Amount of Notification Appliances per NAC:

Amseco
®
Gentex
*Not to exceed a maximum of 2.5A per NAC.

AL800LGK9E Logic Board

Terminal Legend
IN1 +, IN1 –
IN2 +, IN2 –
(Supervised)
RET1 +, RET1 –
RET2 +, RET2 –
(Supervised)
C "DRY1" NC
C "DRY2" NC
(Dry input trigger)
+ OUT1 –
+ OUT2 –
+ OUT3 –
+ OUT4 –
(Supervised)
C "FAULT" NC
(Common
trouble input)
NC, C, NO
(Common
trouble output)
– AUX+
– DC +
NOTE: Unit is equipped with 1A max. auxiliary output: "AUX" will remain battery backed up during
power outage. For loads connected to "AUX" please refer to battery "Stand-by Specifications", pg. 5 for
ratings. When loads are connected to "AUX" output during alarm condition, the remaining outputs may
not exceed 8A total alarm current (example: AUX = 1A, outputs up to 7A).
- 6 -
27 per NAC*
32 per NAC*

Terminal Identification Table:

Function/Description
These terminals connect to the 24VDC FACP notification appliance circuit outputs .
(Class A or Class B) Input trigger voltage is 8-33VDC @ 6 .5mA min . Terminal polar-
ity is shown in alarm condition . During an alarm condition these inputs will cause the
selected outputs chosen to drive notification appliances . The designated outputs are set
by output switches [OUT1 through OUT4] (Output Programming Selection Table, pg.
5). A trouble condition on an output loop will cause the corresponding input to trip the
FACP by opening the FACP loop . An alarm condition will always override trouble to
drive notification appliances . Rated 12V 6 .5mA, 24V 6 .5mA .
For (Class A hookups these terminal pairs return to FACP NAC1 and/or NAC2 . For
Class B hookups the FACP EOL resistor from the NAC1 and/or NAC2 outputs are ter-
minated at these terminals .
An open across these inputs, will cause the selected outputs chosen to drive notification
appliances . The designated outputs are set by output switches [OUT1 through OUT4]
(Output Programming Selection Table, pg. 5). Note these inputs are unidirectional and
will not report a trouble condition to the FACP .
Notification appliances are connected to these regulated outputs (see 02 Application
Guide pg. 2-4). Each power-limited output will supply 2 .5A . Two (2) outputs may be
connected in parallel for a maximum NAC output capability of 4A . Total supply current is
8A (see note below). Outputs are controlled by designated Input 1 [IN1] or Input 2 [IN2]
(Output Programming Selection
An open circuit across this pair of terminals will cause [IN1 and IN2] to simultaneously
signal a trouble condition back to the FACP (Typically used to report AC or BAT Fail) .
Form "C" contact 1A / 28VDC (Fig. 2, pg. 9).
These are dry contact trouble outputs that follow any general loop/system trouble
conditions . (Typically used to trigger a digital communicator or other reporting device) .
Form "C" contact 1A / 28VDC, 0 .35 Power Factor (Fig. 2, pg. 9).
This separate 1A max auxiliary Special Application Power output circuit is Non-
Supervised, Class E . See attached list of devices (Appendix A, pgs. 11-13) .
24VDC from power supply .
®
System Sensor
®
CooperWheelock
32 per NAC*
32 per NAC*
