Summary of Contents for GIGAIPC iTXL-Q47EA
-
Page 1: Thin Mini-Itx Motherboard
(MQ47EAT-SI) Thin Mini-ITX Motherboard User’s Manual 1st Ed www.gigaipc.com... -
Page 2: Copyright Notice
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. -
Page 3: Acknowledgement
Core, Atom are trademarks of Intel Corporation • • ITE is a trademark of Integrated Technology Express, Inc. IBM, PC/AT, PS/2, and VGA are trademarks of International Business • Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com... -
Page 4: Packing List
Before setting up your product, please make sure the following items have been shipped: Item Quantity iTXL-Q47EA MB SATA power cable I/O Bracket If any of these items are missing or damaged, please contact your distributor or sales representative immediately. -
Page 5: About This Document
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: Safety Precautions
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... - Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
-
Page 8: Fcc Statement
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com... -
Page 9: China Rohs Requirements (Cn)
China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 GIGAIPC Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 及其电 ○ ○ ○ ○ ○ ○ 子组件 外部信号 连接器 ○ ○ ○ ○... -
Page 10: China Rohs Requirement (En)
China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products GIGAIPC Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &... -
Page 11: Table Of Contents
Battery (Battery Connector) ......... 26 2.2.6 FP_Audio (Front Panel Audio Header) ......27 2.2.7 SPKR (Speaker Out Connector) ........28 2.2.8 M2E (M.2 Slot, E-Key, Supports NGFF-2230) ....29 2.2.9 PCIEX8 (1 x PCIe x16 (Gen3 x8 bus) slot) ....... 29 www.gigaipc.com... - Page 12 2.2.26 SATA_PWR1, SATA_PWR2 (SATA Power Connector x 2) ..................46 2.2.27 CLR_CMOS (Clear CMOS Jumper) ......... 47 2.2.28 SODIMM1, SODIMM2 (2 x DDR4 SO-DIMM Sockets) ... 48 2.2.29 M2M (M.2 Slot, M-Key, SATA 6Gb/s, Supports NGFF- 2280 Cards) ..............48 www.gigaipc.com...
-
Page 13: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 14 www.gigaipc.com...
-
Page 15: Specifications
Specifications Motherboard iTXL-Q47EA (MQ47EAT-SI) Thin Mini-ITX form factor Form Factor 170W x 170D (mm) Support for 10th Generation Intel® Core™ i9/i7/i5/i3 processors, Pentium® & Celeron® processors in the LGA1200 package TDP under 65W L3 cache varies with CPU Socket LGA 1200 Chipset Intel®... - Page 16 Motherboard iTXL-Q47EA (MQ47EAT-SI) 1 x 4-pin ATX main power connector 4 x SATA 6Gb/s connectors 6 x USB 2.0 headers 1 x Front panel header 1 x Front panel audio header 1 x 2W Speaker out header 1 x LVDS connector...
-
Page 17: Chapter 2 - Hardware Information
Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com... -
Page 18: Jumpers And Connectors
Jumpers and Connectors 19 20 www.gigaipc.com... - Page 19 ATX 2x2 Pin Power Connector USB31_1, USB 3.2 Gen 1 Type A Connector x 4 USB31_2, LAN1, LAN2 GbE Eternet LAN ports x 2 HDMI 2 HDMI 2.0 Connector Display Port Connector LINE_OUT Line Out port (Green) MIC_IN Mic In port (Pink) www.gigaipc.com...
- Page 20 General purpose input/out Connector COM1 COM header RS232/422/485 & 5V/12V/RI JCOM1 COM1 RI# pin RI#/5V/12V Select AT/ATX power mode select jumper AT_CN COM header RS232 COM2 FUSB2_3 USB 2.0 Header ATX Control Header, Support PS-ON Signal of ATX_CTL Power Supply Unit www.gigaipc.com...
- Page 21 Code Description SATA_PWR1 SATA Power Connector x 2 SATA_PWR2 CLR_CMOS Clear CMOS Jumper SODIMM1, 2 x DDR4 SO-DIMM Sockets SODIMM2 M.2 Slot, M-Key, SATA 6Gb/s & PCIe, Supports NGFF-2280 Card www.gigaipc.com...
