- Page 1 Thin Mini-ITX Motherboard User’s Manual 1st Ed www.gigaipc.com...
-
Page 2: Thin Mini-Itx Motherboard
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. -
Page 3: Copyright Notice
Core, Atom are trademarks of Intel Corporation • • ITE is a trademark of Integrated Technology Express, Inc. IBM, PC/AT, PS/2, and VGA are trademarks of International Business • Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com... -
Page 4: Acknowledgement
Before setting up your product, please make sure the following items have been shipped: Item Quantity iTXL-1135G7A or iTXL-1115G4EA MB SATA power cable I/O Bracket If any of these items are missing or damaged, please contact your distributor or sales representative immediately. -
Page 5: Packing List
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: About This Document
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... -
Page 7: Safety Precautions
18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com... - Page 8 Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com...
-
Page 9: Fcc Statement
China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 GIGAIPC Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 及其电 ○ ○ ○ ○ ○ ○ 子组件 外部信号 连接器 ○ ○ ○ ○... -
Page 10: China Rohs Requirements (Cn)
China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products GIGAIPC Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &... -
Page 11: Table Of Contents
2.2.4 USB31 (USB 3.2 Gen 2x1 connector) ......25 2.2.5 LAN1 (GbE LAN connector) ........... 26 2.2.6 LAN2 (2.5GbE LAN connector) ........27 2.2.7 DC_IN2 (ATX 2x2 pin power connector) ....... 28 2.2.8 SYS_FAN (System fan connector) ......... 29 www.gigaipc.com... - Page 12 2.2.27 EDP (Embedded Display Port Connector) ....48 2.2.28 M2M (M.2 Slot, M-key, Support NGFF-2280) ....49 2.2.29 LSW (LVDS resolution jumper) ........50 2.2.30 BKL_LVDS (Backlight Control header for LVDS) ..... 51 2.2.31 ME (ME Enable Jumper) ..........52 www.gigaipc.com...
- Page 13 S5 RTC Wake Settings ........... 63 3.3.7 Network Stack Configuration ........64 3.3.8 NVMe Configuration ............. 65 3.3.9 Offboard SATA Controller Configuration ...... 66 3.3.10 Digital IO Port Configuration ........67 Chipset ................68 Security ................. 70 Boot ................73 Save & Exit ..............74 www.gigaipc.com...
-
Page 14: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 15 154.94 18.05 132.08 10.1 www.gigaipc.com...
-
Page 16: Specifications
Specifications Motherboard iTXL-1135G7A iTXL-1115G4EA (MTGU5AT) (MTGU3AT) Thin Mini-ITX form factor Form Factor 170W x 170D (mm) Intel® Core™ i5-1135G7 Intel® Core™ i3-1115G4E Processor Processor 10nm SuperFin, 4 cores, 8 10nm SuperFin, 2 cores, 4 threads, up to 4.2 GHz threads, up to 3.90 GHz... - Page 17 Motherboard iTXL-1135G7A iTXL-1115G4EA (MTGU5AT) (MTGU3AT) 1 x 4-pin ATX main power connector 1 x SATA Power connector 1 x CPU fan header 1 x System fan header 1 x Front panel header 1 x Front panel audio header 4 x USB 2.0 headers Internal I/O 2 x USB 3.2 Gen 1 headers...
-
Page 18: Chapter 2 - Hardware Information
Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com... -
Page 19: Jumpers And Connectors
Jumpers and Connectors www.gigaipc.com... - Page 20 RI# pin RI#/5V/12V Select for COM1, COM2, JCOM2 COM3, COM4 ports JCOM1 COM4 COM3 COM header (RS-232/422/485 & RI/5V/12V) COM2 COM1 GPIO_CNT General Purpose input/output header AT_CN AT/ATX mode select jumper LVDS LVDS connector SODIMM1 2 x DDR4 SO-DIMM Sockets SODIMM2 www.gigaipc.com...
