ALTV2432UL Series
CCTV Power Supplies
Installation Guide
Models Include:
• ALTV2432UL
- 24VAC @ 7 amp (175VA)
- Thirty-two (32) Fuse Protected Outputs.
• ALTV2432300UL
- 24VAC @ 12.5 amp (300VA)
or 28VAC @ 10 amp (280VA).
- Thirty-two (32) Fuse Protected Outputs.
• ALTV2432600UL
- 24VAC @ 25 amp (600VA)
or 28VAC @ 20 amp (560VA).
- Thirty-two (32) Fuse Protected Outputs.
• ALTV2432ULCB
- 24VAC @ 7 amp (175VA)
- Thirty-two (32) PTC Protected Outputs.
• ALTV2432300ULCB
- 24VAC @ 12.5 amp (300VA)
or 28VAC @ 10 amp (280VA).
- Thirty-two (32) PTC Protected Outputs.
• ALTV2432600ULCB
- 24VAC @ 25 amp (600VA)
or 28VAC @ 20 amp (560VA).
- Thirty-two (32) PTC Protected Outputs.
Rev. 020604
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Altronix ALTV2432ULCB
Summary of Contents for Altronix ALTV2432ULCB
-
Page 1: Installation Guide
ALTV2432UL Series CCTV Power Supplies Installation Guide Models Include: • ALTV2432UL • ALTV2432ULCB - 24VAC @ 7 amp (175VA) - 24VAC @ 7 amp (175VA) - Thirty-two (32) Fuse Protected Outputs. - Thirty-two (32) PTC Protected Outputs. • ALTV2432300UL • ALTV2432300ULCB - 24VAC @ 12.5 amp (300VA) -
Page 2: Specifications
Overview: These Altronix CCTV Power Supplies provide 24VAC/28VAC, (ALTV2432UL and ALTV2432ULCB provide 24VAC), distributed via thirty-two (32) fuse or PTC protected outputs for powering CCTV Cameras, heaters and other video accessories. Thirty-two (32) Output ALTV2432UL Reference Chart: Altronix Model Number... -
Page 3: Terminal Identification
7. Turn main switch on unit to the ON (RESET) position (Figs. 1-3, pgs. 4-6). 8. Green LED(s) will illuminate when unit is powered. 9. Upon completion of wiring, secure enclosure door with screws (supplied). Caution: Equipment to be installed / serviced by authorized / trained personnel only. Shut branch circuit power before installing / servicing equipment. - Page 4 Fig. 1 ALTV2432UL • ALTV2432ULCB Used on PTC Models (example: ALTV2432ULCB) Power Limited Class 2 common common 1 2 3 4 5 6 7 8 common 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8...
- Page 5 Fig. 2 ALTV2432300UL • ALTV2432300ULCB Used on PTC Models (example: ALTV2432300ULCB) Power Limited Class 2 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 common common 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 common...
- Page 6 Fig. 3 ALTV2432600UL • ALTV2432600ULCB Used on PTC Models (example: ALTV2432600ULCB) Power Limited Class 2 common common 1 2 3 4 5 6 7 8 common 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16...
- Page 7 Enclosure Dimensions: 13"H x 13.5"W x 3.5"D 3.25" TOP ONLY 1.1875" 3.25" 1.1875" .75" 1.5" 6.25" 11" 11.75" 12.5" 1.1875" 3.25" .81" 1.4" 1.4" 5.5" 6.5" 11.66" 12.1" 13" - 7 -...
- Page 8 Notes: Altronix is not responsible for any typographical errors. Altronix Corp. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 web site: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A. IIALTV2432ULSeries J21D MEMBER - 8 -...
