Page 1: Thin Mini-Itx Motherboard
Thin Mini-ITX Motherboard User’s Manual 1st Ed www.gigaipc.com... -
Page 2: Copyright Notice
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. -
Page 3: Acknowledgement
Core, Atom are trademarks of Intel Corporation • • ITE is a trademark of Integrated Technology Express, Inc. IBM, PC/AT, PS/2, and VGA are trademarks of International Business • Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com... -
Page 4: Packing List
Before setting up your product, please make sure the following items have been shipped: Item Quantity iTXL-5105A or iTXL-4500A MB SATA power cable I/O Shield If any of these items are missing or damaged, please contact your distributor or sales representative immediately. -
Page 5: About This Document
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: Safety Precautions
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... - Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
-
Page 8: Fcc Statement
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com... -
Page 9: China Rohs Requirements (Cn)
China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 GIGAIPC Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 及其电 ○ ○ ○ ○ ○ ○ 子组件 外部信号 连接器 ○ ○ ○ ○... -
Page 10: China Rohs Requirement (En)
China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products GIGAIPC Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &... -
Page 11: Table Of Contents
SYS_FAN (System fan connector) ......... 24 2.2.4 SODIMMA, SODIMMB (DDR4 SO-DIMM Slot) ....25 2.2.5 FUSB1, FUSB2, FUSB3 (USB 2.0 headers) ....26 2.2.6 SATA0 (SATA 6Gb/s connector) ........27 2.2.7 SATAPWR (SATA power connector) ....... 28 2.2.8 ME_DISABLE (ME Disable jumper) ......29 www.gigaipc.com... - Page 12 TPM Configuration ............48 3.3.2 SATA Configuration ............50 3.3.3 CPU Configuration ............51 3.3.4 Super I/O Configuration ..........52 3.3.5 Hardware Monitor ............53 3.3.6 S5 RTC Wake Settings ........... 54 3.3.7 AMI Graphic Output Protocol Policy ......55 www.gigaipc.com...
- Page 13 3.3.8 Network Stack Configuration ........56 3.3.9 Digital IO Port Configuration ........57 Chipset ................58 Security ................. 59 Boot ................62 Save & Exit ..............63 www.gigaipc.com...
-
Page 14: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 15 20.71 12.84 17.33 17.63 17.99 17.51 6.35 157.48 www.gigaipc.com...
-
Page 16: Specifications
Specifications Motherboard iTXL-5105A (MJPLNBT) iTXL-4500A (MJPLNAT) Thin Mini-ITX form factor Form Factor 170W x 170D (mm) Intel® Celeron® N5105 Intel® Celeron® N4500 Processor Processor 10nm, 4 cores, 4 threads, 10nm, 2 cores, 2 threads, up to 2.90 GHz up to 2.80 GHz... - Page 17 Motherboard iTXL-5105A (MJPLNBT) iTXL-4500A (MJPLNAT) 1 x 4-pin ATX main power connector 1 x ATX control header (For Standard ATX PSU use) 1 x SATA power connector 1 x System fan header 1 x Front panel header 1 x Front panel audio header...
-
Page 18: Chapter 2 - Hardware Information
Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com... -
Page 19: Jumpers And Connectors
Jumpers and Connectors www.gigaipc.com... - Page 20 PCIe x1 (Gen3 x1) Slot M.2 Slot, M-Key NGFF 2280 (SATA 6Gb/s) M.2 Slot, E-Key NGFF 2230 FP_AUDIO Front Audio connector SPKR Speaker out connector BKL_CN Back light brightness control header LVDS resolution jumper LVDS LVDS connector Embedded Display Port connector www.gigaipc.com...