- Page 21 Speaker out connector SPKR Front panel audio header FP_AUDIO Mini PCIE connector MPCIE M.2 Slot, E-Key, Support NGFF-2230 Embedded Display Port connector M.2 Slot, M-Key, Support NGFF-2280 LVDS resolution jumper BKL_LVDS Backlight Control header for LVDS ME Enable jumper www.gigaipc.com...
-
Page 22: Rear I/O Connector
4 x HDMI connector HDMI_43 USB3 USB 3.2 Gen 1 connector USB31 USB 3.2 Gen 2x1 connector LAN1 1 x GbE LAN Port LAN2 1 x 2.5GbE LAN Port HP_OUT 1 x Audio jacks (Line out) 1 x Audio jacks (MIC in) www.gigaipc.com... -
Page 23: Dc_In1 (Dc In Jack)
2.2.1 DC_IN1 (DC In Jack) Power Connector Connector PN Vendor 655-360-000 SHEN-MING www.gigaipc.com... -
Page 24: Hdmi_21, Hdmi_43 (Hdmi Connector)
2.2.2 HDMI_21, HDMI_43 (HDMI connector) HDMI Connector Connector PN Vendor QJ11191-DFB1-4F FOXCONN Pin No. Definition Pin No. Definition TX2p CLKn TX2n TX1p TX1n TX0p Hot Plug TX0n Detect CLKp www.gigaipc.com... -
Page 25: Usb3 (Usb 3.2 Gen 1 Connector)
2.2.3 USB3 (USB 3.2 Gen 1 connector) USB 3.2 Gen 1 Connector Connector PN Vendor UEA11121-8FS6-4F FOXCONN ABA-USB-079-K01 LOTES Definition Definition USB3_RX1n USB3_RX2n USB3_RX1p USB3_RX2p USB3_TX1n USB3_TX2n USB3_TX1p USB3_TX2p www.gigaipc.com... -
Page 26: Usb31 (Usb 3.2 Gen 2X1 Connector)
2.2.4 USB31 (USB 3.2 Gen 2x1 connector) USB 3.2 Gen 2x1 connector Connector PN Vendor 18-A5950-6A33-A TCONN Definition Definition USB_D- USB_D- USB_D+ USB_D+ USB3_RX- USB3_RX- USB3_RX+ USB3_RX+ USB3_TX- USB3_TX- USB3_TX+ USB3_TX+ www.gigaipc.com... -
Page 27: Lan1 (Gbe Lan Connector)
2.2.5 LAN1 (GbE LAN connector) GbE LAN Connector State Description Orange On 1Gbps data rate Green On 100Mbps data rate 10Mbps data rate Pin No. Definition Connector PN Vendor BI_DA+ RT7-GB-0003 BI_DA- BI_DB+ BI_DC+ BI_DC- BI_DB- BI_DD+ BI_DD- www.gigaipc.com... -
Page 28: Lan2 (2.5Gbe Lan Connector)
2.5GbE LAN Connector State Description Yellow On 2.5Gbps data rate Yellow On 1Gbps data rate Green On 100Mbps data rate 10Mbps data rate Pin No. Definition BI_DA+ Connector PN Vendor BI_DA- S22-GB-0006 BI_DB+ JFM4811D-F8AF-4F FOXCONN BI_DC+ BI_DC- BI_DB- BI_DD+ BI_DD- www.gigaipc.com... -
Page 29: Dc_In2 (Atx 2X2 Pin Power Connector)
2.2.7 DC_IN2 (ATX 2x2 pin power connector) Pin 1 power Connector Connector PN Vendor 740-81-04TW56 PINREX Pin No. Definition DC IN DC IN www.gigaipc.com... -
Page 30: Sys_Fan (System Fan Connector)
2.2.8 SYS_FAN (System fan connector) Pin 1 System FAN connector Connector PN Vendor 744-81-045R11 PINREX WF04R22RJQ105 HORNGTONG Pin No. Definition Detect Speed Control www.gigaipc.com... -
