4 Wiring and Connections

4.1 HDMI Cables

Important items to consider when planning or installing a system using IP Video devices.

–

High quality HDMI cables are very important when passing UHD. Adding deep color and HDR raises the need for high quality cables.

–

Long HDMI cables can introduce signal degradation so Savant recommends using the shortest possible HDMI cables.

4.2 10G Ethernet

Fiber (SFP+)

Enhanced small form-factor pluggable connection. Use a Savant certified Direct Access Copper (DAC) SFP+ cable to connect the chassis to the 10G

switch, or Savant certified fiber and fiber connectors along with Savant certified SFP+ modules.

Transport Distance

DAC cable

OM3 multi-mode Fiber

Copper (RJ-45)

RJ-45 10G Ethernet connection.

Transport Distance

Cat5e

Cat6

Cat6a

Cat7

TIP!

The distances in the above Copper table are tested with two patch cables included. If the cable is a homerun (single unbroken length) the distance can be

up to 150ft (50m) for Cat5e/Cat6.

4.3 1G Ethernet/LAN

Standard RJ-45 port that uses 1G reserved data bandwidth commonly used to connect any network compliant device to transmit its data onto the

Ethernet network by sharing the 10G network link. This is a courtesy port it will not work for all network functions. Example: Spanning tree devices are

not supported by this port.

IMPORTANT! Do not connect this port to a network switch.

Savant IP Video with Audio Processing Deployment Guide

009-1621-01 | 181107

6ft (2 m)

1000ft (300 m)

100ft (30m)

300ft (100m)
