 T4CAPR (8Bit) EIPOL0L[3:2] 8-bit Timer 4 Data Register T4CK[3:0] T4DR (8Bit) Comparator fx/1 To interrupt fx/2 T4CN block...
  • Page 158 ABOV Semiconductor Co., Ltd. MC96F6432A T3ST fx/2 fx/4 16-bit Timer 3 Counter fx/8 Clear T4CNT/T3CNT (16Bit) INT_ACK fx/32 Clear fx/128 Clear fx/512 Match To interrupt T3CN T3IFR block fx/2048 Comparator T4DR/T3DR (16Bit) T3CK[2:0] 16-bit Timer 3 Data Register EIPOL0L[1:0] T4CAPR/T3CAPR (16Bit)
  • Page 159: Register Map

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.8.8 Register Map Name Address Direction Default Description T3CNT 1001H (ESFR) Timer 3 Counter Register T3DR 1001H (ESFR) Timer 3 Data Register T3CAPR 1001H (ESFR) Timer 3 Capture Data Register T3CR 1000H (ESFR) Timer 3 Control Register...
  • Page 160: Timer/Counter 3 Register Description

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.8.9 Timer/Counter 3 Register Description The timer/counter 3 register consists of timer 3 counter register (T3CNT), timer 3 data register (T3DR), timer 3 capture data register (T3CAPR) and timer 3 control register (T3CR). 11.8.10 Register Description for Timer/Counter 3...
  • Page 161 MC96F6432A ABOV Semiconductor Co., Ltd. T3CR (Timer 3 Control Register): 1000H (ESFR) – T3EN T3MS T3CK2 T3CK1 T3CK0 T3CN T3ST – Initial value: 00H T3EN Control Timer 3 Timer 3 disable Timer 3 enable T3MS Control Timer 3 Operation Mode...
  • Page 162: Timer/Counter 4 Register Description

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.8.11 Timer/Counter 4 Register Description The timer/counter 4 register consists of timer 4 PWM period high/low register (T4PPRH/L), timer 4 PWM A duty high/low register (T4ADRH/L), timer 4 PWM B duty high/low register (T4BDRH/L), timer 4 PWM C duty high/low...
  • Page 163 MC96F6432A ABOV Semiconductor Co., Ltd. T4BDRH (Timer 4 PWM B Duty High Register: 6-ch PWM mode only): 100DH (ESFR) – – – – – – T4BDRH1 T4BDRH0 – – – – – – Initial value: 00H T4BDRH[1:0] T4 PWM B Duty Data High Byte...
  • Page 164 ABOV Semiconductor Co., Ltd. MC96F6432A T4DLYC (Timer 4 PWM C Delay Register: 6-ch PWM mode only): 1012H (ESFR) T4DLYCA3 T4DLYCA2 T4DLYCA1 T4DLYCA0 T4DLYCB3 T4DLYCB2 T4DLYCB1 T4DLYCB0 Initial value: 00H T4DLYCA[3:0] PWM4CA Delay Data (Rising edge only) T4DLYCB[3:0] PWM4CB Delay Data (Rising edge only)
  • Page 165 MC96F6432A ABOV Semiconductor Co., Ltd. T4CR (Timer 4 Control Register): 1002H (ESFR) 16BIT T4MS T4CN T4ST T4CK3 T4CK2 T4CK1 T4CK0 Initial value: 00H 16BIT Select Two 8-bit or 16-bit Mode for Timer 3/4 Two 8-bit Timer 3/4 16-bit Timer 3...
  • Page 166 ABOV Semiconductor Co., Ltd. MC96F6432A T4PCR1 (Timer 4 PWM Control Register 1): 1003H (ESFR) PWM4E ESYNC BMOD PHLT UPDT UALL NOPS1 NOPS0 Initial value: 00H PWM4E Control Timer 4 Mode Select timer/counter or capture mode of Timer 4 Select 10-bit PWM mode of Timer 4...
  • Page 167 MC96F6432A ABOV Semiconductor Co., Ltd. T4PCR2 (Timer 4 PWM Control Register 2): 1004H (ESFR) – FORCA PAAOE PABOE PBAOE PBBOE PCAOE PCBOE – Initial value: 00H FORCA Control The PWM outputs Mode 6-channel mode (The PWM4xA/PWM4xB pins are output according to the T4xDR registers, respectively.
  • Page 168 ABOV Semiconductor Co., Ltd. MC96F6432A T4PCR3 (Timer 4 PWM Control Register 3): 1005H (ESFR) HZCLR POLBO POLAA POLAB POLBA POLBB POLCA POLCB Initial value: 00H HZCLR High-Impedance Output Clear Bit No effect Clear high-impedance output (The PWM4xA/PWM4xB pins are back to output and this bit is automatically cleared to logic ‘0’.
  • Page 169 MC96F6432A ABOV Semiconductor Co., Ltd. T4ISR (Timer 4 Interrupt Status Register): 1006H (ESFR) – – – IOVR IBTM ICMA ICMB ICMC – – – Initial value: 00H Timer 4 Compare Match or Timer 4 Overflow Interrupt Status, Write ‘0’ to this bit for...
  • Page 170: Buzzer Driver

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.9 Buzzer Driver 11.9.1 Overview The Buzzer consists of 8bit counter, buzzer data register (BUZDR) and buzzer control register (BUZCR). The Square Wave (61.035Hz~125.0kHz @ 8MHz)is outputted through P13/SEG17/AN10/EC1/BUZO pin. The buzzer data register (BUZDR) controls the buzzer frequency (look at the following expression). In buzzer control register(BUZCR), BUCK[1:0] selects source clock divided by prescaler.
  • Page 171: Register Map

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.9.3 Register Map Name Address Direction Default Description BUZDR Buzzer Data Register BUZCR Buzzer Control Register Buzzer Driver Register Map Table 11.16 11.9.4 Buzzer Driver Register Description Buzzer driver consists of buzzer data register (BUZDR) and buzzer control register (BUZCR).
  • Page 172: Spi 2

