FortiSwitch-5003 module
Inserting a FortiSwitch-5003 module into a chassis
FortiGate-5000 Series Quick Guide
01-00000-0294-20060315
The FortiSwitch-5003 module left extraction lever contacts to a hidden power
switch. The module must be fully installed in a chassis slot and this extraction
lever must be closed and locked for the FortiSwitch-5003 module to receive power
and operate normally. If the FortiSwitch-5003 module is not receiving power, the
Hot Swap LED glows blue and all other LEDs remain off.
Figure 28: FortiSwitch-5003 module mounting components
Closed
Alignment Pin
Mounting
Knot
Extraction
Lever
Open
Alignment Pin
Mounting
Knot
Extraction
Switch
Lever
Contact
Table 14: FortiSwitch-5003 normal operating LEDs
LED
State
+
Green
Off
+
System
Green
Console
Network
Off unless FortiGate-5000 series modules are operating in HA mode.
activity LEDs
0-15
OK
Green
Inserting a FortiSwitch-5003 module into a chassis
Power
Switch
35
