Changing jumper settings
Changing jumper settings
26
Table 5: FortiGate-5001FA2 module LEDs
LED State Description
STA Green Normal operation.
Red The FortiGate-5001FA2 is booting or a fault condition exists.
IPM Blue The FortiGate-5001FA2 is ready to be hot-swapped (removed
from the chassis).
Flashing The FortiGate-5001FA2 is changing from hot swap to running
Blue mode or from running mode to hot swap.
Off Normal operation. The FortiGate-5001FA2 module is in
contact with the chassis backplane.
1, 2, 3, 4 Green The correct cable is connected to the gigabit SPF interface.
Flashing Network activity at the gigabit SPF interface.
5, 6, 7, 8 Green The correct cable is connected to the copper 1000Base-T
gigabit interface and the connected equipment has power.
Flashing Network activity at this interface.
Amber The interface is connected at 1000 Mbps.
Table 6 lists and describes the FortiGate-5001FA2 connectors.
Table 6: FortiGate-5001FA2 connectors
Connector Type Speed
1 and 2 LC SFP 1000Base-SX
3 and 4 LC SFP 1000Base-SX
5, 6, 7, 8 RJ-45 1000Base-T
CONSOLE DB-9 9600 bps
USB USB
The JP3 jumper on the FortiGate-5001FA2 module is factory set by Fortinet into
one of two positions (see Figure 23 on page
• For a FortiGate-5140 or FortiGate-5050 chassis, the jumper connects pins 2
and 3
• For a FortiGate-5020 chassis, the jumper connects pins 1 and 2
The jumper must connect pins 2 and 3 if the chassis contains a shelf manager.
Both the FortiGate-5140 and the FortiGate-5050 contain shelf managers, and the
FortiGate-5020 does not.
If the JP3 jumper settings are incorrect, when you insert the FortiGate-5001FA2
module into a chassis the module may not start up or may not be able to
communicate with the chassis shelf manager.
FortiGate-5001FA2 security system
Protocol Description
Ethernet Two gigabit SFP interfaces that can
accept fiber or copper gigabit
transceivers.
Ethernet Two gigabit SFP interfaces that can
accept fiber or copper gigabit
transceivers.
Ethernet Copper gigabit connection to
10/100/1000Base-T copper networks.
RS-232 Serial connection to the command line
serial interface.
USB key firmware updates and
configuration backup (FortiOS v3.0).
27):