    11.10 SPI 2 11.10.1 Overview There is serial peripheral interface (SPI 2) one channel in MC96F6432A. The SPI 2 allows synchronous serial data transfer between the external serial devices. It can do Full-duplex communication by 4-wire (MOSI2, MISO2, SCK2, SS2), support master/slave mode, can select serial clock (SCK2) polarity, phase and whether LSB first data transfer or MSB first data transfer.
  • Page 173: Data Transmit / Receive Operation

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.10.3 Data Transmit / Receive Operation User can use SPI 2 for serial data communication by following step 1. Select SPI 2 operation mode(master/slave, polarity, phase) by control register SPICR. 2. When the SPI 2 is configured as a Master, it selects a Slave by SS2 signal (active low).
  • Page 174: Spi 2 Timing Diagram

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.10.5 SPI 2 Timing Diagram SCK2 (CPOL = 0) SCK2 (CPOL = 1) MISO2/MOSI2 (Output) MOSI2/MISO2 (Input) SPIIFR Figure 11.50 SPI 2 Transmit/Receive Timing Diagram at CPHA = 0 SCK2 (CPOL = 0) SCK2 (CPOL = 1)
  • Page 175: Register Map

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.10.6 Register Map Name Address Direction Default Description SPISR SPI 2 Status Register SPIDR SPI 2 Data Register SPICR SPI 2 Control Register SPI 2 Register Map Table 11.17 11.10.7 SPI 2 Register Description The SPI 2 register consists of SPI 2 control register (SPICR), SPI 2 status register (SPISR) and SPI 2 data register (SPIDR) 11.10.8 Register Description for SPI 2...
  • Page 176 ABOV Semiconductor Co., Ltd. MC96F6432A SPISR (SPI 2 Status Register): B7H – – – SPIIFR WCOL SS_HIGH FXCH SSENA – – – Initial value: 00H When SPI 2 Interrupt occurs, this bit becomes ‘1’. IF SPI 2 interrupt is enable, this bit is SPIIFR auto cleared by INT_ACK signal.
  • Page 177 MC96F6432A ABOV Semiconductor Co., Ltd. SPICR (SPI 2 Control Register): B5H SPIEN FLSB CPOL CPHA DSCR SCR1 SCR0 Initial value: 00H SPIEN This bit controls the SPI 2 operation Disable SPI 2 operation Enable SPI 2 operation FLSB This bit selects the data transmission sequence...
  • Page 178: 12-Bit A/D Converter

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.11 12-bit A/D Converter 11.11.1 Overview The analog-to-digital converter (A/D) allows conversion of an analog input signal to corresponding 12-bit digital value. The A/D module has eight analog inputs. The output of the multiplexer is the input into the converter which generates the result through successive approximation.
  • Page 179: Block Diagram

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.11.3 Block Diagram TRIG[2:0] ADST T1 A match signal T4 overflow event signal T4 A match event signal ADSEL[3:0] Start T4 B match event signal (Select one input pin T4 C match event signal of the assigned pins)
  • Page 180: Adc Operation

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.11.4 ADC Operation Align bit set “0” ADCO11 ADCO10 ADCO9 ADCO8 ADCO7 ADCO6 ADCO5 ADCO4 ADCO3 ADCO2 ADCO1 ADCO0 ADCDRH7 ADCDRH6 ADCDRH5 ADCDRH4 ADCDRH3 ADCDRH2 ADCDRH1 ADCDRH0 ADCDRL7 ADCDRL6 ADCDRL5 ADCDRL4 ADCDRH[7:0] ADCDRL[7:4] ADCDRL[3:0] bits are “0”...
  • Page 181: Register Map

    MC96F6432A ABOV Semiconductor Co., Ltd. SET ADCCRH Select ADC Clock and Data Align Bit. SET ADCCRL ADC enable & Select AN Input Channel. Converting START Start ADC Conversion. If Conversion is completed, AFLAG is set “1” and ADC AFLAG = 1? interrupt is occurred.
  • Page 182: Register Description For Adc

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.11.7 Register Description for ADC ADCDRH (A/D Converter Data High Register):9FH ADDM11 ADDM10 ADDM9 ADDM8 ADDM7 ADDM6 ADDM5 ADDM4 ADDL11 ADDL10 ADDL9 ADDL8 Initial value: xxH ADDM[11:4] MSB align, A/D Converter High Data (8-bit) ADDL[11:8]...
  • Page 183 MC96F6432A ABOV Semiconductor Co., Ltd. ADCCRL (A/D Converter Counter Low Register): 9CH STBY ADST REFSEL AFLAG ADSEL3 ADSEL2 ADSEL1 ADSEL0 Initial value: 00H STBY Control Operation of A/D (The ADC module is automatically disabled at stop mode) ADC module disable...
  • Page 184: Usi (Usart + Spi + I2C)

    11.12 USI (USART + SPI + I2C) 11.12.1 Overview The USI is an acronym of USART, SPI and I2C, MC96F6432A has two USI function blocks, USI0 and USI1 are absolutely same functionally. Each USI consists of USI control register1/2/3/4, USI status register 1/2, USI baud-rate...
  • Page 185: Usin Uart Mode

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.12.2 USIn UART Mode The universal synchronous and asynchronous serial receiver and transmitter (USART) is a highly flexible serial communication device. The main features are listed below. − Full Duplex Operation (Independent Serial Receive and Transmit Registers) −...
  • Page 186: Usin Uart Block Diagram

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.12.3 USIn UART Block Diagram Master SCKn Control USInMS[1:0] SCLK USInBD (fx: System clock) To interrupt block Baud Rate Generator DBLSn WAKEIEn RXCIEn Clock Sync Logic At Stop mode WAKEn Low level RXCn detector RXDn...
  • Page 187: Usin Clock Generation

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.12.4 USIn Clock Generation USInBD DBLSn SCLK (USInBD+1) Prescaling Up-Counter txclk SCLK MASTERn Sync Register USInMS[1:0] CPOLn SCKn rxclk Figure 11.58 Clock Generation Block Diagram (USIn) The clock generation logic generates the base clock for the transmitter and receiver. The USIn supports four modes of clock operation and those are normal asynchronous, double speed asynchronous, master synchronous and slave synchronous mode.
  • Page 188: Usin External Clock (Sckn)

