Enclosure Dimensions - Altronix MAXIMAL Maximal11E Installation Manual

1.25"
(31.75mm)
8.5"
(215.9mm)
7.5"
(190.5mm)
26"
(660.4mm)
LEFT
10"
(254mm)
Altronix is not responsible for any typographical errors .
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www .altronix .com | e-mail: info@altronix .com | Lifetime Warranty | Made in U .S .A .
IIMaximalE Series
- 12 -
Enclosure Dimensions (H x W x D approximate):
26" x 19" x 6 .25" (660 .4mm x 482 .6mm x 158 .8mm)
2" 4"
(50.8mm) (101.6mm)
0.85"
(21.59mm)
1.5"
(38.1mm)
26"
(660.4mm)
1"
(25.4mm)
0.85"
(21.59mm)
19"
(482.6mm)
7"
(177.8mm)
TOP
19"
(482.6mm)
8.9"
(226.06mm) (213.36mm)
8.9"
(226.06mm) (213.36mm)
BOTTOM
19"
(482.6mm)
E21S
4" 2"
(101.6mm) (50.8mm)
6.25"
(158.75mm)
0.85"
8.4"
(21.59mm)
1.5"
(38.1mm)
5"
(127mm)
7.5"
(190.5mm)
1"
(25.4mm)
8.4"
0.85"
(21.59mm)
6.25"
(158.75mm)
4"
2"
(101.6mm)
(50.8mm)
Maximal Expandable Power Systems
1.25"
(31.75mm)
1.5"
(38.1mm)
7"
(177.8mm)
8.5"
(215.9mm)
26"
(660.4mm)
RIGHT
7"
(177.8mm)
2"
(50.8mm)
1.25"
(31.75mm)