Page 31: Cpu_Fan (Cpu Fan Connector)
2.2.9 CPU_FAN (CPU fan connector) Pin 1 CPU FAN connector Connector PN Vendor 744-81-045W1Z PINREX Pin No. Definition Detect Speed Control www.gigaipc.com... -
Page 32: Bkl_Edp (Backlight Control Header For Edp)
2.2.10 BKL_EDP (Backlight control header for EDP) Pin 1 Backlight control connector Connector PN Vendor 721-81-05TW00 PINREX A2001WV-05P146 JOINT-TECH Pin No. Definition Backlight Enable www.gigaipc.com... -
Page 33: Jcom4, Jcom3, Jcom2, Jcom1 (Ri# Pin Ri#/5V/12V Select For Com1, Com2, Com3, Com4 Port)
2.2.11 JCOM4, JCOM3, JCOM2, JCOM1 (RI# pin RI#/5V/12V Select for COM1, COM2, COM3, COM4 port) Pin 1 JCOM1, JCOM2, JCOM3, JCOM4 Connector PN Vendor Jumper 220-97-03GB01 PINREX PH06N53BAZ000 HORNGTONG 1-2 Close: 5V (Power COM) 3-4 Close: RI (Stand COM) 5-6 Close: 12V (Power COM) www.gigaipc.com... -
Page 34: Com1~4 (Com Header (Rs-232/422/485 & Ri/5V/12V)
Pin 1 Serial Port Cable Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH RS-232 RS-422 RS-485 Full Duplex Half Duplex TXD+ TXD- RXD- – RXD+ – – – – – – – – – No Connect – – – – www.gigaipc.com... -
Page 35: Gpio_Cnt (General Propose Input/Output Header)
2.2.13 GPIO_CNT (General Propose input/output header) Pin 1 Pin 1 GPIO Connector Pin No. Definition SMBus DATA Connector PN Vendor Pin No. Definition 725-81-12TW00 PINREX GPIO-output_1 A2004WV-2X06P46 JOINT-TECH GPIO-input_1 GPIO-output_2 GPIO-input_2 GPIO-output_3 GPIO-input_3 GPIO-output_4 GPIO-input_4 SMBus Clock www.gigaipc.com... -
Page 36: At_Cn (At/Atx Mode Select Jumper)
2.2.14 AT_CN (AT/ATX mode select jumper) Pin 1 AT/ATX mode select jumper Connector PN Vendor 220-96-03GB01 PINREX PH03N2-7BAN000 HORNGTONG Pin No. Definition AT MODE Detect ATX MODE Jumper setting 1-2 Close : AT mode. 2-3 Close : ATX mode.(Default setting) www.gigaipc.com... -
Page 37: Lvds (Lvds Connector)
2.2.15 LVDS (LVDS connector) Pin 1 LVDS Connector Pin No. Definition Pin No. Definition CLK2- CLK1- Pin No. Definition Pin No. Definition 3.3V 3.3V Connector PN Vendor 712-76-40GWE0 PINREX SPEC0 SPED0 A1252WV-SF-2X20PD01 JOINT-TECH CLK2+ CLK1+ www.gigaipc.com... -
Page 38: So-Dimm1, So-Dimm2 (2 X Ddr4 So-Dimm Slot)
2.2.16 SO-DIMM1, SO-DIMM2 (2 x DDR4 SO-DIMM Slot) www.gigaipc.com... -
Page 39: Sys_Panel (Front Panel Header)
2.2.17 SYS_PANEL (Front panel header) Pin 1 System Panel Header Connector PN Vendor 210-92-05GW5W PINREX Pin No. Definition HDD LED+ Power LED+ HDD LED- Power LED- Power Button+ Reset Button Power Button- No Connect No Pin www.gigaipc.com... -