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.12.5 USIn External Clock (SCKn) External clocking is used in the synchronous mode of operation. External clock input from the SCKn pin is sampled by a synchronization logic to remove meta-stability. The output from the synchronization logic must be passed through an edge detector before it is used by the transmitter and receiver.
  • Page 189: Usin Uart Data Format

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.12.7 USIn UART Data format A serial frame is defined to be one character of data bits with synchronization bits (start and stop bits) and optionally a parity bit for error detection. The USART supports all 30 combinations of the following as valid frame formats.
  • Page 190: Usin Uart Parity Bit

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.12.8 USIn UART Parity bit The parity bit is calculated by doing an exclusive-OR of all the data bits. If odd parity is used, the result of the exclusive-OR is inverted. The parity bit is located between St + bits and first stop bit of a serial frame.
  • Page 191: Usin Uart Parity Generator

    MC96F6432A ABOV Semiconductor Co., Ltd. USIn UART Parity Generator 11.12.9.3 The parity generator calculates the parity bit for the serial frame data to be sent. When parity bit is enabled (USInPM1=1), the transmitter control logic inserts the parity bit between the bits and the first stop bit of the frame to be sent.
  • Page 192: Usin Uart Receiver Flag And Interrupt

    ABOV Semiconductor Co., Ltd. MC96F6432A USIn UART Receiver Flag and Interrupt 11.12.10.2 The UART receiver has one flag that indicates the receiver state. The receive complete (RXCn)flag indicates whether there are unread data in the receive buffer. This flag is set when there is unread data in the receive buffer and cleared when the receive buffer is empty.
  • Page 193: Usin Asynchronous Data Reception

    MC96F6432A ABOV Semiconductor Co., Ltd. USIn Asynchronous Data Reception 11.12.10.5 To receive asynchronous data frame, the UART includes a clock and data recovery unit. The clock recovery logic is used for synchronizing the internally generated baud-rate clock to the incoming asynchronous serial frame on the RXDn pin.
  • Page 194 ABOV Semiconductor Co., Ltd. MC96F6432A When the receiver is enabled (RXEn=1), the clock recovery logic tries to find a high-to-low transition on the RXDn line, the start bit condition. After detecting high to low transition on RXDn line, the clock recovery logic uses samples 8, 9 and 10 for normal mode to decide if a valid start bit is received.
  • Page 195: Usin Spi Mode

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.12.11 USIn SPI Mode The USIn can be set to operate in industrial standard SPI compliant mode. The SPI mode has the following features. − Full Duplex, Three-wire synchronous data transfer − Mater and Slave Operation −...
  • Page 196 ABOV Semiconductor Co., Ltd. MC96F6432A SCKn (CPOLn=0) SCKn (CPOLn=1) SAMPLE MOSIn MSB First … BIT7 BIT6 BIT2 BIT1 BIT0 LSB First … BIT0 BIT1 BIT5 BIT6 BIT7 MISOn /SSn OUT (MASTER) /SSn IN (SLAVE) Figure 11.64 USIn SPI Clock Formats when CPHAn=0 When CPHAn=0, the slave begins to drive its MISOn output with the first data bit value when SSn goes to active low.
  • Page 197 MC96F6432A ABOV Semiconductor Co., Ltd. SCKn (CPOLn=0) SCKn (CPOLn=1) SAMPLE MOSIn … MSB First BIT7 BIT6 BIT2 BIT1 BIT0 … LSB First BIT0 BIT1 BIT5 BIT6 BIT7 MISOn /SSn OUT (MASTER) /SSn IN (SLAVE) Figure 11.65 USIn SPI Clock Formats when CPHAn=1 When CPHAn=1, the slave begins to drive its MISOn output when SSn goes active low, but the data is not defined until the first SCKn edge.
  • Page 198: Usin Spi Block Diagram

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.12.13 USIn SPI Block Diagram USInBD Control SCLK Baud Rate Generator (fx: System clock) MASTERn USInSSEN Edge Detector SCKn Control Controller FXCHn RXEn CPOLn CPHAn MISOn Data Receive Shift Register Rx Control Recovery (RXSR) RXCn...
  • Page 199: Usin I2C Mode

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.12.14 USIn I2C Mode The USIn can be set to operate in industrial standard serial communication protocols mode. The I2C mode uses 2 bus lines serial data line (SDAn) and serial clock line (SCLn) to exchange data. Because both SDAn and SCLn lines are open-drain output, each line needs pull-up resistor.
  • Page 200: Usin I2C Start / Repeated Start / Stop

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.12.16 USIn I2C Start / Repeated Start / Stop One master can issue a START (S) condition to notice other devices connected to the SCLn, SDAn lines that it will use the bus. A STOP (P) condition is generated by the master to release the bus lines so that other devices can use it.
  • Page 201: Usin I2C Acknowledge

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.12.18 USIn I2C Acknowledge The acknowledge related clock pulse is generated by the master. The transmitter releases the SDAn line (HIGH) during the acknowledge clock pulse. The receiver must pull down the SDAn line during the acknowledge clock pulse so that it remains stable LOW during the HIGH period of this clock pulse.
  • Page 202: Usin I2C Operation

    ABOV Semiconductor Co., Ltd. MC96F6432A Wait High Start High Counting Counting Fast Device SCLOUT High Counter Reset Slow Device SCLOUT SCLn Figure 11.71 Clock Synchronization during Arbitration Procedure (USIn) Arbitration Process Device 1 loses Device1 outputs not adapted Arbitration High...
  • Page 203: Usin I2C Master Transmitter

    MC96F6432A ABOV Semiconductor Co., Ltd. USIn I2C Master Transmitter 11.12.20.1 To operate I2C in master transmitter, follow the recommended steps below. Enable I2C by setting USInMS[1:0]bits in USInCR1 and USInEN bit in USInCR2. This provides main clock to the peripheral.
  • Page 204 ABOV Semiconductor Co., Ltd. MC96F6432A This is ACK signal processing stage for data packet transmitted by master. I2C holds the SCLn LOW. When I2C loses bus mastership while transmitting data arbitrating other masters, the MLOSTn bit in USInST2 is set.
  • Page 205: Usin I2C Master Receiver

