Microcom 334M Operator's Manual page 226

^A ^D COMMAND
X 111 Kiosk Cutter Mode: This command enables the non-volatile full and/or partial
cut operation. The ^D112 command is also used with the ^D111 command to
adjust the advance distance to the cutter blades and then retract to the home
position (dot row one).
0 Disable Kiosk Cutter Mode.
1 Enable Kiosk Cutter Mode.
2 Enable partial Kiosk Cutter Mode.
4 Enable full Kiosk Cutter Mode with LTS
X 112 Kiosk Cutter Advance Distance Command: The valid range is from
0 to 1000 with the recommended distance of 150.
X 113 Verbose Mode:
0 Disable Verbose Mode.
1 Enable Verbose Mode.
114 RSS-14 Data Entry Command: The Reduced Space Symbology (RSS-14)
barcode is fully supported by the 324M and 424M printers. There are 6
different types of RSS-14 that are supported by the printer:
X 115 Set Cutter Type: Selects the type of cutter installed on the printer.
0 No cutter
1 Guillotine
2 Rotary
X 116 Synchronous Print Mode
0 Exit all sync. modes
1 Enter single sync mode
2 Enter continuous sync mode
3 Enter rapid fire continuous sync mode
4 Enter rapid fire external print mode
X 117 Cutter Hold-off: X represents the number of cuts to skip on the first X labels
following a TOF.
X 118 Home Cutter: This command will return the cutter gear to the home or open
position when issued. Only available of the X28 Series of printer's.
X 119 Display Memory Allocation: This command shows how all of the RAM and
flash memory is being used.
X 120 AutoLoad Delay Selection: The AutoLoad Delay is the amount of time, in
Milliseconds, that the printer waits after detecting that media has been put into
the printer before it starts feeding it in.
121 Top of Form Command: This command causes the printer to perform a
Top-of-Form. This command requires a LPD sensor to be installed on the
printer.
13-14 334M Operator's Manual - 880060-0110
