Connecting the FortiGate-5140 chassis to AC power using the FortiGate-5053 power converter tray
Connecting a FortiGate-5140 chassis to the FortiGate-5053 power converter
tray
12
To use a FortiGate-5053 power converter tray with the FortiGate-5140 chassis
you need to make DC power connections between the FortiGate-5140 chassis
and the FortiGate-5053 power converter tray. You also need to the connect the
FortiGate-5140 chassis to Data Center ground.
Figure 8: Connect a FortiGate-5140 PEM to a FortiGate-5053 power converter tray
(RTN)
(Red)
-48V/-60 VDC Black to
FortiGate-5053
-48/-58 VDC
-48V/-60 VDC nom
4
3
2
4
3
2
-48V/-60 VDC
terminal strip
connectors
1, 2, 3, 4
24 VAC 1
V-
V-
(Black)
RTN Red to
FortiGate-5053
RTN
RTN
1
4
3
2
1
1
4
3
2
1
RTN (positive)
terminal strip
connectors
1, 2, 3, 4
FortiGate-5000 Series Quick Guide
FortiGate-5140 chassis
2
3
AC in
01-00000-0294-20060315