Page 40: F_Usb2_1, F_Usb2_2 (Usb 2.0 Header)
2.2.18 F_USB2_1, F_USB2_2 (USB 2.0 header) Pin 1 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Pin No. Definition No Pin www.gigaipc.com... -
Page 41: Tpm_Spi (Trusted Platform Module Connector)
2.2.19 TPM_SPI (Trusted Platform Module Connector) Pin 1 TPM Module Connector Pin No. Definition SPI_CS Pin No. Definition Connector PN Vendor TPM_CLK 52S-90-14GB10 PINREX 3.3V TPM_RST BH14NQ-7BAI010 HORNGTONG 3.3V TPM_SO TPM_SI www.gigaipc.com... -
Page 42: Satapw0 (Sata Power Connector)
2.2.20 SATAPW0 (SATA power connector) Pin 1 Hard Disk Power Connector Connector PN Vendor 743-81-04TW00 PINREX WF04Q2-3BJQ000 HORNGTONG Pin No. Definition www.gigaipc.com... -
Page 43: Sata0 (Sata 6Gb/S Connector)
2.2.21 SATA0 (SATA 6Gb/s connector) Pin 1 SATA 6Gb/s Connector Connector PN Vendor WATF-07DBLBA1UW WINWIN Pin No. Definition www.gigaipc.com... -
Page 44: F_Usb3 (Usb 3.2 Gen 1 Header)
2.2.22 F_USB3 (USB 3.2 Gen 1 header) Pin 1 USB 3.2 Gen 1 Header Pin No. Definition P2_D+ P2_D- P2_TX+ P2_TX- Pin No. Definition P2_RX+ Power P2_RX- P1_RX- Power P1_RX+ No Pin Connector PN Vendor P1_TX- P1_TX+ 52X-80-20GU65 PINREX WUIR-19A9N4BU3W WINWIN P1_D- P1_D+ www.gigaipc.com... -
Page 45: Spkr (Speaker Out Connector)
2.2.23 SPKR (Speaker out connector) Pin 1 Speaker out Connector Connector PN Vendor 721-81-045W00 PINREX A2001WV-04P146 JOINT-TECH Pin No. Definition Speaker Out L+ Speaker Out L- Speaker Out R- Speaker Out R+ www.gigaipc.com... -
Page 46: Fp_Audio (Front Panel Audio Header)
2.2.24 FP_AUDIO (Front panel audio header) Pin 1 Front Audio Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Definition Pin Definition MIC_Left FAUDIO_JD MIC_Right No Connect Detect HPOUT_Left HPOUT_ Right www.gigaipc.com... -
Page 47: Mpcie (Mini Pcie Connector)
Pin No. Definition Pin No. Definition USB Dp PCIE WAKE 3.3V 3.3V 3.3V PCIE Clock SIM PWR Request SIM DATA PCIE Clock n SIM Clock PCIE Clock p SIM Reset 3.3V UIM VPP3 Connector PN Vendor WLAN_DISABLE AS0B221-S99Q-7H FOXCONN Reset www.gigaipc.com... -
Page 48: M2E (M.2 Slot, E-Key, Support Ngff-2230)
PCIE CLOCKp PCIE CLOCKn SUSCLK Pin No. Definition Pin No. Definition PCIE Clock PCIRST 3.3V Request 3.3V PCIE wake up BT_Disable WLAN_DISABLE 3.3V 3.3V Pin No. Definition Pin No. Definition Connector PN Vendor 80152-8521 BELLWETHER PCIE_TXp APCI0095-P002A LOTES PCIE_TXn CL_RST www.gigaipc.com... -
Page 49: Edp (Embedded Display Port Connector)