    MC96F6432A ABOV Semiconductor Co., Ltd. USIn I2C Master Receiver 11.12.20.2 To operate I2C in master receiver, follow the recommended steps below. Enable I2C by setting USInMS[1:0]bits in USInCR1 and USInEN bit in USInCR2. This provides main clock to the peripheral.
  • Page 206 ABOV Semiconductor Co., Ltd. MC96F6432A 1-Byte of data is being received. This is ACK signal processing stage for data packet transmitted by slave. I2C holds the SCLn LOW. When 1- Byte of data is received completely, I2C generates TENDn interrupt.
  • Page 207: Usin I2C Slave Transmitter

    MC96F6432A ABOV Semiconductor Co., Ltd. USIn I2C Slave Transmitter 11.12.20.3 To operate I2C in slave transmitter, follow the recommended steps below. If the main operating clock (SCLK) of the system is slower than that of SCLn, load value 0x00 into USInSDHR to make SDAn change within one system clock period from the falling edge of SCLn.
  • Page 208: Usin I2C Slave Receiver

    ABOV Semiconductor Co., Ltd. MC96F6432A USIn I2C Slave Receiver 11.12.20.4 To operate I2C in slave receiver, follow the recommended steps below. If the main operating clock (SCLK) of the system is slower than that of SCLn, load value 0x00 into USInSDHR to make SDAn change within one system clock period from the falling edge of SCLn.
  • Page 209: Usin I2C Block Diagram

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.12.21 USIn I2C Block Diagram IICnIFR To interrupt block Slave Address Register USInSAR RXACKn, GCALLn, Interrupt IICnIE TENDn, STOPDn, Generator SSELn, MLOSTn, General Call And USInGCE BUSYn, TMODEn Address Detector Receive Shift Register SDAn USInDR, (Rx)
  • Page 210: Register Map

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.12.22 Register Map Name Address Direction Default Description USI0BD USI0 Baud Rate Generation Register USI0DR USI0 Data Register USI0SDHR USI0 SDA Hold Time Register USI0SCHR USI0 SCL High Period Register USI0SCLR USI0 SCL Low Period Register...
  • Page 211: Register Description For Usin

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.12.24 Register Description for USIn USInBD (USIn Baud- Rate Generation Register: For UART and SPI mode): E3H/F3H, n = 0, 1 USInBD7 USInBD6 USInBD5 USInBD4 USInBD3 USInBD2 USInBD1 USInBD0 Initial value: FFH USInBD[7:0] The value in this register is used to generate internal baud rate in asynchronous mode or to generate SCKn clock in SPI mode.
  • Page 212 ABOV Semiconductor Co., Ltd. MC96F6432A USInSDHR (USInSDA Hold Time Register: For I2C mode): E4H/F4H, n = 0, 1 USInSDHR7 USInSDHR6 USInSDHR5 USInSDHR4 USInSDHR3 USInSDHR2 USInSDHR1 USInSDHR0 Initial value: 01H USInSDHR[7:0] The register is used to control SDAn output timing from the falling edge of SCI in I2C mode.
  • Page 213 MC96F6432A ABOV Semiconductor Co., Ltd. USInSCLR (USInSCL Low Period Register: For I2C mode): E6H/F6H, n = 0, 1 USInSCLR7 USInSCLR6 USInSCLR5 USInSCLR4 USInSCLR3 USInSCLR2 USInSCLR1 USInSCLR0 Initial value: 3FH USInSCLR[7:0] This register defines the high period of SCLn when it operates in I2C master mode.
  • Page 214 ABOV Semiconductor Co., Ltd. MC96F6432A USInCR1 (USIn Control Register 1: For UART, SPI and I2C mode): D9H/E9H, n = 0, 1 USInS1 USInS0 USInMS1 USInMS0 USInPM1 USInPM0 USInS2 CPOLn ORDn CPHAn Initial value: 00H USInMS[1:0] Selects operation mode of USIn...
  • Page 215 MC96F6432A ABOV Semiconductor Co., Ltd. USInCR2 (USIn Control Register 2: For UART, SPI and I2C mode): DAH/EAH, n = 0, 1 DRIEn TXCIEn RXCIEn WAKEIEn TXEn RXEn USInEN DBLSn Initial value: 00H DRIEn Interrupt enable bit for data register empty (only UART and SPI mode).
  • Page 216 ABOV Semiconductor Co., Ltd. MC96F6432A USInCR3 (USIn Control Register 3: For UART, SPI and I2C mode): DBH/EBH, n = 0, 1 MASTERn LOOPSn DISSCKn USInSSEN FXCHn USInSB USInTX8 USInRX8 Initial value: 00H MASTERn Selects master or slave in SPI and synchronous mode operation and controls the direction of SCKn pin Slave mode operation (External clock for SCKn).
  • Page 217 MC96F6432A ABOV Semiconductor Co., Ltd. USI0CR4 (USIn Control Register 4: For I2C mode): DCH/ECH, n = 0, 1 – IICnIFR TXDLYENBn IICnIE ACKnEN IMASTERn STOPCn STARTCn – Initial value: 00H This is an interrupt flag bit for I2C mode. When an interrupt occurs, this bit becomes ‘1’.
  • Page 218 ABOV Semiconductor Co., Ltd. MC96F6432A USInST1 (USIn Status Register 1: For UART and SPI mode): E1H/F1H, n = 0, 1 DREn TXCn RXCn WAKEn USInRST DORn Initial value: 80H DREn The DREn flag indicates if the transmit buffer (USInDR) is ready to receive new data. If DREn is ‘1’, the buffer is empty and ready to be written.
  • Page 219 MC96F6432A ABOV Semiconductor Co., Ltd. USInST2 (USIn Status Register 2: For I2C mode): E2H/F2H, n = 0, 1 GCALLn TENDn STOPDn SSELn MLOSTn BUSYn TMODEn RXACKn Initial value: 00H GCALLn This bit has different meaning depending on whether I2C is master or slave. When I2C is a master, this bit represents whether it received AACK (address ACK) from slave.
  • Page 220: Baud Rate Setting (Example)