-
Page 22: Io Connector Information
DC In Jack USB31_1, USB 3.2 Gen 1 Type A Connector x 4 USB31_2, LAN1, LAN2 GbE Eternet LAN port x 2 HDMI 2 HDMI 2.0 Connector Display Port Connector LINE_OUT Line Out port (Green) MIC_IN Mic In port (Pink) www.gigaipc.com... -
Page 23: Dc_In (Dc In Jack)
2.2.2 DC_IN (DC In Jack) DC In Jack Connector PN Vendor 655-360-000 SHEN-MING www.gigaipc.com... -
Page 24: Dc_In2 (Atx 1X4 Pin Power Connector)
2.2.3 DC_IN2 (ATX 1x4 Pin Power Connector) Pin 1 Power Connector Connector PN Vendor 740-81-04TW56 PINREX Pin No. Definition DC IN DC IN www.gigaipc.com... -
Page 25: Sata2, 3, 4, 5 (Sata 6 Gb/S Connector)
2.2.4 SATA2, 3, 4, 5 (SATA 6 Gb/s Connector) SATA 2 SATA 3 SATA 5 SATA 4 SATA 6GB/S Connector Pin No. Definition SATA 0 SATA 1 SATA 2 SATA 3 www.gigaipc.com... -
Page 26: Battery (Battery Connector)
2.2.5 Battery (Battery Connector) Pin 1 Battery Connector Pin No. Definition www.gigaipc.com... -
Page 27: Fp_Audio (Front Panel Audio Header)
2.2.6 FP_Audio (Front Panel Audio Header) Pin 1 Front Audio Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Definition Definition MIC-LEFT JACKSENCE DELTECT MIC-RIGHT DELTECT LINE-LEFT LINE-RIGHT www.gigaipc.com... -
Page 28: Spkr (Speaker Out Connector)
2.2.7 SPKR (Speaker Out Connector) Pin 1 Speaker Out Connector Connector PN Vendor 721-81-045W00 PINREX A2001WV-04P146 JOINT-TECH Pin No. Definition SPEAKER L+ SPEAKER L- SPEAKER R- SPEAKER R+ www.gigaipc.com... -
Page 29: M2E (M.2 Slot, E-Key, Supports Ngff-2230)
2.2.8 M2E (M.2 Slot, E-Key, Supports NGFF-2230) 2.2.9 PCIEX8 (1 x PCIe x16 (Gen3 x8 bus) slot) www.gigaipc.com... -
Page 30: Cpu_Fan (Cpu Fan Connector)
2.2.10 CPU_FAN (CPU FAN Connector) Pin 1 CPU Fan Connector Connector PN Vendor 744-81-045W11 PINREX Pin No. Definition Sense www.gigaipc.com... -
Page 31: Fusb2_2 (Usb 2.0 Header)
2.2.11 FUSB2_2 (USB 2.0 Header) Pin 1 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX 2 4 6 8 10 PH10R53BAZ009 HORNGTONG 1 3 5 7 9 Pin No. Definition No Pin www.gigaipc.com... -
Page 32: Fusb2_1 (Usb 2.0 Header)
2.2.12 FUSB2_1 (USB 2.0 Header) Pin 1 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX 2 4 6 8 10 PH10R53BAZ009 HORNGTONG 1 3 5 7 9 Pin No. Definition No Pin www.gigaipc.com... -
Page 33: Sys_Fan (System Fan Connector)
2.2.13 SYS_FAN (System Fan Connector) Pin 1 System FAN Connector PN Vendor 744-81-045R11 PINREX WF04R22RJQ105 HORNGTONG Pin No. Definition www.gigaipc.com... -
Page 34: Lsw (Lvds Resolution Jumper)
1024 x 600 1600 x 900 18bit 24bit 1280 x 800 1680 x 1050 18bit 24bit 1280 x 960 1600 x 1200 18bit 24bit 1280 x 1024 1920 x 1080 24bit 24bit 1366 x 768 1920 x 1200 18bit 24bit www.gigaipc.com... -
Page 35: Edp (Embedded Display Port Connector)
Embedded Display Port connector Pin No. Definition Pin No. Definition 3.3V TX3n TX3p AUXn Pin No. Definition Pin No. Definition AUXp Connector PN Vendor Hot Plug TX0n 115B30-000040-G4-R STARCONN Detect Backlight TX0p Enable Backlight TX1n controll TX1p 3.3V TX2n 3.3V TX2p 3.3V www.gigaipc.com... -
Page 36: Bkl_Cn (Back Light Brightness Control Connector)