Embedded Display Port connector Pin No. Definition Pin No. Definition 3.3V TX3n TX3p Pin No. Definition Pin No. Definition AUXn AUXp Hot Plug TX0n Detect Connector PN Vendor Backlight TX0p Enable 115B30-000040-G4-R STARCONN Backlight TX1n controll TX1p 3.3V TX2n 3.3V TX2p 3.3V www.gigaipc.com... -
Page 50: M2M (M.2 Slot, M-Key, Support Ngff-2280)
PCIE Clock Request PCIE Clock n PCIe Wake# SSD LED PCIE Clock p 3.3V 3.3V 3.3V Pin No. Definition Pin No. Definition 3.3V SUSCLK Detect 3.3V 3.3V 3.3V Connector PN Vendor PCIE1 RXn PCIE1 RXp 2E0BC41-C85CM-LH FOXCONN PCIE2 TXn www.gigaipc.com... -
Page 51: Lsw (Lvds Resolution Jumper)
1024 x 600 1600 x 900 18bit 24bit 1280 x 800 1680 x 1050 18bit 24bit 1280 x 960 1600 x 1200 18bit 24bit 1280 x 1024 1920 x 1080 24bit 24bit 1366 x 768 1920 x 1200 18bit 24bit www.gigaipc.com... -
Page 52: Bkl_Lvds (Backlight Control Header For Lvds)
2.2.30 BKL_LVDS (Backlight Control header for LVDS) Pin 1 Backlight control connector Connector PN Vendor 721-81-05TW00 PINREX A2001WV-05P146 JOINT-TECH Pin No. Definition Backlight Enable www.gigaipc.com... -
Page 53: Me (Me Enable Jumper)
2.2.31 ME (ME Enable Jumper) Pin 1 ME Enable Jumper ME Enable Jumper Enable Disable www.gigaipc.com... -
Page 54: Chapter 3 - Bios
Chapter 3 Chapter 3 – BIOS www.gigaipc.com... -
Page 55: Introduction
Execute command or enter the submenu Increase the numeric value or make ＋ changes Decrease the numeric value or make – changes General Help Previous Values Load Optimized Defaults Settings Save changes & Exit the BIOS Setup program Exit the BIOS Setup program www.gigaipc.com... -
Page 56: The Main Menu
ME FW version Shows ME firmware version Set the Date for the system System Date (Format : Week - Month - Day - Year) Set the time for the system System Time (Format : Hour - Minute - Second) www.gigaipc.com... -
Page 57: Advanced
Advanced The Advanced menu is to configure the functions of hardware settings through submenu. Use arrow keys to move among the items, and press <Enter> to access into the related submenu. www.gigaipc.com... -
Page 58: Tpm Configuration
3.3.1 TPM Configuration Use TPM Configuration submenu to choose TPM interface. Item Description PTT : Internal TPM (Default setting) TPM Device dTPM : External TPM (When using External TPM module or Selection having TPM chip on MB) www.gigaipc.com... - Page 59 Item Description Security Device Enabled : Enables TPM feature (Default setting) support Disabled : Disables TPM feature Item Description None : No execution will be conducted (Default setting) Pending operation TPM clear : Set to clear data on TPM www.gigaipc.com...
