Atdec AWMS-2-D13-C Installation Manual page 10

Dynamic Arm
Dynamic Arm
COMPONENT CHECKLIST
A
A
Dynamic
Dynamic
Monitor Arm
Monitor Arm
(x1)
(x1)
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! This product is compatible with Atdec AWM Series products.
! The Dynamic Arm (AWM-AD) requires a Channel Clamp (AWM-LC, sold separately) for installation on an AWM Post.
! The Dynamic Arm (AWM-AD) requires a Desk Base (AWM-LB, sold separately) for installation directly onto an AWM fixing.
! The manufacturer accepts no responsibility for incorrect installation.
C
C
Screw
Screw
M4x25mm
M4x25mm
(x4)
(x4)
B F
B F
VESA Spacer
VESA Spacer
Head (x4)
head (x4)
(x1)
(x1)
D E
D E
Screw Screw
Screw Screw
M4x16mm M4x12mm
M4x16mm M4x12mm
(x4) (x4)
(x4) (x4)
G H
G H
Security 4mm
Security 4mm
Screw Allen Key
screw allen key
(x1) (x1)
(x1) (x1)
AWM-AD
Installation Guide
AWM-AD
REQUIRED TOOLS
• Phillips Head Screwdriver
WEIGHT RANGE
0 - 9kg
(0 - 20lbs)
AWMS-2-D13-C | Page 10 of 13
AWM-AD Page 1 of 4
