REVO C
3PH from 30A to 40A

8.1 Access to L1-L2-L3 and T1-T2-T3 terminal Screw

1. Open fuse holder by pulling the frontal cover
2. Fix the wire on Ln
4. Close the cover by pressing
3. Fix the wire on Tn
Repeat for each Phase
