- Page 1 (MH42EAT-SI) Thin Mini-ITX Motherboard User’s Manual 1st Ed www.gigaipc.com...
-
Page 2: Thin Mini-Itx Motherboard
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. -
Page 3: Copyright Notice
Core, Atom are trademarks of Intel Corporation • • ITE is a trademark of Integrated Technology Express, Inc. IBM, PC/AT, PS/2, and VGA are trademarks of International Business • Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com... -
Page 4: Acknowledgement
Before setting up your product, please make sure the following items have been shipped: Item Quantity iTXL-H42EA MB SATA power cable I/O Bracket If any of these items are missing or damaged, please contact your distributor or sales representative immediately. -
Page 5: Packing List
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: About This Document
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... -
Page 7: Safety Precautions
18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com... - Page 8 Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com...
-
Page 9: Fcc Statement
China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 GIGAIPC Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 及其电 ○ ○ ○ ○ ○ ○ 子组件 外部信号 连接器 ○ ○ ○ ○... -
Page 10: China Rohs Requirements (Cn)
China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products GIGAIPC Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &... -
Page 11: Table Of Contents
4) ................... 25 2.2.5 LAN1, LAN2 (GbE Ethernet LAN Ports x 2) ....26 2.2.6 HDMI_DP (HDMI + DP connector) ........ 27 2.2.7 SATA0, 1, 2, 3 (SATA 6Gb/s Connector x 4) ....28 2.2.8 Battery (Battery Connector) ......... 29 www.gigaipc.com... - Page 12 2.2.27 FUSB2_3 (USB 2.0 Header) ........... 48 2.2.28 ATX_CTL (ATX Control Header, Support PS-ON Signal of Power Supply Unit) ............49 2.2.29 SATA_PWR1, SATA_PWR2 (SATA Power Connector x 2) ..................50 2.2.30 CLR_CMOS (Clear CMOS Jumper) ......... 51 2.2.31 ME_EN (ME Enable Jumper) ......... 52 www.gigaipc.com...
- Page 13 3.3.8 Network Stack Configuration ........67 3.3.9 NVMe Configuration ............. 68 3.3.10 Offboard SATA Controller Configuration ...... 69 3.3.11 Digital IO Port Configuration ........70 Chipset ................71 Security ................. 73 Boot ................76 Save & Exit ..............77 www.gigaipc.com...
-
Page 14: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 15 16.3 170.0 33.02 132.08 0.00 11.5 36.5 54.3 73.2 94.1 119.0 136.7 149.1 170.00 19.8 10.16 154.94 www.gigaipc.com...
-
Page 16: Specifications
Specifications Motherboard iTXL-H42EA (MH42EAT-SI) Thin Mini-ITX form factor Form Factor 170W x 170D (mm) Support for 10th Generation Intel® Core™ i9/i7/i5/i3 processors, Pentium® & Celeron® processors in the LGA1200 package TDP under 65W L3 cache varies with CPU Socket 1 x LGA 1200 Chipset Intel®... - Page 17 Motherboard iTXL-H42EA (MH42EAT-SI) 1 x 4-pin ATX main power connector 2 x SATA Power connectors 1 x CPU fan header 1 x Systen fan header 1 x Front panel header 1 x Front panel audio header 1 x 2W Speaker out header Internal I/O 5 x USB 2.0 headers...
-
Page 18: Chapter 2 - Hardware Information
Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com... -
Page 19: Jumpers And Connectors
Jumpers and Connectors 19 20 www.gigaipc.com... - Page 20 ATX 2x2 Pin Power Connector USB31_1, USB 3.2 Gen 1 Type A Connector x 4 USB31_2, LAN1, LAN2 GbE Ethernet LAN ports x 2 HDMI Connector HDMI_DP Display Port Connector LINE_OUT Line Out port (Green) MIC_IN Mic In port (Pink) www.gigaipc.com...
- Page 21 General purpose input/out Connector COM1 COM header (RS-232/422/485 & RI/5V/12V) JCOM1 RI# pin RI#/5V/12V Select for COM1 port AT/ATX mode select jumper AT_CN COM header (RS-232) COM2 FUSB2_3 USB 2.0 Header ATX Control Header, Support PS-ON Signal of ATX_CTL Power Supply Unit www.gigaipc.com...
- Page 22 Code Description SATA_PWR1 SATA Power Connector x 2 SATA_PWR2 CLR_CMOS Clear CMOS Jumper ME_EN ME Enable jumper SODIMM1, 2 x DDR4 SO-DIMM Sockets SODIMM2 M2_M M.2 Slot, M-Key, Support NGFF-2280 www.gigaipc.com...
