Altronix AL802ULADA Installation Manual
Nac power extender
Hide thumbs
Also See for AL802ULADA:
- Installation manual (13 pages) ,
- Application manual (8 pages) ,
- Application manual (8 pages)
Related Manuals for Altronix AL802ULADA
Summary of Contents for Altronix AL802ULADA
- Page 1 AL802ULADA NAC Power Extender Installation Guide (see Application Guide for additional information) Altronix Corp. 140 58th St. Brooklyn, NY More than just power. Rev. 111519...
-
Page 2: Table Of Contents
Enclosure Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 16 - 2 - AL802ULADA... -
Page 3: Overview
Overview: Altronix AL802ULADA is an extremely cost-effective 8A remote power supply/battery charger . It may be con- nected to any 12 or 24 volt Fire Alarm Control Panel (FACP) . Primary applications include Notification Appliance Circuit (NAC such as strobes and horns) expansion support to meet ADA requirements . It also provides auxiliary power to support system accessories . -
Page 4: Power Supply Specifications
Use two (2) 12VDC / 7AH, two (2) 12VDC / 12AH or two (2) 12VDC / 36AH Battery batteries connected in series . Stand-by/Alarm 90mA/175mA Current Consumption: EOL Resistor (end of line): 2 .2K (2200 Ohm), Altronix Model # AL-EOL22 (included) . Ground fault maximum 1000 Ohm . test impedance: Stand-by Specifications: Stand-by Time Total... -
Page 5: Output Programming Selection Table
Cooper Wheelock . vated at the same time . *NOTE: The AL802ULADA will only synchronize horns, horn/strobes and strobes that contain synchronization capability . The same synchronization mode must be selected for all outputs NOTE: It is required to control visual notification appliances (strobes) via Input 1 (IN1) and audible notification appliances (horns) via Input 2 (IN2). -
Page 6: Amount Of Notification Appliances Per Nac
For loads connected to “AUX” please refer to battery “Stand-by Specifications”, pg. 5 for ratings. When loads are connected to “AUX” output during alarm condition, the remaining outputs may not exceed 8A total alarm current (example: AUX = 1A, outputs up to 7A). - 6 - AL802ULADA... -
Page 7: Al800Ada Power Supply Board
To reset the memory depress the reset button (Fig. 2c, pg. 9) . The LED(s) will extinguish . Note: If indicating circuits have been restored, memory reset is not required for normal operation of the unit . AL802ULADA - 7 -... -
Page 8: Battery Calculation Worksheet
Current Current For each device use this formula: This column x This column = Equals Current per number of devices . Stand-by: 90mA 90mA AL802ULADA (Current draw from battery) Alarm: 175mA 175mA AL802 Current 90mA 175mA Auxiliary Devices Refer to device manual for current ratings . -
Page 9: Hookup Diagram
AL802ULADA - 9 -... -
Page 10: Optional Hookups
Input fuse rating is 5A @ 250V . Note: Maximum charging current is 3 .2A . Note: Expected battery life is 5 years; however, it is recommended changing batteries in 4 years or less if needed . - 10 - AL802ULADA... -
Page 11: Compatible Ul/Cul Listed Devices For Synchronization
Appendix A: Compatible UL/cUL Listed Devices for Synchronization –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– A-1 Strobes, Horns, and Horn/Strobes Table A-1 below lists Strobes, Horns, and Horn/Strobes compatible with AL802ULADA NAC outputs . System Sensor: CHSR - UL P4R-SP - UL PC4RH-P - UL SPSCW - UL... - Page 12 Appendix A (cont’d): Compatible UL/cUL Listed Devices for Synchronization –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– A-1 Strobes, Horns, and Horn/Strobes (cont’d) Table A-1 below lists Strobes, Horns, and Horn/Strobes compatible with AL802ULADA NAC outputs . Gentex: GCS24CR - UL GCCB24PCR / W - UL GEC24-15/75WR - UL...
- Page 13 Appendix A (cont’d): Compatible UL/cUL Listed Devices for Synchronization –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– A-1 Strobes, Horns, and Horn/Strobes (cont’d) Table A-1 below lists Strobes, Horns, and Horn/Strobes compatible with AL802ULADA NAC outputs . Cooper/Wheelock: 50-241575W-FR - UL/cUL E70-24MCW-FN - UL/cUL ET90-24MCCH-FN - UL/cUL...
-
Page 14: B-1 Relays
Appendix B - UL Listed Compatible Devices –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– B-1 Relays Table B-2 below lists relays compatible with AL802ULADA AUX output and Outputs 1-8 when programmed as AUX . Manufacturer Model Current (mA) Manufacturer Model Current (mA) PR-1 R-20T PR-2 R-24T... - Page 15 Notes: AL802ULADA - 15 -...
-
Page 16: Enclosure Dimensions
Altronix is not responsible for any typographical errors . 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www .altronix .com | e-mail: info@altronix .com | Lifetime Warranty | Made in U .S .A . MEMBER...
