Atdec AWMS-2-D13-C Installation Manual page 2

2 x dynamic arms on 135 post with c-clamp

Advertisement

C-Clamp
C Clamp
COMPONENT CHECKLIST
A
A
C Clamp Bracket
C Clamp Bracket
(x1)
(x1)
B
B
C Clamp Plate
(x1)
C Clamp Plate
(x1)
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! This product is compatible with Atdec modular (AWM) products.
! The manufacturer accepts no responsibility for incorrect installation.
C
C
Cover for Post
Cover for Post
(x1)
(x1)
D
D
Cover for Base
(x1)
Cover for Base
(x1)
Installation Guide
REQUIRED TOOLS
• All tools supplied
E
E
4mm Allen key
4mm
(x1)
Allen key
(x1)
F
F
5mm
5mm Allen key
Allen key
(x1)
(x1)
AWM-FC
AWM-FC
AWMS-2-D13-C | Page 2 of 13
AWM-FC Page 1 of 4