-
Page 23: Io Connector Information
DC_IN DC In Jack USB31_1, USB 3.2 Gen 1 Type A Connector x 4 USB31_2, LAN1, LAN2 GbE Ethernet LAN Port x 2 HDMI Connector HDMI_DP Display Port Connector LINE_OUT Line Out port (Green) MIC_IN Mic In port (Pink) www.gigaipc.com... -
Page 24: Dc_In (Dc In Jack)
2.2.2 DC_IN (DC In Jack) DC In Jack Connector Connector PN Vendor 655-360-000 SHEN-MING www.gigaipc.com... -
Page 25: Dc_In2 (Atx 2X2 Pin Power Connector)
2.2.3 DC_IN2 (ATX 2x2 Pin Power Connector) Pin 1 Power Connector Connector PN Vendor 740-81-04TW56 PINREX Pin No. Definition DC IN DC IN www.gigaipc.com... -
Page 26: Usb31_1, Usb31_2 (Usb 3.2 Gen 1 Type A Connector X 4)
2.2.4 USB31 _1, USB31 _ 2 (USB 3.2 Gen 1 Type A connector x 4) USB Connector Connector PN Vendor UEA11121-8FS6-4F FOXCONN ABA-USB-079-K01 LOTES Definition Definition USB3_RX1n USB3_RX2n USB3_RX1p USB3_RX2p USB3_TX1n USB3_TX2n USB3_TX1p USB3_TX2p www.gigaipc.com... -
Page 27: Lan1, Lan2 (Gbe Ethernet Lan Ports X 2)
LAN1, LAN2 (GbE Ethernet LAN Ports x 2) LAN Connector State Description Orange On 1Gbps data rate Green On 100Mbps data rate 10Mbps data rate Connector PN Vendor Pin No. Definition Pin No. Definition TX1+ TX3+ RB1-13NB5N5A TX1- TX3- TX2+ TX4+ TX2- TX4- www.gigaipc.com... -
Page 28: Hdmi_Dp (Hdmi + Dp Connector)
DP Connector Pin No. Definition Pin No. Definition Pin No. Definition Pin No. Definition TX2p TX0p TX3n CLKn TX2n TX0n TX1p TX1p AUXp TX1n TX1n TX0p TX2p AUXn Hot Plug Detect Hot Plug TX0n TX2n 3.3V Detect CLKp TX3p 3.3V www.gigaipc.com... -
Page 29: Sata0, 1, 2, 3 (Sata 6Gb/S Connector X 4)
2.2.7 SATA0, 1, 2, 3 (SATA 6Gb/s Connector x 4) SATA 6Gb/s Connector Connector PN Vendor WATM- WINWIN 07ABNB2BAUW3 SATA 0 SATA 1 770-83-07SW19 PINREX SATA 2 SATA 3 Pin No. Definition www.gigaipc.com... -
Page 30: Battery (Battery Connector)
2.2.8 Battery (Battery Connector) Pin 1 Battery Connector Pin No. Definition www.gigaipc.com... -
Page 31: Fp_Audio (Front Panel Audio Header)
2.2.9 FP_AUDIO (Front Panel Audio Header) Pin 1 Front Panel Audio Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Definition Definition MIC-LEFT JACKSENCE DELTECT MIC-RIGHT DELTECT LINE-LEFT LINE-RIGHT www.gigaipc.com... -
Page 32: Spkr (Speaker Out Connector)
2.2.10 SPKR (Speaker Out Connector) Pin 1 Speaker Out Connector Connector PN Vendor 721-81-045W00 PINREX A2001WV-04P146 JOINT-TECH Pin No. Definition SPEAKER L+ SPEAKER L- SPEAKER R- SPEAKER R+ www.gigaipc.com... -
Page 33: M2E (M.2 Slot, E-Key, Support Ngff-2230)
PCIE CLOCKp PCIE CLOCKn SUSCLK Pin No. Definition Pin No. Definition PCIE Clock PCIRST 3.3V Request 3.3V PCIE wake up BT_Disable WLAN_DISABLE 3.3V 3.3V Pin No. Definition Pin No. Definition Connector PN Vendor 80152-8521 BELLWETHER PCIE_TXp 2E0BC21-S85BE-7H FOXCONN PCIE_TXn www.gigaipc.com... -
Page 34: Pciex8 (1 X Pcie X16 (Gen3 X8) Slot)
2.2.12 PCIEX8 (PCIe Gen3 x8) PCIEX16 connector www.gigaipc.com... -
Page 35: Cpu_Fan (Cpu Fan Connector)
2.2.13 CPU_FAN (CPU FAN Connector) Pin 1 CPU Fan Connector Connector PN Vendor 744-81-045W11 PINREX Pin No. Definition Detect Speed �ontrol www.gigaipc.com... -
Page 36: Fusb2_2 (Usb 2.0 Header)
