FortiGate-5002FB2 security system
Inserting a FortiGate-5002FB2 module into a chassis
FortiGate-5000 Series Quick Guide
01-00000-0294-20060315
The FortiGate-5002FB2 module left extraction lever contacts to a hidden power
switch. The module must be fully installed in a chassis slot and this extraction
lever must be closed and locked for the FortiGate-5002FB2 module to receive
power and operate normally. If the FortiGate-5002FB2 module is not receiving
power, the IPM LED glows blue and all other LEDs remain off.
Figure 26: FortiGate-5002FB2 module mounting components
Closed
Alignment Pin
Mounting
Knot
Extraction Lever
Extraction
Lever
Open
Alignment Pin
Mounting
Knot
Extraction Lever
Extraction
Switch
Lever
Contact
Table 11: FortiGate-5002FB2 normal operating LEDs
LED
State
STATUS
Green
PWR
Green
IPM
Off
Inserting a FortiGate-5002FB2 module into a chassis
Lock
Power
Switch
Lock
31