-
Page 21: Rear I/O Connector
2.1.1 Rear I/O Connector Code Description DC_IN1 DC IN (12-24V) HDMI1 HDMI HDMI2 USB31_1 USB 3.2 Gen 1 USB31_2 LAN1 RJ45 LAN Ports LAN2 LINE_OUT Audio jacks (Line out) MIC_IN Audio jacks (Mic in) www.gigaipc.com... -
Page 22: Dc_In2 (Atx 2X2 Pin Power Connector)
2.2.1 DC_IN2 (ATX 2x2 pin power connector) Pin 1 Power Connector Connector PN Vendor 740-81-04TW56 PINREX Pin No. Definition +12V +12V www.gigaipc.com... -
Page 23: Atx_Ctl (Atx Control Header)
2.2.2 ATX_CTL (ATX control header) Pin 1 ATX control header Connector PN Vendor 744-81-02TW10 PINREX Pin No. Definition ATX_PS_ON# ATX_5VSB www.gigaipc.com... -
Page 24: Sys_Fan (System Fan Connector)
2.2.3 SYS_FAN (System fan connector) Pin 1 System FAN connector Connector PN Vendor 744-81-045W11 PINREX WF04R22WJQ195 HORNGTONG Pin No. Definition Detect Speed Control www.gigaipc.com... -
Page 25: Sodimma, Sodimmb (Ddr4 So-Dimm Slot)
2.2.4 SODIMMA, SODIMMB (DDR4 SO-DIMM Slot) www.gigaipc.com... -
Page 26: Fusb1, Fusb2, Fusb3 (Usb 2.0 Headers)
2.2.5 FUSB1, FUSB2, FUSB3 (USB 2.0 headers) Pin 1 USB 2.0 header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Pin No. Definition No Pin No Connect www.gigaipc.com... -
Page 27: Sata0 (Sata 6Gb/S Connector)
2.2.6 SATA0 (SATA 6Gb/s connector) SATA connector Connector PN Vendor WAT3M-07A1G3BU4W WINWIN ABA-SAT-054-S15 LOTES Pin No. Definition www.gigaipc.com... -
Page 28: Satapwr (Sata Power Connector)
2.2.7 SATAPWR (SATA power connector) Pin 1 Hard Disk Power Connector Connector PN Vendor 743-91-045W00 PINREX Pin No. Definition www.gigaipc.com... -
Page 29: Me_Disable (Me Disable Jumper)
2.2.8 ME_DISABLE (ME Disable jumper) Pin 1 ME Disable Connector ME Disable jumper Enable (Default) Disable Pin No. Definition 3.3V www.gigaipc.com... -
Page 30: Sys_Panel (Front Panel Header)
2.2.9 SYS_PANEL (Front panel header) Pin 1 System Panel Header Connector PN Vendor 210-92-05G111 PINREX Pin No. Definition HDD LED+ Power LED+ HDD LED- Power LED- Power Button+ Reset Button Power Button- No Connect No Pin www.gigaipc.com... -
Page 31: Gpio_Cnt (General Purpose Input/Output Header)
2.2.10 GPIO_CNT (General Purpose input/output header) Pin 1 GPIO Connector Pin No. Definition SMB_DATA Connector PN Vendor Pin No. Definition 725-81-12TW00 PINREX GPO1 A2004WV-2X06P46 JOINT-TECH GPI1 GPO2 GPI2 GPO3 GPI3 GPO4 GPI4 SMB_CLK www.gigaipc.com... -
Page 32: Com1, Com2, Com3, Com4 (Serial Port)
COM1 : Support RS232/422/485 & RI/5V/12V Full Duplex Half Duplex For RI/5V/12V jumper setting, please see P. 34 COM2, COM3, COM4 : Support RS232 only Data- Data+ – – – – – – – – – – No Connect – – RI/5V/12V – – www.gigaipc.com... -
Page 33: At_Cn (At/Atx Power Mode Select Jumper)
2.2.12 AT_CN (AT/ATX power mode select jumper) Pin 1 AT/ATX power mode select jumper Connector PN Vendor 220-96-03GB01 PINREX PH03N2-7BAN000 HORNGTONG Pin No. Definition AT MODE Detect ATX MODE Jumper setting 1-2 Close : AT mode. 2-3 Close : ATX mode.(Default setting) www.gigaipc.com... -
Page 34: Jcom1 (Com 1 Ri# Pin Ri#/5V/12V Select)
2.2.13 JCOM1 (COM 1 RI# pin RI#/5V/12V Select) Pin 1 JCOM1 Jumper Connector PN Vendor 220-97-03GB01 PINREX 1-2 Close: PH06N53BAZ000 HORNGTONG 5V (Power COM) 3-4 Close: RI (Stand COM) 5-6 Close: 12V (Power COM) www.gigaipc.com... -
Page 35: Pciex1 (Pcie X1 (Gen3 X1) Slot)
2.2.14 PCIEX1 (PCIe x1 (Gen3 x1) slot) PCIEX1 connector www.gigaipc.com... -
Page 36: M2M (M.2 Slot, M-Key Ngff 2280 (Sata 6Gb/S))
Pin No. Definition DEVSLP SATA_RXP SATA_RXN Pin No. Definition Pin No. Definition 3.3V SATA_TXN 3.3V SATA_TXP PLT_RST 3.3V 3.3V Pin No. Definition Pin No. Definition 3.3V SUSCLK 3.3V 3.3V 3.3V 3.3V Connector PN Vendor 80159-8521 BELLWETHER 2E0BC21-S85BM-7H FOXCONN APCI0096-P002A LOTES www.gigaipc.com... -