2.2.14 FUSB2_2 (USB 2.0 Header) Pin 1 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX 2 4 6 8 10 PH10R53BAZ009 HORNGTONG 1 3 5 7 9 Pin No. Definition No Pin www.gigaipc.com... -
Page 37: Fusb2_1 (Usb 2.0 Header)
2.2.15 FUSB2_1 (USB 2.0 Header) Pin 1 USB 2.0 Header Connector PN Vendor 210-91-05GB02 PINREX PH05R23BAZ005 HORNGTONG Pin No. Definition www.gigaipc.com... -
Page 38: Sys_Fan (System Fan Connector)
2.2.16 SYS_FAN (System Fan Connector) Pin 1 System FAN connector Connector PN Vendor 744-81-045R11 PINREX WF04R22RJQ105 HORNGTONG Pin No. Definition www.gigaipc.com... -
Page 39: Lsw (Lvds Resolution Jumper)
1024 x 600 1600 x 900 18bit 24bit 1280 x 800 1680 x 1050 18bit 24bit 1280 x 960 1600 x 1200 18bit 24bit 1280 x 1024 1920 x 1080 24bit 24bit 1366 x 768 1920 x 1200 18bit 24bit www.gigaipc.com... -
Page 40: Edp (Embedded Display Port Connector)
Embedded Display Port connector Pin No. Definition Pin No. Definition 3.3V TX3n TX3p AUXn Pin No. Definition Pin No. Definition AUXp Connector PN Vendor Hot Plug TX0n 115B30-000040-G4-R STARCONN Detect Backlight TX0p Enable Backlight TX1n controll TX1p 3.3V TX2n 3.3V TX2p 3.3V www.gigaipc.com... -
Page 41: Bkl_Cn (Backlight Control Connector)
2.2.19 BKL_CN (Backlight Control Connector) Pin 1 Backlight Control Connector Connector PN Vendor 721-81-05TW00 PINREX A2001WV-05P146 JOINT-TECH Pin No. Definition Backlight enable www.gigaipc.com... -
Page 42: Lvds (Lvds Connector)
But below model no need to add. SPED0 A0~A3 is odd channel 0~3, A4~A7 is ev en channel. Note: *The LVDS output connector of the unit is only intended to be CLK2+ connected to an UL/IEC/EN approval CLK1+ equipment with fire enclosure. CLK2- CLK1- www.gigaipc.com... -
Page 43: Sys_Panel (System Panel Header)
2.2.21 SYS_PANEL (System Panel Header) Pin 1 System Panel Header Connector PN Vendor 210-92-05GW5W PINREX Pin No. Definition HD-p MPD-p HD-n MPD-n POWER-ON Reset Reserved www.gigaipc.com... -
Page 44: Gpio_Cnt (General Purpose Input/Output Connector)
2.2.22 GPIO_C NT (General purpose input/output Connector) Pin 1 GPIO Connector Pin No. Definition SMBus Clock SMBus DATA Pin No. Definition Connector PN Vendor GPIO-output_1 725-81-12TW00 PINREX GPIO-input_1 A2004WV-2X06P46 JOINT-TECH GPIO-output_2 GPIO-input_2 GPIO-output_3 GPIO-input_3 GPIO-output_4 GPIO-input_4 www.gigaipc.com... -
Page 45: Com1 (Com Header Rs-232/422/485 & Ri/5V/12V)
2.2.23 COM1 (COM header RS-232/422/485 & RI/5V/12V) Pin 1 COM1 Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH RS-232 RS-422 RS-485 Full Duplex Half Duplex TXD+ TXD- RXD- – RXD+ – – – – – – – – – No Connect – – – – www.gigaipc.com... -
Page 46: Jcom1 (Ri# Pin Ri#/5V/12V Select For Com1 Port)
2.2.24 JCOM1 (RI# pin RI#/5V/12V Select for COM1 Port) Pin 1 JCOM1 Jumper Select Connector PN Vendor 210-92-03GB01 PINREX 1-2 Close: PH06R53BAZ000 HORNGTONG 5V (Power COM) 3-4 Close: RI (Stand COM) 5-6 Close: 12V (Power COM) www.gigaipc.com... -
Page 47: At_Cn (At/Atx Mode Select Jumper)
2.2.25 AT_CN (AT/ATX mode select jumper) Pin 1 AT/ATX mode select jumper Connector PN Vendor 222-96-03GBE1 PINREX Pin No. Definition AT MODE Detect ATX MODE Jumper setting 1-2 Close : AT mode. 2-3 Close : ATX mode.(Default setting) www.gigaipc.com... -
