Changing jumper settings

Changing jumper settings
22
Table 1: FortiGate-5001SX LEDs (Continued)
LED State Description
ACC Off or The ACC LED flashes red when the FortiGate-5001SX module
Flashing access the FortiOS flash disk.
red
STA Green Normal operation.
Red The FortiGate-5001SX is starting or a fault condition exists.
IPM Blue The FortiGate-5001SX is ready to be hot-swapped (removed
from the chassis).
Flashing The FortiGate-5001SX is changing from hot swap to running
Blue mode or from running mode to hot swap.
Off Normal operation. The FortiGate-5001SX module is in contact
with the chassis backplane.
1, 2, 3, 4 Green The correct cable is connected to the gigabit SPF interface.
Flashing Network activity at the gigabit SPF interface.
5, 6, 7, 8 Green The correct cable is connected to the copper 1000Base-T
gigabit interface and the connected equipment has power.
Flashing Network activity at this interface.
Amber The interface is connected at 1000 Mbps.
Table 2 lists and describes the FortiGate-5001SX connectors.
Table 2: FortiGate-5001SX connectors
Connector Type Speed
1, 2, 3, 4 LC 1000Base-SX Ethernet
SFP
5, 6, 7, 8 RJ-45 1000Base-T
CONSOLE DB-9 9600 bps
USB USB
The JP3 jumper on the FortiGate-5001SX module is factory set by Fortinet into
one of two positions (see Figure 20 on page
• For a FortiGate-5140 or FortiGate-5050 chassis, the jumper connects pins 2
and 3
• For a FortiGate-5020 chassis, the jumper connects pins 1 and 2
The jumper must connect pins 2 and 3 if the chassis contains a shelf manager.
Both the FortiGate-5140 and the FortiGate-5050 contain shelf managers, and the
FortiGate-5020 does not.
If the JP3 jumper settings are incorrect, when you insert the FortiGate-5001SX
module into a chassis the module may not start up or may not be able to
communicate with the chassis shelf manager.
FortiGate-5001SX security system
Protocol Description
Four gigabit SFP interfaces that can
accept fiber or copper gigabit
transceivers.
Ethernet Copper gigabit connection to
10/100/1000Base-T copper networks.
RS-232 serial Serial connection to the command line
interface.
USB key firmware updates and
configuration backup (FortiOS v3.0).
23):