2.2.16 BKL_CN (Back Light Brightness Control Connector) Pin 1 Back Light Brightness Control Connector PN Vendor Connector 721-81-05TW00 PINREX A2001WV-05P146 JOINT-TECH Pin No. Definition Backlight enable www.gigaipc.com... -
Page 37: Lvds (Lvds Connector)
But below model no need to add. SPED0 A0~A3 is odd channel 0~3, A4~A7 is ev en channel. Note: *The LVDS output connector of the unit is only intended to be CLK2+ connected to an UL/IEC/EN approval CLK1+ equipment with fire enclosure. CLK2- CLK1- www.gigaipc.com... -
Page 38: Sys_Panel (System Panel Header)
2.2.18 SYS_PANEL (System Panel Header) Pin 1 System Panel Header Connector PN Vendor 210-92-05G111 PINREX 210-92-05GW5W PINREX Pin No. Definition HD-P MPD-P HD-N MPD-N POWER-ON Reset Reserved www.gigaipc.com... -
Page 39: Gpio_Cnt (General Purpose Input/Output Connector)
2.2.19 GPIO_CNT (General purpose input/output Connector) Pin 1 GPIO Connector Pin No. Definition GPIO-input_4 SMBus Clock SMBus DATA Pin No. Definition Connector PN Vendor GPIO-output_1 725-81-12TW00 PINREX GPIO-input_1 A2004WV-2X06P46 JOINT-TECH GPIO-output_2 GPIO-input_2 GPIO-output_3 GPIO-input_3 GPIO-output_4 www.gigaipc.com... -
Page 40: Com1 (Com Header Rs232/422/485 & 5V/12V/Ri)
2.2.20 COM1 (COM header RS232/422/485 & 5V/12V/RI) Pin 1 COM1 Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Pin No. Definition www.gigaipc.com... -
Page 41: Jcom1 (Com1 Ri# Pin Ri#/5V/12V Select)
2.2.21 JCOM1 (COM1 RI# pin RI#/5V/12V Select) Pin 1 JCOM1 Jumper Select Connector PN Vendor 220-97-03GB01 PINREX 1-2 Close: PH06N53BAZ000 HORNGTONG 5V (Power COM) 3-4 Close: RI (Stand COM) 5-6 Close: 12V (Power COM) www.gigaipc.com... -
Page 42: At_Cn (At/Atx Power Mode Select Jumper)
2.2.22 AT_CN (AT/ATX power mode select jumper) Pin 1 AT/ATX power mode select jumper Connector PN Vendor PH03N33BAAA00 HORNGTONG Pin No. Definition AT MODE Detect ATX MODE Jumper setting 1-2 Close : AT mode. 2-3 Close : ATX mode.(Default setting) www.gigaipc.com... -
Page 43: Com2 (Rs232 Seriel Port Header)
2.2.23 COM2 (RS232 Seriel Port Header) Pin 1 COM 2 Header Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Pin No. Definition www.gigaipc.com... -
Page 44: Fusb2_3 (Usb 2.0 Header)
2.2.24 FUSB2_3 (USB 2.0 Header) Pin 1 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Pin No. Definition No Pin www.gigaipc.com... -
Page 45: Atx_Ctl (Atx Control Header, Support Ps-On Signal Of Power Supply Unit)
2.2.25 ATX_CTL (ATX Control Header, Support PS-ON Signal of Power Supply Unit) Pin 1 ATX Control Header Connector PN Vendor 744-81-02TW10 PINREX Pin No. Definition PSON# www.gigaipc.com... -
Page 46: Sata_Pwr1, Sata_Pwr2 (Sata Power Connector X 2)
2.2.26 SATA_PWR1, SATA_PWR2 (SATA Power Connector x 2) Pin 1 SATA Power Connector Connector PN Vendor 743-81-04TW00 PINREX WF04Q2-3BJQ000 HORNGTONG Pin No. Definition www.gigaipc.com... -
Page 47: Clr_Cmos (Clear Cmos Jumper)
2.2.27 CLR_CMOS (Clear CMOS Jumper) Pin 1 Clear COMS Jumper Pin No. Definition Clear CMOS Open: Normal Operation (Default setting) Close: Clear COMS data. www.gigaipc.com... -
Page 48: Sodimm1, Sodimm2 (2 X Ddr4 So-Dimm Sockets)
2.2.28 SODIMM1, SODIMM2 (2 x DDR4 SO-DIMM Sockets) 2.2.29 M2M (M.2 Slot, M-Key, SATA 6Gb/s, Supports NGFF-2280 Cards) www.gigaipc.com...