Page 37: M2E (M.2 Slot, E-Key Ngff 2230)
2.2.16 M2E (M.2 Slot, E-Key NGFF 2230) M.2 E Key Connector WLAN_RXP WLAN_RXN CLK_DP CLK_DN SUSCLK Pin No. Definition Pin No. Definition CLK_REQ PLT_RST# PCIE_WAKE BT_Disable# USB_D+ WIFI_Disable# USB_D- PERST Connector PN Vendor Pin No. Definition Pin No. Definition 2E0BC21-S85BE-7H FOXCONN 80152-8521 BELLWETHER WLAN_TXP WLAN_TXN www.gigaipc.com... -
Page 38: Fp_Audio (Front Audio Connector)
2.2.17 FP_AUDIO (Front audio connector) Pin 1 Front Audio Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Definition Pin Definition MIC_L FAUDIO_JD MIC_R No Connect Detect HPOUT_L HPOUT_R www.gigaipc.com... -
Page 39: Spkr (Speaker Out Connector)
2.2.18 SPKR (Speaker out connector) Pin 1 Audio Amplifie Connector Connector PN Vendor 721-81-045W00 PINREX A2001WV-04P146 JOINT-TECH Pin No. Definition Speaker Out L+ Speaker Out L- Speaker Out R- Speaker Out R+ www.gigaipc.com... -
Page 40: Bkl_Cn (Backlight Control Connector)
2.2.19 BKL_CN (Backlight control connector) Pin 1 Backlight control connector Connector PN Vendor 721-81-05TW00 PINREX A2001WV-05P146 JOINT-TECH Pin No. Definition Back Light Enable www.gigaipc.com... -
Page 41: Lsw (Lvds Resolution Jumper)
1024 x 600 1600 x 900 18bit 24bit 1280 x 800 1680 x 1050 18bit 24bit 1280 x 960 1600 x 1200 18bit 24bit 1280 x 1024 1920 x 1080 24bit 24bit 1366 x 768 1920 x 1200 18bit 24bit www.gigaipc.com... -
Page 42: Lvds (Lvds Connector)
2.2.21 LVDS (LVDS connector) Pin 1 LVDS Connector Pin No. Definition Pin No. Definition CLK1- Pin No. Definition Pin No. Definition 3.3V Connector PN Vendor 3.3V 712-76-40GWE0 PINREX SPEC0 A1252WV-SF-2X20PD01 JOINT-TECH SPED0 CLK2+ CLK1+ CLK2- www.gigaipc.com... -
Page 43: Edp (Embedded Display Port Connector)
2.2.22 EDP (Embedded Display Port Connector) Pin 1 Embedded Display Port connector Definition Definition 3.3V TX3N Definition Definition TX3P eDP SW AUXN TX0N Hot Plug Detect AUXP Backlight TX0P Enable Connector PN Vendor 115B30-000040-G4-R STARCONN Backlight TX1N control TX1P 3.3V TX2N 3.3V TX2P 3.3V www.gigaipc.com... -
Page 44: Chapter 3 - Bios
Chapter 3 Chapter 3 – BIOS www.gigaipc.com... -
Page 45: Introduction
Execute command or enter the submenu Increase the numeric value or make ＋ changes Decrease the numeric value or make – changes General Help Previous Values Load Optimized Defaults Settings Save changes & Exit the BIOS Setup program Exit the BIOS Setup program www.gigaipc.com... -
Page 46: The Main Menu
ME FW version Shows ME firmware version Set the Date for the system System Date (Format : Weekday - Month - Day - Year) Set the time for the system System Time (Format : Hour - Minute - Second) www.gigaipc.com... -
Page 47: Advanced
Advanced The Advanced menu is to configure the functions of hardware settings through submenu. Use arrow keys to move among the items, and press <Enter> to access into the related submenu. www.gigaipc.com... -
Page 48: Tpm Configuration
3.3.1 TPM Configuration Use TPM Configuration submenu to choose TPM interface. Item Description PTT : Internal TPM (Default setting) TPM Device dTPM : External TPM (When using External TPM module or Selection having TPM chip on MB) www.gigaipc.com... - Page 49 Item Description Security Device Enabled : Enables TPM feature (Default setting) support Disabled : Disables TPM feature Item Description None : No execution will be conducted (Default setting) Pending operation TPM clear : Set to clear data on TPM www.gigaipc.com...
