Atdec AWMS-2-D13-C Installation Manual page 3

1. C Clamp overview
1.1 Default - This is the "out of the box" configuration
MIN THICKNESS - 25mm ( 1")
MAX THICKNESS - 33mm ( 1
2. Re-configure Clamp
2.1 Slide pad off
3. Post mount configuration
3.1 Attach plate to post
3.4 Check the set screws are mounted in position. Also check the
desk clamp bracket is positioned tight up against the mounting
surface edge
M8 x 16mm
Set Screw
5 / ")
16
2.3 Invert pad
3.2 Place in desired location
Fasteners
supplied
with post
!
Tighten
Firmly
Desk Clamp
Bracket
Mounting
surface
Pad
1.2 Inverted - The C Clamp can be reconfigured for thicker surfaces
MIN THICKNESS - 18mm (
MAX THICKNESS - 25.8mm (1")
2.3 Slide pad back on
3.3 Slide the C Clamp bracket over the plate
and position screw tips in the indents on
the base plate
Note: You may need to un-screw the set screws
out of the plate using the allen key
3.5 Tighten the set screws firmly and evenly on both sides of the
desk clamp bracket.
11 / ")
16
