Motherboard
1 x 4-pin ATX main power connector
4 x SATA 6Gb/s connectors
6 x USB 2.0 headers
1 x Front panel header
1 x Front panel audio header
1 x 2W Speaker out header
1 x LVDS connector
Internal I/O
1 x System fan header
1 x CPU fan header
1 x COM header (RS-232)
1 x COM header (RS-232/422/485 & 5V/12V/RI)
2 x SATA Power connectors
1 x eDP connector
1 x GPIO (8 bits) & SMBUS header
1 x ATX Control header
2 x Audio jacks (Line out, Mic in)
1 x HDMI 2.0
1 x Display Port
Rear I/O
2 x RJ45 LAN Ports
4 x USB 3.2 Gen1
1 x DC Jack (+12V/+19~24VDC)
TPM
1 x TPM Header
OS Compatibility
Windows® 10 (x64)
1 x DC-in (+12V/ +19~24VDC)
PSU Connectors
1 x 4-pin ATX power connector
Operating temperature: 0°C to 60°C
Operating
Operating humidity: 0-90% (non-condensing)
Properties
Non-operating temperature: -40°C to 85°C
Non-operating humidity: 0%-95% (non-condensing)
Order Information Motherboard: 9MQ47EATMR-SI
TPM 2.0 module : 9CTM000NR-00
Optional kit:
TPM Cable : 25CRZ-100600-S9R
iTXL-Q47EA (MQ47EAT-SI)
www.gigaipc.com
16
