REVO C
3PH from 30A to 40A
3

Quick Start

Attention: this procedure must be carried out by skilled people only.
If your REVO C code is in line with what you really need, then the main configuration is already done by
Producer and you just need to do the following steps:
1.
Verify REVO C current sizing. Be sure that:
• the load current is equal or less than the nominal one of REVO C
• the main voltage is equal or less than the nominal voltage of REVO C
2.
Verify the Installation
3.
Verify the Wiring:
• all auxiliary connections must be done in line with wirings on this manual
• verify that there isn't a short circuit on the load
4.
Supply the Unit
5.
Go in the Operator menu
Set the parameters Operative Load Voltage and Nominal Current of the load using the frontal keypad
or Thyristor configurator software.
The Unit is ready to work
The auxiliary voltage supply of the REVO C unit must be synchronized with load voltage power supply.
If the Auxiliary Voltage (written on the identification label) is different from Supply Voltage (to the load), use an
external transformer.
IMPORTANT!
Starting Strategy (Enable):
1: Feed the unit with L1-L2-L3 power voltage supply
2: Feed the auxiliary supply
3: Close the Enable contact to start with the regulation
If your REVO C code is NOT in line with what you really need, use the enclosed configurator software tool
to set-up the unit. Install the software on your PC, select REVO C and click on test unit changing what
you need.