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.12.25 Baud Rate setting (example) fx=1.00MHz fx=1.8432MHz fx=2.00MHz Baud Rate (bps) USI0BD/USI1BD ERROR USI0BD/USI1BD ERROR USI0BD/USI1BD ERROR 2400 0.2% 0.0% 0.2% 4800 0.2% 0.0% 0.2% 9600 -7.0% 0.0% 0.2% 14.4k 8.5% 0.0% -3.5% 19.2k 8.5% 0.0%...
  • Page 221: Lcd Driver

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.13 LCD Driver 11.13.1 Overview The LCD driver is controlled by the LCD Control Register (LCDCRH/L). The LCLK[1:0] determines the frequency of COM signal scanning of each segment output. A RESET clears the LCD control register LCDCRH and LCDCRL values to logic ‘0’.
  • Page 222: Lcd Display Ram Organization

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.13.2 LCD Display RAM Organization Display data are stored to the display data area in the external data memory. The display data which stored to the display external data area (address 0000H-001AH) are read automatically and sent to the LCD driver by the hardware.
  • Page 223: Lcd Signal Waveform

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.13.3 LCD Signal Waveform COM0 SEG0 1 Frame COM1 VLC0 COM0 VLC2(VLC1, VLC3) SEG3 SEG1 SEG2 VLC0 COM1 VLC2(VLC1, VLC3) VLC0 VLC2(VLC1, VLC3) SEG0 VLC0 SEG1 VLC2(VLC1, VLC3) +VLC0 +VLC2(VLC1, VLC3) COM0-SEG0 -VLC2(VLC1, VLC3) -VLC0 Figure 11.75...
  • Page 224 ABOV Semiconductor Co., Ltd. MC96F6432A SEG1 SEG3 SEG2 COM0 1 Frame VLC0 VLC1 COM1 COM0 VLC2(VLC3) COM2 VLC0 VLC1 COM1 VLC2(VLC3) VLC0 VLC1 COM2 VLC2(VLC3) VLC0 VLC1 SEG1 VLC2(VLC3) VLC0 VLC1 SEG2 VLC2(VLC3) +VLC0 +VLC1 +VLC2(VLC3) COM0-SEG1 -VLC2(VLC3) -VLC1 -VLC0 Figure 11.76...
  • Page 225 MC96F6432A ABOV Semiconductor Co., Ltd. SEG3 SEG2 COM0 1 Frame COM1 VLC0 VLC1 COM2 COM0 VLC2(VLC3) COM3 VLC0 VLC1 COM1 VLC2(VLC3) VLC0 VLC1 COM2 VLC2(VLC3) VLC0 VLC1 SEG2 VLC2(VLC3) VLC0 VLC1 SEG3 VLC2(VLC3) +VLC0 +VLC1 +VLC2(VLC3) COM0-SEG2 -VLC2(VLC3) -VLC1 -VLC0 Figure 11.77...
  • Page 226 ABOV Semiconductor Co., Ltd. MC96F6432A COM0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7 COM1 COM2 COM3 COM4 1 Frame COM5 COM6 VLC0 COM7 VLC1 COM0 VLC2 VLC3 VLC0 VLC1 COM1 VLC2 VLC3...
  • Page 227: Lcd Voltage Dividing Resistor Connection

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.13.4 LCD Voltage Dividing Resistor Connection (1/ 2 Bias, 2xR (1/ 2 Bias, R VLCD VLCD VLC0 VLC1 VLC2 VLC3 VLC0 VLC1 VLC2 VLC3 DISP DISP LCTEN LCTEN VLC0 VLC1 VLC2 VLC3 VLC0 VLC1 VLC2...
  • Page 228 ABOV Semiconductor Co., Ltd. MC96F6432A (1/ 2 BIAS) VLCD DISP LCTEN VLC0 VLC1 VLC2 VLC3 R’ R’ (1/ 3 BIAS) (1/ 4 BIAS) VLCD VLCD DISP DISP LCTEN LCTEN VLC0 VLC1 VLC2 VLC3 VLC0 VLC1 VLC2 VLC3 R’ R’ R’...
  • Page 229: Block Diagram

    MC96F6432A ABOV Semiconductor Co., Ltd. 11.13.5 Block Diagram Port Latch SEG/Port Driver Display COM/Port Driver fLCD Timing LCDCRL Controller LCDCRH VLC0 LCD Bias VLC1 Voltage VLC2 Generator Contrast LCDCCR Controller VLC3 Figure 11.81 LCD Circuit Block Diagram 11.13.6 Register Map...
  • Page 230: Register Description For Lcd Driver

    ABOV Semiconductor Co., Ltd. MC96F6432A 11.13.8 Register Description for LCD Driver LCDCRH (LCD Driver Control High Register): 9AH – – – – – COMCHG LCDDR DISP – – – – – Initial value: 00H COMCHG Common Signal Output Port Change Control COM0 –...
  • Page 231 MC96F6432A ABOV Semiconductor Co., Ltd. LCDCRL (LCD Driver Control Low Register): 99H – IRSEL DBS3 DBS2 DBS1 DBS0 LCLK1 LCK0 – R./W Initial value: 00H IRSEL Internal LCD Bias Dividing Resistor Select = 60kΩ (R LCD1 = 120kΩ (R LCD2...
  • Page 232 ABOV Semiconductor Co., Ltd. MC96F6432A LCDCCR (LCD Driver Contrast Control Low Register): 9BH – – – LCTEN VLCD3 VLCD VLCD1 VLCD0 – – – Initial value: 00H LCTEN Control LCD Driver Contrast LCD Driver Contrast disable LCD Driver Contrast enable...
  • Page 233: Power Down Operation

