Dynamic Monitor Arm F clamp
COMPONENT CHECKLIST
AWM-FF
FF
F Clamp
(x1)
F Clamp
CONTENTS
F Clamp
Page 2
Arm Base
Page 3
Dynamic Arm
Page 4
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! Do not remove/ throw away the plastic sleeve on arm base and arm links.
! The manufacturer accepts no responsibility for incorrect installation.
! This product is compatible with Atdec AWM Series products.
! Product must only be installed on a solid work surface capable of supporting the weight of all equipment being mounted.
! Curved monitors, deep devices (such as all-in-one PCs), VESA mounted accessories (such as mini PC brackets and mounts),
and offset VESA locations exert additional leverage that can exceed the capacity of the mount even though the monitor
weight may be within the stated range. Please contact Atdec if you would like further information.
AWM-LB
FH
Arm Base
(x1)
HD F Clamp
AWM-FF
Component Checklist + Clamp Installation
AWM-LB
Component Checklist + Base Installation
AWM-AD
Component Checklist + Arm Installation
AWM-AD
FC
Dynamic Arm
(x1)
C Clamp
Installation Guide
AWMS-DB-F
REQUIRED TOOLS
AC-GC
• Phillips Head Screwdriver
Grommet
Clamp
AWMS-DB-F Page 1 of 6