-
Page 50: Sata Configuration
3.3.2 SATA Configuration Item Description Serial ATA Port shows 2.5" SATA HDD/SSD information shows M.2 SATA interface SSD information www.gigaipc.com... -
Page 51: Cpu Configuration
To speed up CPU frequency transition time from basic frequency to maximum frequency. Intel(R) Speed Enabled : Enables Intel(R) Speed Shift Technology Interrupt control (Default Shift Technology setting) Interrupt control Disabled : Disables Intel(R) Speed Shift Technology Interrupt control www.gigaipc.com... -
Page 52: Super I/O Configuration
Enabled : Enables allows you to configure the serial port settings Serial Port 3 Disabled : if Disabled, displays no configuration for the serial port Configuration Device settings : Serial Port 4 Display the specified Serial Port base I/O address and IRQ Configuration www.gigaipc.com... -
Page 53: Hardware Monitor
Normal : Fan speed set by BIOS default (Default setting) Control Full Speed : Set Fan operates at full speed CPU temperature Shows current CPU temperature System Shows current system temperature temperature CPU Fan Speed Shows current CPU fan Speed SYS Fan Speed Shows current System fan Speed www.gigaipc.com... -
Page 54: S5 Rtc Wake Settings
Enable or Disable System to wake on a specific time. Wake system Disabled : Disables system to wake on a specific time (Default setting) from S5 Fixed Time : Enables system to wake on a specific time (Format : hr : min : sec) www.gigaipc.com... -
Page 55: Ami Graphic Output Protocol Policy
3.3.7 AMI Graphic Output Protocol Policy Item Description Choose default monitor output when there are more than one monitor plugged Output Select on the motherboard. www.gigaipc.com... -
Page 56: Network Stack Configuration
3.3.8 Network Stack Configuration Item Description When system is power on, install LAN driver under UEFI mode Network Stack Disabled : Disables UEFI Network Stack (Default setting) Enabled : Enables UEFI Network Stack www.gigaipc.com... -
Page 57: Digital Io Port Configuration
Enabled : If Digital IO Output value/level is modified in OS, they will be memorized and kept. SOGPO_1 (Pin 1) SOGPI_1 (Pin 2) SOGPO_2 (Pin 3) SOGPI_2 (Pin 4) Configure Digital IO Input or Output values for each pin. SOGPO_3 (Pin 5) SOGPI_3 (Pin 6) SOGPO_4 (Pin 7) SOGPI_4 (Pin 8) www.gigaipc.com... -
Page 58: Chipset
Enable/Disable XHCI Hand-off function XHCI Hand-off Enabled : Enables XHCI Hand-off function (Default setting) Disabled : Disables XHCI Hand-off function Enable/Disable BIOS Lock function BIOS Lock Enabled : Enables BIOS Lock function (Default setting) Disabled : Disabled BIOS Lock funtion www.gigaipc.com... -
Page 59: Security
To set up Administrator's password Administrator Minimum length : 3 Password Maximum length : 20 To set up User's password User Password Minimum length : 3 Maximum length : 20 Secure Boot Press <Enter> to configure the advanced items www.gigaipc.com... - Page 60 No : Cancel to restore factory settings Reset To Setup Yes : Agree to setup mode Mode No : Cancel to setup mode Enables expert users to modify Secure boot policy variables without full Key Management authentication Press <Enter> to configure the advanced items www.gigaipc.com...
- Page 61 'UEFI CA' from database from DB No : Cancel to remove 'UEFI CA' from database Restore DB variables to fac tor y Restore DB defaults defaults Yes : Agree to restore DB defaults No : Cancel to restore DB defaults www.gigaipc.com...
-
Page 62: Boot
Enabled : Enables Full screen LOGO Show on POST screen LOGO Show Disabled : Disables Full screen LOGO Show on POST screen (Default setting) Shows the information of the storage that be installed in the system Boot Option #1 Choose/set the boot priority www.gigaipc.com... -
Page 63: Save & Exit
Yes : Agree to load optimized defaults No : Cancel to load optimized defaults Enable/Disable Me FW image re-flash function Me FW Image Enabled : Enables Me FW image re-flash function Re-Flahs Disabled : Disables Me FW image re-flash function (Default setting) www.gigaipc.com...
