Table 12: FortiSwitch-5003 module LEDs (Continued)
LED State Description
Yellow Link/Activity mode - Port is not forwarding packets.
Link/Speed mode - Indicates 1000 Mbps connection
Network
activity Green Link/Activity mode - Blinking LED indicates network traffic.
LEDs Link/Speed mode - Indicates 100 Mbps connection.
0-15
Off Link/Activity mode - No link.
Link/Speed mode - Indicates 10 Mbps connection.
Yellow Link/Activity mode - Port is not forwarding packets.
Link/Speed mode - Indicates 1000 Mbps connection
Green Link/Activity mode - Blinking LED indicates network traffic.
E1
Link/Speed mode - Indicates 100 Mbps connection.
Off Link/Activity mode - No link.
Link/Speed mode - Indicates 10 Mbps connection.
Yellow Link/Activity mode - Port is not forwarding packets.
Link/Speed mode - Indicates 1000 Mbps connection
Green Link/Activity mode - Blinking LED indicates network traffic.
E0
Link/Speed mode - Indicates 100 Mbps connection.
Off Link/Activity mode - No link.
Link/Speed mode - Indicates 10 Mbps connection.
OK Green Initialization completed successfully.
EXT FLT Yellow Cannot establish a link to a configured port or another
connection problem external to the adaptor.
INT FLT Yellow Failure of internal tests. Off during power up.
Hot Swap Blue Light on indicates the switch is ready to remove. During a hot
swap, LED is on. LED turns off when the switch is correctly
installed.
Reset Press and hold Reset for three seconds to restart the switch.
LED Mode Change the port LED display function from Link/Activity mode
to Link/Speed mode.
Table 13 lists and describes the FortiSwitch-5003 connectors.
Table 13: FortiGate-5003 connectors
Connector Type Speed
ETH0 RJ-45 100Base-T Ethernet
CONSOLE RJ-45 9600 bps
ZRE0, RJ-45 1000Base-T Ethernet
ZRE1,
ZRE2
Protocol Description
Ethernet out of band management
connection.
RS-232 Serial connection to the command line
serial interface.
Redundant connections to another
FortiGate chassis.