Page 48: Com2 (Com Header (Rs-232))
2.2.26 COM2 (COM header (RS-232)) Pin 1 COM2 Header Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Pin No. Definition www.gigaipc.com... -
Page 49: Fusb2_3 (Usb 2.0 Header)
2.2.27 FUSB2_3 (USB 2.0 Header) Pin 1 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Pin No. Definition No Pin www.gigaipc.com... -
Page 50: Atx_Ctl (Atx Control Header, Support Ps-On Signal Of Power Supply Unit)
2.2.28 ATX_CTL (ATX Control Header, Support PS-ON Signal of Power Supply Unit) Pin 1 ATX Control Header Connector PN Vendor 744-81-02TW10 PINREX Pin No. Definition PSON# www.gigaipc.com... -
Page 51: Sata_Pwr1, Sata_Pwr2 (Sata Power Connector X 2)
2.2.29 SATA_PWR1, SATA_PWR2 (SATA Power Connector x 2) Pin 1 SATA Power Connector Connector PN Vendor 743-81-04TW00 PINREX WF04Q2-3BJQ000 HORNGTONG Pin No. Definition www.gigaipc.com... -
Page 52: Clr_Cmos (Clear Cmos Jumper)
2.2.30 CLR_CMOS (Clear CMOS Jumper) Pin 1 Clear COMS Jumper Pin No. Definition Clear CMOS Open: Normal Operation (Default setting) Close: Clear COMS data. www.gigaipc.com... -
Page 53: Me_En (Me Enable Jumper)
2.2.31 ME_EN (ME Enable Jumper) Pin 1 ME Enable Jumper ME Enable Jumper Enable Disable www.gigaipc.com... -
Page 54: Sodimm1, Sodimm2 (2 X Ddr4 So-Dimm Sockets)
2.2.32 SODIMM1, SODIMM2 (2 x DDR4 SO-DIMM Sockets) www.gigaipc.com... -
Page 55: M2_M (M.2 Slot, M-Key, Support Ngff-2280)
PCIE Clock+ PCIE3 TXn 3.3V PCIE3 TXp 3.3V Pin No. Definition Pin No. Definition 3.3V PCIE2 RXn 3.3V SUSCLK PCIE2 RXp Detect 3.3V 3.3V PCIE2 TXn 3.3V PCIE2 TXp Connector PN Vendor PCIE1 RXn PCIE1 RXp APCI0073-P001A LOTES AS0BC21-S40BM-7H FOXCONN www.gigaipc.com... -
Page 56: Chapter 3 - Bios
Chapter 3 Chapter 3 – BIOS www.gigaipc.com... -
Page 57: Introduction
Execute command or enter the submenu Increase the numeric value or make ＋ changes Decrease the numeric value or make – changes General Help Previous Values Load Optimized Defaults Settings Save changes & Exit the BIOS Setup program Exit the BIOS Setup program www.gigaipc.com... -
Page 58: The Main Menu
ME FW version Shows ME firmware version Set the Date for the system System Date (Format : Week - Month - Day - Year) Set the time for the system System Time (Format : Hour - Minute - Second) www.gigaipc.com... -
Page 59: Advanced
Advanced The Advanced menu is to configure the functions of hardware settings through submenu. Use arrow keys to move among the items, and press <Enter> to access into the related submenu. www.gigaipc.com... -
Page 60: Tpm Configuration
3.3.1 TPM Configuration Use TPM Configuration submenu to choose TPM interface. Item Description PTT : Internal TPM (Default setting) TPM Device dTPM : External TPM (When using External TPM module or Selection having TPM chip on MB) www.gigaipc.com... - Page 61 Disabled : Disables TPM feature None : No execution will be conducted (Default setting) Pending operation TPM clear : Set to clear data on TPM Enabled : Enables Platform Hiearchy (PH) Randomization. (Default setting) PH Randomization Disabled : Disables Platform Hiearchy (PH) Randomization. www.gigaipc.com...