-
Page 60: Sata And Rst Configuration
Intel VMD feature helps you to control and manage NVMe PCIe SSD. / Enable VMD Enabled : Enables Intel VMD feature controller Disabled : Disables Intel VMD feature (Default setting) Serial ATA Port 0 shows 2.5" SATA HDD/SSD information shows M.2 SATA interface SSD information www.gigaipc.com... -
Page 61: Cpu Configuration
To speed up CPU frequency transition time from basic frequency to maximum frequency. Intel(R) Speed Enabled : Enables Intel(R) Speed Shift Technology Interrupt control (Default Shift Technology setting) Interrupt control Disabled : Disables Intel(R) Speed Shift Technology Interrupt control www.gigaipc.com... -
Page 62: It8786 Super Io Configuration
Disabled : if Disabled, displays no configuration for the serial port Device settings : Serial Port 3 Display the specified Serial Port base I/O address and IRQ Configuration COM Port Mode : Serial Port 4 Choose RS-232, RS-422, or RS-485 feature Configuration www.gigaipc.com... -
Page 63: Hardware Monitor
Normal : Fan speed set by BIOS default (Default setting) Control Full Speed : Set Fan operates at full speed CPU temperature Shows current CPU temperature System Shows current system temperature temperature CPU Fan Speed Shows current CPU fan Speed SYS Fan Speed Shows current System fan Speed www.gigaipc.com... -
Page 64: S5 Rtc Wake Settings
Enable or Disable System to wake on a specific time. Wake system Disabled : Disables system to wake on a specific time (Default setting) from S5 Fixed Time : Enables system to wake on a specific time (Format : hr : min : sec) www.gigaipc.com... -
Page 65: Network Stack Configuration
When Network stack is enabled : Ipv4 PXE Support Disabled : Disables Ipv4 PXE Support Enabled : Enables Ipv4 PXE Support When Network stack is enabled : Ipv6 PXE Support Disabled : Disables Ipv6 PXE Support Enabled : Enables Ipv6 PXE Support www.gigaipc.com... -
Page 66: Nvme Configuration
3.3.8 NVMe Configuration NVMe Configuration shows information when your M.2 NVMe PCIe SSD is installed. www.gigaipc.com... -
Page 67: Offboard Sata Controller Configuration
3.3.9 Offboard SATA Controller Configuration www.gigaipc.com... -
Page 68: Digital Io Port Configuration
Enabled : If Digital IO Output value/level is modified in OS, they will be memorized and kept. SOGPO_1 (Pin 1) SOGPI_1 (Pin 2) SOGPO_2 (Pin 3) SOGPI_2 (Pin 4) Configure Digital IO Input or Output values for each pin. SOGPO_3 (Pin 5) SOGPI_3 (Pin 6) SOGPO_4 (Pin 7) SOGPI_4 (Pin 8) www.gigaipc.com... -
Page 69: Chipset
Power on : System power on when the power is back Loss Power off : Do not power on when the power is back (Default setting) Last state : Restore the system to the state before power loss occures www.gigaipc.com... - Page 70 Enabled : Enables WWAN Firmware Flash Device function Flash Device Disabled : Disables WWAN Firmware Flash Device function (Default setting) Enable/Disable BIOS Lock function BIOS Lock Enabled : Enables BIOS Lock function (Default setting) Disabled : Disabled BIOS Lock funtion www.gigaipc.com...
-
Page 71: Security
To set up Administrator's password Administrator Minimum length : 3 Password Maximum length : 20 To set up User's password User Password Minimum length : 3 Maximum length : 20 Secure Boot Press <Enter> to configure the advanced items www.gigaipc.com... - Page 72 No : Cancel to restore factory settings Reset To Setup Yes : Agree to setup mode Mode No : Cancel to setup mode Enables expert users to modify Secure boot policy variables without full Key Management authentication Press <Enter> to configure the advanced items www.gigaipc.com...
- Page 73 'UEFI CA' from database from DB No : Cancel to remove 'UEFI CA' from database Restore DB variables to fac tor y Restore DB defaults defaults Yes : Agree to restore DB defaults No : Cancel to restore DB defaults www.gigaipc.com...
-
Page 74: Boot
Enabled : Enables Full screen LOGO Show on POST screen LOGO Show Disabled : Disables Full screen LOGO Show on POST screen (Default setting) Boot Option #1 Shows the information of the storage that be installed in the system Boot Option #2 Choose/set the boot priority www.gigaipc.com... -
Page 75: Save & Exit
Yes : Agree to load optimized defaults No : Cancel to load optimized defaults Enable/Disable Me FW image re-flash function Me FW Image Enabled : Enables Me FW image re-flash function Re-Flahs Disabled : Disables Me FW image re-flash function (Default setting) www.gigaipc.com...
