Atdec AWMS-2-D13-C Installation Manual page 7

1. Attach Post to fixing (fixing sold seperately)
1.1 Follow the installation
guide provided with your
fixing to attach it to the post
and fit it to the worksurface.
2. Check post placement & arm positions
2.1 Do not mount a monitor arm on the rear channel
of a post when the post is fixed to the desk using an
F Clamp, Heavy Duty F Clamp, or C Clamp.
F Clamp Heavy Duty
F Clamp
AWM-FF AWM-FH
3. Cable cover position and post cap
3.1 To reposition the cable cover, pull it
straight up and out of the post and insert
it into any of the available channels
Note: The cable cover shown does not
come with all posts
4. Cable clips and cover
4.1 Push the cable down into
the cable clip.
Note: Cable clips do not come with all
posts. Additional clips sold separately.
No portion of this document or any artwork contained herein should be reproduced in any way without
the express written consent of Atdec Pty Ltd. Due to continuing product development, the manufacturer
reserves the right to alter specifications without notice. ©20180518E
atdec.com | atdec.co.uk | atdec.com.au
AWM Fixing options
FB
Bolt Through
FB
Bolt
Kit
Bolt
Through AWM-FB
Through
Kit
Kit
C Clamp
AWM-FC
3.2 Optional cable cover positions
Cable Cover
4.2 Insert one side of the
cable clip into the channel on
the post assembly, then push
in the other side.
FF FH
F Clamp Heavy Duty
FF FH
HD F Clamp
F Clamp
F Clamp
F Clamp HD F Clamp
AWM-FF AWM-FH
4.3 Loop cable and insert
into cable cover.
FC AC-GC
C Clamp Grommet
FC AC-GC
Grommet
C Clamp
C Clamp Grommet
AWM-FC
Clamp
Rear of Mounting Rear of Mounting
Surface Surface
Rear of Mounting
Surface
3.3 Fit post cap onto the top of the post
Allen Key
Post Cap
Note: An allen key
may be stored in
the Post Cap.
Post
4.4 Feed remaining cable
into the cover.
AWMS-2-D13-C | Page 7 of 13
AWM-P Page 2 of 2
Clamp
Clamp AC-GC
Rear of Mounting
Surface
