FortiGate-5050 chassis
Connecting the FortiGate-5050 chassis to AC power using the
FortiGate-5053 power converter tray
FortiGate-5000 Series Quick Guide
01-00000-0294-20060315
Connecting the FortiGate-5050 chassis to AC power using the FortiGate-5053 power converter tray
Figure 12: Connecting a FortiGate-5050 chassis to Data Center ground
Data Center
ground
connector
If Data Center DC power is not available, you can use the FortiGate-5053 power
converter tray with FortiGate-5020/5050 power supplies (shown in
convert AC power to DC power. The FortiGate-5053 power converter tray and the
power supplies are not supplied with the FortiGate-5050 chassis and must be
purchased separately. (FortiGate-5020/5050 power supplies are also used to
provide power to a FortiGate-5020 chassis.)
The front panel of the FortiGate-5053 power converter tray (shown in
provides access to the FortiGate-5020/5050 power supplies.
Figure 13: Front panel of the FortiGate-5053 power converter tray with one power
supply removed
Slot 3
The back panel of the FortiGate-5053 (shown in
power connector terminal consisting of a RTN connector and a -48VDC
connector. The -48VDC connector is labelled -V. The RTN connector is not
labelled.
Figure 14: Back panel of the FortiGate-5053 power converter tray
Positive
(RTN)
(red)
FortiGate-5050
Ground
connector
Slot 2
Figure
24 VAC 1
V-
V-
-48V/-58 VDC
(black)
DC out
Figure 13) to
Figure 13)
Slot 1
14) includes one DC
2 3
AC in