    12.1 Overview The MC96F6432A has two power-down modes to minimize the power consumption of the device. In power down mode, power consumption is reduced considerably. The device provides three kinds of power saving functions, Main- IDLE, Sub-IDLE and STOP mode. In three modes, program is stopped.
  • Page 234: Idle Mode

    ABOV Semiconductor Co., Ltd. MC96F6432A 12.3 IDLE Mode The power control register is set to ‘01h’ to enter the IDLE Mode. In this mode, the internal oscillation circuits remain active. Oscillation continues and peripherals are operated normally but CPU stops. It is released by reset or interrupt.
  • Page 235: Stop Mode

    MC96F6432A ABOV Semiconductor Co., Ltd. 12.4 STOP Mode The power control register is set to ‘03H’ to enter the STOP Mode. In the stop mode, the selected oscillator, system clock and peripheral clock is stopped, but watch timer can be continued to operate with sub clock. With the clock frozen, all functions are stopped, but the on-chip RAM and control registers are held.
  • Page 236: Release Operation Of Stop Mode

    ABOV Semiconductor Co., Ltd. MC96F6432A 12.5 Release Operation of STOP Mode After STOP mode is released, the operation begins according to content of related interrupt register just before STOP mode start (Figure 12.3).If the global interrupt Enable Flag (IE.EA)is set to `1`, the STOP mode is released by the interrupt which each interrupt enable flag = `1` and the CPU jumps to the relevant interrupt service routine.
  • Page 237: Register Map

    MC96F6432A ABOV Semiconductor Co., Ltd. 12.6 Register Map Name Address Direction Default Description PCON Power Control Register Power Down Operation Register Map Table 12.2 12.7 Power Down Operation Register Description The power down operation register consists of the power control register (PCON).
  • Page 238: Reset

    Control Register Refer to the Peripheral Registers Reset State Table 13.1 13.2 Reset Source The MC96F6432A has five types of reset sources. The following is the reset sources. − External RESETB − Power ON RESET (POR) − WDT Overflow Reset (In the case of WDTEN = `1`) −...
  • Page 239: Reset Noise Canceller

    MC96F6432A ABOV Semiconductor Co., Ltd. 13.4 RESET Noise Canceller The Figure 13.2 is the Noise canceller time diagram for Noise cancel of Port RESET. It has the Noise cancel value is about 2us(@V =5V) to Port Reset input. t < T t <...
  • Page 240 ABOV Semiconductor Co., Ltd. MC96F6432A Counting for configure read start after POR is released Internal nPOR PAD RESETB “H” LVR_RESETB .. 27 28 BIT (for Configure) 00 01 02 03 BIT (for Reset) 1us X 256 X 28h = about 10ms...
  • Page 241 MC96F6432A ABOV Semiconductor Co., Ltd. Process Description Remarks ① - No Operation ② -1st POR level Detection -about 1.4V - (INT-OSC 8MHz/8)x256x28h Delay section (=10ms) -Slew Rate >= 0.05V/ms ③ -VDD input voltage must rise over than flash operating voltage for Configure option read -about 1.5V ~ 1.6V...
  • Page 242: External Resetb Input

    ABOV Semiconductor Co., Ltd. MC96F6432A 13.6 External RESETB Input The External RESETB is the input to a Schmitt trigger. If RESETB pin is held with low for at least 10us over within the operating voltage range and stable oscillation, it is applied and the internal state is initialized. After reset state becomes ‘1’, it needs the stabilization time with 16ms and after the stable state, the internal RESET becomes ‘1’.
  • Page 243: Brown Out Detector Processor

    Brown Out Detector Processor The MC96F6432A has an On-chip brown-out detection circuit (BOD) for monitoring the VDD level during operation by comparing it to a fixed trigger level. The trigger level for the BOD can be selected by LVRVS[3:0] bit to be 1.85V, 2.20V, 2.32V, 2.44V, 2.59V, 2.75V, 2.93V, 3.14V, 3.38V, 3.67V, 4.00V, 4.40V.
  • Page 244 ABOV Semiconductor Co., Ltd. MC96F6432A “H” “H” Internal nPOR “H” PAD RESETB LVR_RESETB ..27 28 BIT (for Config) 00 01 02 BIT (for Reset) 1us X 256 X 28h = about 10ms Config Read 1us X 4096 X 4h = about 16ms...
  • Page 245: Lvi Block Diagram

    MC96F6432A ABOV Semiconductor Co., Ltd. 13.8 LVI Block Diagram 2.20V 2.32V 2.44V 2.59V 2.75V Reference 2.93V LVI Circuit LVIF Voltage 3.14V Generator 3.38V 3.67V 4.00V 4.40V LVIEN LVILS[3:0] Figure 13.12 LVI Diagram 13.9 Register Map Name Address Direction Default Description...
  • Page 246: Register Description For Reset Operation

    ABOV Semiconductor Co., Ltd. MC96F6432A 13.11 Register Description for Reset Operation RSTFR (Reset Flag Register): E8H – – – – PORF EXTRF WDTRF LVRF – – – – Initial value: 80H Power-On Reset flag bit. The bit is reset by writing ‘0’ to this bit.
  • Page 247 MC96F6432A ABOV Semiconductor Co., Ltd. LVRCR (Low Voltage Reset Control Register): D8H – – LVRST LVRVS3 LVRVS2 LVRVS1 LVRVS0 LVREN – – Initial value: 00H LVRST LVR Enable when Stop Release Not effect at stop release LVR enable at stop release NOTE) When this bit is ‘1’, the LVREN bit is cleared to ‘0’...
  • Page 248 ABOV Semiconductor Co., Ltd. MC96F6432A LVICR (Low Voltage Indicator Control Register): 86H – – LVIF LVIEN LVILS3 LVILS2 LVILS1 LVILS0 – – Initial value: 00H LVIF Low Voltage Indicator Flag Bit No detection Detection LVIEN LVI Enable/Disable Disable Enable LVILS[3:0]...
  • Page 249: On-Chip Debug System(Mc96F6432 Only)

