FortiGate-5050 chassis
Connecting a FortiGate-5050 chassis to the FortiGate-5053 power converter
tray
FortiGate-5000 Series Quick Guide
01-00000-0294-20060315
Connecting the FortiGate-5050 chassis to AC power using the FortiGate-5053 power converter tray
To use a FortiGate-5053 power converter tray with the FortiGate-5050 chassis
you need to make DC power connections between the FortiGate-5050 chassis
and the FortiGate-5053 power converter tray. You also need to the connect the
FortiGate-5050 chassis to Data Center ground.
Figure 16: Connecting a FortiGate-5050 power input connector to a FortiGate-5053
power converter tray
(RTN)
(red)
RTN red to
FortiGate-5053
RTN
DC VOLTAGE RANGE
Power wire
fixture
Positive (RTN) (red)
24 VAC 1
V-
V-
(black)
-48V/-58 VDC black to
FortiGate-5053
-48/-58 VDC
INPUT A
-48V TO -58V
RTN (-DC IN)
25
AMP
-48V/-58V
-DC in
(black)
2 3
AC in
