AL800ADA Power Supply Board*

Terminal
Function/Description
Legend
L, G, N Connect 120VAC to these terminals: L to hot, N to neutral .
– DC + 24VDC @ 8A in alarm non power-limited output .
Form "C" dry contacts used to instantaneously signal the loss AC to local annunciation devices,
AC FAIL
with AC present terminals marked NO and C are open, NC and C are closed . When loss of AC
NO, C, NC
occurs terminals marked NO and C are closed, NC and C are open .
Form "C" dry contacts used to instantaneously signal the loss AC to local annunciation devices,
AC LOCAL
with AC present terminals marked NO and C are open, NC and C are closed . When loss of AC
NC, NO, C
occurs terminals marked NO and C are closed, NC and C are open .
Form "C" dry contacts used to signal low battery voltage or loss of battery voltage .
BAT FAIL
Under normal conditions terminals marked NO and C are open, NC and C are closed . During a
NO, C, NC
trouble condition terminals marked NO and C are closed, and NC and C are open (Fig. 2, pg. 9).
+ BAT – Stand-by battery input (leads provided) (Fig. 2, pg. 9).
*Power Board Parameter Specifications:
• AC Fail condition will report approximately 30 seconds after loss of AC . To delay report for 2 .5 to 3 hours
cut jumper AC DELAY on the Power Supply Board (AC trouble output delay option) . If this mode is
selected the Power Supply Board must be reset by removing all power to it for 30 seconds .
• Low battery condition will report at approximately 21VDC .
• Battery presence detection will report within 180 seconds after battery remains undetected (missing or
removed) . A restored battery will report within 30 seconds .
AL800ADA - Power Supply Board
Red (DC) Green (AC)
ON ON
ON OFF
OFF ON
OFF OFF
AL800LGK9E - Logic Board
LED OFF
Output 1 Normal
Output 2 Normal
Output 3 Normal
Output 4 Normal
Input 1 Normal
Input 2 Normal
Fault Normal
* Indicates current trouble condition . When trouble (open, short or ground) occurs on a specific output, the
corresponding red output LED, [OUT1-OUT4] will blink . The corresponding green input LED will
blink as well . Loop trouble will report within 30 seconds .
** Indicates trouble condition memory . When a trouble condition restores, the units red output LED,
[OUT1-OUT4] will blink with a shorter and distinctly a different duration .
The green input LEDs will be off (normal condition) .
To reset the memory depress the reset button (Fig. 2c, pg. 9) . The LED(s) will extinguish .
Note: If indicating circuits have been restored, memory reset is not required for normal operation of the unit .
AL802ULADA
Terminal Identification Table:

LED Diagnostics:

Power Supply Status
Normal operating condition .
Loss of AC . Stand-by battery is supplying power .
No DC output .
Loss of AC . Discharged or no stand-by battery . No DC output .
ON
Alarm Condition
Alarm Condition
Alarm Condition
Alarm Condition
Alarm Condition
Alarm Condition
Alarm Condition
BLINK (LONG)*
Trouble Condition
Trouble Condition
Trouble Condition
Trouble Condition
Trouble Condition
Trouble Condition
–
BLINK (SHORT)**
Trouble Condition Memory
Trouble Condition Memory
Trouble Condition Memory
Trouble Condition Memory
–
–
–