    Overview 14.1.1 Description MC96F6432A can not support On-chip debug(OCD). MC96F6432A isn’t equipped with on-chip debugger. We recommend to develop and debug program with MC96F6432. On-chip debug system of MC96F6432 can be used for programming the non-volatile memories and on-chip debugging. Detail descriptions for programming via the OCD interface can be found in the following chapter.
  • Page 250: Feature

    ABOV Semiconductor Co., Ltd. MC96F6432A 14.1.2 Feature • Two-wire external interface: 1-wire serial clock input, 1-wire bi-directional serial data bus • Debugger Access to: − All Internal Peripheral Units − Internal data RAM − Program Counter − Flash and Data EEPROM Memories •...
  • Page 251: Two-Pin External Interface

    MC96F6432A ABOV Semiconductor Co., Ltd. 14.2 Two-Pin External Interface 14.2.1 Basic Transmission Packet • 10-bit packet transmission using two-pin interface. • 1-packet consists of 8-bit data, 1-bit parity and 1-bit acknowledge. • Parity is even of ‘1’ for 8-bit data in transmitter.
  • Page 252: Packet Transmission Timing

    ABOV Semiconductor Co., Ltd. MC96F6432A 14.2.2 Packet Transmission Timing Data Transfer 14.2.2.1 DSDA acknowledgement acknowledgement signal from receiver signal from receiver DSCL START STOP Figure 14.3 Data Transfer on the Twin Bus Bit Transfer 14.2.2.2 DSDA DSCL data line change...
  • Page 253: Start And Stop Condition

    MC96F6432A ABOV Semiconductor Co., Ltd. Start and Stop Condition 14.2.2.3 DSDA DSDA DSCL DSCL START condition STOP condition Figure 14.5 Start and Stop Condition Acknowledge Bit 14.2.2.4 Data output By transmitter no acknowledge Data output By receiver acknowledge DSCL from...
  • Page 254: Connection Of Transmission

    ABOV Semiconductor Co., Ltd. MC96F6432A 14.2.3 Connection of Transmission Two-pin interface connection uses open-drain(wire-AND bidirectional I/O). pull resistors DSDA(Debugger Serial Data Line) DSCL(Debugger Serial Clock Line) DSCL DSDA DSCL DSDA DSDA DSDA DSCL DSCL Target Device(Slave) Host Machine(Master) Current source for DSCL to fast 0 to 1 transition in high speed mode Figure 14.8...
  • Page 255: Flash Memory

    15.1.1 Description MC96F6432A incorporates flash memory to which a program can be written, erased and overwritten while mounted on the board. The flash memory can be read by ‘MOVC’ instruction and it can be programmed in serial ISP mode or user program mode.
  • Page 256: Flash Program Rom Structure

    ABOV Semiconductor Co., Ltd. MC96F6432A 15.1.2 Flash Program ROM Structure 07FFFH Sector 511 07FC0H 07FC0H 07FBFH Sector 510 07F80H 07F80H 07F7FH Sector 509 07F40H 07F40H 07F3FH Sector 508 Flash Sector Address Address Sector 2 00080H 00080H 0007FH Sector 1 00040H...
  • Page 257: Register Map

    MC96F6432A ABOV Semiconductor Co., Ltd. 15.1.3 Register Map Name Address Direction Default Description FSADRH Flash Sector Address High Register FSADRM Flash Sector Address Middle Register FSADRL Flash Sector Address Low Register FIDR Flash Identification Register FMCR Flash Mode Control Register Flash Memory Register Map Table 15.1...
  • Page 258: Register Description For Flash

    ABOV Semiconductor Co., Ltd. MC96F6432A 15.1.5 Register Description for Flash FSADRH (Flash Sector Address High Register): FAH – – – – FSADRH3 FSADRH 2 FSADRH1 FSADRH0 – – – – Initial value: 00H FSADRH[3:0] Flash Sector Address High FSADRM (Flash Sector Address Middle Register): FBH...
  • Page 259 MC96F6432A ABOV Semiconductor Co., Ltd. FMCR (Flash Mode Control Register): FEH – – – – FMBUSY FMCR2 FMCR1 FMCR0 – – – – Initial value: 00H FMBUSY Flash Mode Busy Bit. This bit will be used for only debugger. No effect when “1” is written...
  • Page 260: Serial In-System Program (Isp) Mode

    15.1.7 Protection Area (User program mode) MC96F6432A can program its own flash memory (protection area). The protection area can not be erased or programmed. The protection areas are available only when the PAEN bit is cleared to ‘0’, that is, enable protection area at the configure option 2 if it is needed.
  • Page 261: Erase Mode

    MC96F6432A ABOV Semiconductor Co., Ltd. 15.1.8 Erase Mode The sector erase program procedure in user program mode Page buffer clear (FMCR=0x01) Write ‘0’ to page buffer Set flash sector address register (FSADRH/FSADRM/FSADRL). Set flash identification register (FIDR). (Note) Check the UserID for to prevent the invalid work Set flash mode control register (FMCR).
  • Page 262: Write Mode

    ABOV Semiconductor Co., Ltd. MC96F6432A 15.1.9 Write Mode The sector Write program procedure in user program mode Page buffer clear (FMCR=0x01) Write data to page buffer Set flash sector address register (FSADRH/FSADRM/FSADRL). Set flash identification register (FIDR). (Note1) Check the UserID for to prevent the invalid work Set flash mode control register (FMCR).
  • Page 263 MC96F6432A ABOV Semiconductor Co., Ltd. The Byte Write program procedure in user program mode Page buffer clear (FMCR=0x01) Write data to page buffer Set flash sector address register (FSADRH/FSADRM/FSADRL). Set flash identification register (FIDR). (Note1) Check the UserID for to prevent the invalid work Set flash mode control register (FMCR).
  • Page 264: Protection For Invalid Erase/Write

