Chapter 10
10.3

Internal Cleaning

The overall internal cleaning of the printer is important to help reduce the dust and other
contaminates residing in the printer that may attach to the print head or drive roller and
affect the printer's performance. Refer to Figure 10-3 for common areas needing cleaning.
1. Remove any installed media.
2. Turn the printer power "OFF."
3. Release print assembly latches and lift to access the inside of the printer.
4. Internal cleaning can be done using a combination of compressed air, vacuum with
anti-static protection, soft-bristle brushes, foam/cotton tipped swabs, and/or lint-free
cloths dampened in isopropyl alcohol. Use any combination of these materials to
remove dust or other contaminants from the printer.
5. Reinstall media and run labels to check print quality.
Blow dust out with
compressed air or
vacuum with anti-static
vacuum cleaner.
Clean Peel Edge with
lint-free cloth or swabs
dampened with isopropyl
alcohol.
334M Operator's Manual - 880060-0110
Figure 10-3 Internal Cleaning
Printer Maintenance
Clean Drive Roller with
lint-free cloth or swabs
dampened with isopropyl
alcohol. (Drive Roller
can be rotated by hand.)
10-4