-
Page 62: It8786 Super Io Configuration
Serial Port 2 Enabled : Enables allows you to configure the serial port settings Configuration Disabled : if Disabled, displays no configuration for the serial port Device settings : Display the specified Serial Port base I/O address and IRQ www.gigaipc.com... -
Page 63: Hardware Monitor
Normal : Fan speed set by BIOS default (Default setting) Control Full Speed : Set Fan operates at full speed CPU Temperature Shows current CPU temperature System Shows current system temperature Temperature CPU Fan Speed Shows current CPU fan Speed SYS Fan Speed Shows current System fan Speed www.gigaipc.com... -
Page 64: S5 Rtc Wake Settings
Enable or Disable System to wake on a specific time. Wake system Disabled : Disables system to wake on a specific time (Default setting) from S5 Fixed Time : Enables system to wake on a specific time (Format : hr : min : sec) www.gigaipc.com... -
Page 65: Cpu Configuration
CPU P states Enabled : Enables CPU P states function Disabled : Disables CPU P states function (Default setting) To optimize CPU performance. Optimize Performance Enabled : Enables optimize performance function Disabled : Disables optimize performance function (Default setting) www.gigaipc.com... -
Page 66: Sata And Rst Configuration
3.3.6 SATA And RST Configuration Item Description SATA Mode Set SATA controller to AHCI mode Selection Serial ATA Port 0 Serial ATA Port 1 shows 2.5" SATA HDD/SSD information Serial ATA Port 2 Serial ATA Port 3 www.gigaipc.com... -
Page 67: Ami Graphic Output Protocol Policy
3.3.7 AMI Graphic Output Protocol Policy Item Description Choose default monitor output when there are more than one monitor plugged Output Select on the motherboard. www.gigaipc.com... -
Page 68: Network Stack Configuration
When Network stack is enabled : Ipv4 PXE Support Disabled : Disables Ipv4 PXE Support Enabled : Enables Ipv4 PXE Support When Network stack is enabled : Ipv6 PXE Support Disabled : Disables Ipv6 PXE Support Enabled : Enables Ipv6 PXE Support www.gigaipc.com... -
Page 69: Nvme Configuration
3.3.9 NVMe Configuration NVMe Configuration shows information when your M.2 NVMe PCIe SSD is installed. www.gigaipc.com... -
Page 70: Offboard Sata Controller Configuration
3.3.10 Offboard SATA Controller Configuration www.gigaipc.com... -
Page 71: Digital Io Port Configuration
Enabled : If Digital IO Output value/level is modified in OS, they will be memorized and kept. SOGPO_1 (Pin 1) SOGPI_1 (Pin 2) SOGPO_2 (Pin 3) SOGPI_2 (Pin 4) Configure Digital IO Input or Output values for each pin. SOGPO_3 (Pin 5) SOGPI_3 (Pin 6) SOGPO_4 (Pin 7) SOGPI_4 (Pin 8) www.gigaipc.com... -
Page 72: Chipset
Enabled : Enables Above 4GB MMIO BIOS assignment function Disabled : Disables Above 4GB MMIO BIOS assignment function (Default setting) Enable/Disable onboard audio controller HD Audio Enabled : Enables onboard audio controller (Default setting) Disabled : Disables onboard audio controller www.gigaipc.com... - Page 73 Enable/Disable XHCI Hand-off function XHCI Hand-off Enabled : Enables XHCI Hand-off function (Default setting) Disabled : Disables XHCI Hand-off function Enable/Disable BIOS Lock function BIOS Lock Enabled : Enables BIOS Lock function (Default setting) Disabled : Disabled BIOS Lock funtion www.gigaipc.com...
-
Page 74: Security
To set up Administrator's password Administrator Minimum length : 3 Password Maximum length : 20 To set up User's password User Password Minimum length : 3 Maximum length : 20 Secure Boot Press <Enter> to configure the advanced items www.gigaipc.com... - Page 75 No : Cancel to restore factory settings Reset To Setup Yes : Agree to setup mode Mode No : Cancel to setup mode Enables expert users to modify Secure boot policy variables without full Key Management authentication Press <Enter> to configure the advanced items www.gigaipc.com...
- Page 76 'UEFI CA' from database from DB No : Cancel to remove 'UEFI CA' from database Restore DB variables to fac tor y Restore DB defaults defaults Yes : Agree to restore DB defaults No : Cancel to restore DB defaults www.gigaipc.com...
-
Page 77: Boot
Enabled : Enables Full screen LOGO Show on POST screen LOGO Show Disabled : Disables Full screen LOGO Show on POST screen (Default setting) Boot Option #1 Shows the information of the storage that be installed in the system Boot Option #2 Choose/set the boot priority www.gigaipc.com... -
Page 78: Save & Exit
Yes : Agree to load optimized defaults No : Cancel to load optimized defaults Enable/Disable Me FW image re-flash function Me FW Image Enabled : Enables Me FW image re-flash function Re-Flahs Disabled : Disables Me FW image re-flash function (Default setting) www.gigaipc.com...