    ABOV Semiconductor Co., Ltd. MC96F6432A 15.1.10 Protection for Invalid Erase/Write It should be taken care to the flash erase/write programming in code. You must make preparations for invalid jump to the flash erase/write code by malfunction, noise and power off.
  • Page 265 MC96F6432A ABOV Semiconductor Co., Ltd. The flash sector address (FSADRH/FSADRM/FSADRL) should always keep the address of the flash which is used for data area. For example, The FSADRH/FSADRM is always 0x00/0x7f” if 0x7f00 to 0x7fff is used for data. Overview of main...
  • Page 266: Flow Of Protection For Invalid Erase/Write

    ABOV Semiconductor Co., Ltd. MC96F6432A Flow of Protection for Invalid Erase/Write 15.1.10.1 Start Work1 Decide to write/erase Set Flags on flash Work2 Match Check the flag for Write UserID1/2/3 UserID Work3 Match Check the UserID for Write/Erase Flash write/erase flash...
  • Page 267: Read Mode

    MC96F6432A ABOV Semiconductor Co., Ltd. 15.1.11 Read Mode The Reading program procedure in user program mode Load receive data from flash memory on MOVC instruction by indirectly addressing mode. Program Tip – reading A,#0 DPH,#0x7F DPL,#0x40 ;flash memory address MOVC A,@A+DPTR ;read data from flash memory...
  • Page 268: Configure Option

    ABOV Semiconductor Co., Ltd. MC96F6432A Configure Option 16.1 Configure Option Control The data for configure option should be written in the configure option area (003EH – 003FH) by programmer (Writer tools). CONFIGURE OPTION 2 : ROM Address 003FH – –...
  • Page 269: Appendix

    MC96F6432A ABOV Semiconductor Co., Ltd. APPENDIX 17.1 Instruction Table Instructions are either 1, 2 or 3 bytes long as listed in the ‘Bytes’ column below. Each instruction takes either 1, 2 or 4 machine cycles to execute as listed in the following table. 1 machine cycle comprises 2 system clock cycles.
  • Page 270 ABOV Semiconductor Co., Ltd. MC96F6432A LOGICAL Mnemonic Description Bytes Cycles Hex code ANL A, Rn AND register to A 58-5F ANL A, dir AND direct byte to A ANL A, @Ri AND indirect memory to A 56-57 ANL A, #data...
  • Page 271 MC96F6432A ABOV Semiconductor Co., Ltd. DATA TRANSFER Mnemonic Description Bytes Cycles Hex code MOV A, Rn Move register to A E8-EF MOV A, dir Move direct byte to A MOV A, @Ri Move indirect memory to A E6-E7 MOV A, #data...
  • Page 272 ABOV Semiconductor Co., Ltd. MC96F6432A BRANCHING Mnemonic Description Bytes Cycles Hex code ACALL addr 11 Absolute jump to subroutine 11→F1 LCALL addr 16 Long jump to subroutine Return from subroutine RETI Return from interrupt AJMP addr 11 Absolute jump unconditional 01→E1...
  • Page 273 MC96F6432A ABOV Semiconductor Co., Ltd. 17.2 Flash Protection for Invalid Erase/Write  Overview This is example to prevent changing code or data in flash by abnormal operation(noise, unstable power, malfunction, etc…).  How to protect the flash • Divide into decision and execution to Erase/Write in flash.
  • Page 274 ABOV Semiconductor Co., Ltd. MC96F6432A  Flowchart Start Initial ① Set LVR/LVI more than 2.0V Start Main Loop Working ③ Write Flash? Set User_ID1 ② Working ③ Check User_ID1? Set User_ID2 Working Check User_ID2? Set User_ID3 ③ Working Write Flash Set FSADDRH/M/L ④...
  • Page 275 Initialize User_ID1/2/3 Set Flash Sector Address to Dummy Address • Sample Source Refer to the ABOV homepage. It is created based on the MC97F2664. Each product should be modified according to the Page Buffer Size and Flash Size  Etc •...
  • Page 276: Table Of Contents

    ABOV Semiconductor Co., Ltd. MC96F6432A Table of contents Revision history ................................2 Overview ................................... 3 Description ................................3 Features ................................4 Development tools .............................. 5 1.3.1 Compiler ..............................5 1.3.2 OCD(On-chip debugger) emulator and debugger ..................5 1.3.3 Programmer ..............................7 MTP programming ..............................
  • Page 277 MC96F6432A ABOV Semiconductor Co., Ltd. I/O Ports .................................. 62 I/O Ports ................................62 Port Register ..............................62 9.2.1 Data Register (Px) ............................. 62 9.2.2 Direction Register (PxIO) .......................... 62 9.2.3 Pull-up Resistor Selection Register (PxPU) ....................62 9.2.4 Open-drain Selection Register (PxOD) ..................... 62 9.2.5...
  • Page 278 ABOV Semiconductor Co., Ltd. MC96F6432A 11.2.3 Register Map ............................103 11.2.4 Basic Interval Timer Register Description ....................104 11.2.5 Register Description for Basic Interval Timer ..................104 11.3 Watch Dog Timer ............................105 11.3.1 Overview ..............................105 11.3.2 WDT Interrupt Timing Waveform ......................105 11.3.3...
  • Page 279 MC96F6432A ABOV Semiconductor Co., Ltd. 11.9.5 Register Description for Buzzer Driver ....................171 11.10 SPI 2 ................................172 11.10.1 Overview .............................. 172 11.10.2 Block Diagram ............................172 11.10.3 Data Transmit / Receive Operation ...................... 173 11.10.4 SS2 pin function ........................... 173 11.10.5...
  • Page 280 ABOV Semiconductor Co., Ltd. MC96F6432A 11.13.5 Block Diagram ............................229 11.13.6 Register Map ............................229 11.13.7 LCD Driver Register Description ......................229 11.13.8 Register Description for LCD Driver ....................230 Power Down Operation ............................ 233 12.1 Overview ................................. 233 12.2 Peripheral Operation in IDLE/STOP Mode .....................
  • Page 281 MC96F6432A ABOV Semiconductor Co., Ltd. 17.1 Instruction Table .............................. 269 17.2 Flash Protection for Invalid Erase/Write ......................273 Table of contents ................................. 276...

This manual is also suitable for:

Mc96f6332a

Table of Contents
