Savant® IP Video Single Input Transmitter 4K UHD with Control (PAV-VIM1CP2)
Quick Reference Guide

Box Contents

(1)
Single Video IP Transmitter (PAV-VIM1CP2-xx)
(1)
Installation kit (075-0210-xx)
(1)
Power Adapter with International Clips (025-0195-xx)
(1) International Clips (CN, US, UK, EU & AUS)
(2) Mounting Brackets (071-1093-xx)
(4) M2.5 x 4mm screws (for mounting brackets) (039-0590-xx)
(1)
IR Emitter (4ft long) (064-0442-xx)
(1)
3-pin RS232 Control Connector (028-0805-xx)
(1)
Product Information and Regulatory Statement (009-1950-xx)

Specifications

Environmental

Temperature
30° to 105° F (0° to 40° C)
Humidity
10% to 90% Relative Humidity (non-condensing)

Dimensions and Weights

Height
0.98 in
Device
(2.48cm)
3.63 in
Shipping
(9.22 cm)

Power

Power over
IEEE 802.3at
Ethernet (PoE+)
Input Power
12V 2A DC
Power
16 W
Consumption

Compliance

FCC Part 15
Safety and
Emissions
RoHS
Compliant

Supported Releases

Software
da Vinci 9.4 and higher
Release

Supported Audio and Video Formats

Audio
Supported
Pass-though of all HDMI 2.0 audio formats are
Formats
supported.
Video
HDR
Supported
Supported
640x480
6
Formats
720x480
4
720x576
800x600
1024x768
1280x720
1280x720
1 = at 24 Hz
3 = at 30 Hz
2 = at 25 Hz
4 = at 50 Hz
PAV-VIM1CP2-xx Quick Reference Guide | 009-2033-01
Copyright 2022 Savant Systems, Inc | 220823
Width
Depth
6.3 in
5.72 in
(16cm)
(14.52cm)
15.5 in
8.5 in
(39.37 cm)
(21.59 cm)
CE
C-Tick
5
5
1280x1024
3840x2160
1
1920x1080
3840x2160
3
1920x1080
3840x2160
5
4
1920x1080
3840x2160
5
5
1920x1080
4096x2160
4
5
1920x1200
4096x2160
5
1
3840x2160
5 = at 60 Hz

Required Components

Savant IP Video Receiver
Savant System Host
Savant qualified 10G Managed Network Switch
Savant User Interface
Savant Development Environment (SDE)

Front Panel

B
C
A
Power
Video
LinkTx
Weight
A
Power LED
1.35 lb
(0.61 kg)
B
Video LED
2.65 lb
(1.20 kg)
C
LinkTX LED
D
LinkRX LED
E
Status
F
P1
G
Reset

Networking Guidelines

To ensure that the IP Address will not change due to a power outage,
Savant recommends using DHCP reservation within the router. By
using this method IP Addresses for all devices can be managed from a
single UI, avoiding the need to access devices individually.
NOTE: IP video device requirements and how to manage IP addresses
are available on the Savant Device Netwoking Guidelines on the
Savant Customer Community.
2
3

Network Requirements

4
For more information, see the Savant Device Networking Guidelines
5
on the Savant Customer Community.
3
5
Additional Information
Refer to the following documents located on the Savant Customer
Community for additional information.
Savant IP Video Deployment Guide (009-1977-xx)
Savant IP Video Network Configuration Guide (009-1552-xx)
Savant IP Audio Deployment Guide (009-1571-xx)
Savant Device Networking Guidelines
1
of
2
D
E
LinkRx
Status
Off - Device is off. No power applied.
Blue - Main board is powered
Off - No video signal detected.
Blue - Video signal detected.
Off - No valid connection
Blue - Valid link
Blinking - Sending Ethernet Data
Off - No valid connection
Blue - Valid link
Blinking - Receiving Ethernet
Blue - Reset button is pressed when the
device is powered on
Blinking - Reset button has been released or
the device was powered on without holding
the reset button
Reserved for future use.
Hold down this button with a pointed
stylus for 20 seconds while powering up
the device to restore the device to factory
default settings
45 Perseverance Way, Hyannis, MA 02601
Savant.com
F
G
P1
Reset
| 508.683.2500
