GIGAIPC uATX-Q47EA Owner's Manual

Micro-atx motherboard
Hide thumbs Also See for uATX-Q47EA:

Advertisement

Quick Links

Download this manual
uATX-Q47EA (MQ47EAM)
Micro-ATX Motherboard
User's Manual 1st Ed
1
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

Advertisement

loading
Need help?

Need help?

Do you have a question about the uATX-Q47EA and is the answer not in the manual?

Questions and answers

Related Manuals for GIGAIPC uATX-Q47EA

Summary of Contents for GIGAIPC uATX-Q47EA

  • Page 1 (MQ47EAM) Micro-ATX Motherboard User’s Manual 1st Ed www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 2 GIGAIPC reserves the right to make changes in the product design without notice to its users. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 3 IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 4 Quantity uATX-Q47EA (MQ47EAM) IO Shield CABLE SATA If any of these items are missing or damaged, please contact your distributor or sales representative immediately. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 5 (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 6 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 8 Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 9 ○ 及其电子组件 外部信号 ○ ○ ○ ○ ○ ○ 连接器及线材 O： 表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T 11363-2006 标准规定的限量要求以下。 X： 表示该有毒有害物质至少在该部件的 某一均质材料中的含量超出 SJ/T 11363-2006 标准规定的限量要求。 备注： 此产品所标示之环保使用期限， 系指在一般正常使用状况下。 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 10 SJ/T 11363-2006-stipulated requirement. Note: The Environment Friendly Use Period as labeled on this product is applicable under normal usage only www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 11 F_PANEL (Front panel header) ......... 25 2.2.5 CLR_CMOS (Clear CMOS jumper) ........26 2.2.6 ME_EN (ME Enable jumper) ..........27 2.2.7 FUSB2_1, F_USB2_2 (USB 2.0 header) ......28 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 12 (USB + LAN Connector) ..........48 2.2.27 USB20 (USB 2.0 Connector) ........... 49 Chapter 3 – BIOS Introduction ..............51 The Main Menu..............52 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 13 3.3.10 Offboard SATA Controller Configuration ......63 3.3.11 Digital IO Port Configuration ........... 64 Chipset ................65 Security ................67 Boot .................. 70 Save & Exit ............... 71 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 14 Chapter 1 Chapter1 - Product Specifications www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 15 20.08 20.08 43.32 43.32 66.91 66.91 90.48 90.48 114.04 114.04 135.86 135.86 243.84 243.84 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 16 1 x PCIe x1 (Gen3 x1) 1 x 2230 M.2 E-Key (PCIe x1 + USB 2.0) 1 x 2280/2242 M.2 M-Key (PCIe x4, SATA 6Gb/s) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 17 OS Compatibility Windows 10 (x64) Operating temperature: 0°C to 60°C Operating humidity: 0-90% (non-condensing) Operating Properties Non-operating temperature: -40°C to 85°C Non-operating humidity: 0%-95% (non-condensing) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 18 Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 19 Jumpers and Connectors www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 20 VGA header ATX_12V 8-pin ATX 12V power connector (for CPU) DDR4_1, DDR4_2 DDR4 DIMM Sockets x 4 DDR4_3, DDR4_4 ATX_SEL AT/ATX mode select jumper www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 21 2 x USB 3.2 Gen 1 (bottom) 1 x RJ45 LAN Port (top) USB31_LAN1 2 x USB 3.2 Gen 1 (bottom) USB20 4 x USB 2.0 Ports www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 22 Connector PN Vendor 740-41-24TW46 PINREX ABA-POW-013-K08 LOTES Pin No. Definition Pin No. Definition 3.3V 3.3V 3.3V -12V PS_ON Power Good 5VSB +12V +12V 3.3V www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 23 SYS_FAN, CPU_FAN (Fan connector) PIN 1 PIN 1 System FAN Connector Connector PN Vendor 744-81-045R11 PINREX WF04R22RJQ105 HORNGTONG Pin No. Definition Detect Speed Control www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 24 2.2.3 SATA2, SATA3, SATA4, SATA5 (SATA 6Gb/s Connector) SATA 6Gb/s Connector Connector PN Vendor WATM-07ABNB2BAUW3 WINWIN 770-83-07SW19 PINREX Pin No. Definition www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 25 PINREX PH10R53BAZ010 HORNGTONG Pin No. Definition HDD LED+ Power LED+ HDD LED- Power LED- Power button+ Reset button Power button- No connect No pin www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 26 2.2.5 CLR_CMOS (Clear CMOS jumper) PIN 1 Clear CMOS connector Connector PN Vendor 210-91-02GBK2 PINREX PH02R23BAZE11 HORNGTONG Clear CMOS Jumper Disable Enable www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 27 2.2.6 ME_EN (ME Enable jumper) PIN 1 ME Enable connector Connector PN Vendor 210-91-02GBK2 PINREX PH02R23BAZE11 HORNGTONG ME Enable Jumper Enable Disable www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 28 2.2.7 FUSB2_1, F_USB2_2 (USB 2.0 header) PIN 1 USB2.0 Header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Pin No. Definition No Pin No Connect www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 29 COM3, COM4 : Support RS-232 only TXD+ TXD- RXD- – RXD+ – – – – – – – – – No Connect – – – – www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 30 Choose “IT8786 Super IO Configuration” Step 3 : Step 4 : Select “Serial Port 1 Configuration” Choose “COM Port Mode” for RS-422, RS-485 function setting www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 31 Connector PN Vendor 210-92-03GB01 PINREX PH06R53BAZ000 HORNGTONG JCOM1, JCOM2 Jumper 1-2 Close: 5V (Power COM) 3-4 Close: RI (Stand COM) 5-6 Close: 12V (Power COM) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 32 GPIO header Connector PN Vendor 725-81-12TW00 PINREX A2004WV-2X06P46 JOINT-TECH Pin No. Definition GPIO-output_1 GPIO-input_1 GPIO-output_2 GPIO-input_2 GPIO-output_3 GPIO-input_3 GPIO-output_4 GPIO-input_4 SMBus Clock SMBus DATA www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 33 2.2.11 FP_AUDIO (Front panel audio header) PIN 1 Front panel audio header Connector PN Vendor 210-92-05GE05 PINREX Pin No. Definition MIC_LEFT MIC_RIGHT Detect LINE_RIGHT JACKSENSE Detect No connect LINE_LEFT www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 34 TPM header Connector PN Vendor 52M-90-14GBE7 PINREX Pin No. Definition LPCCLK 3.3V PFM RST VCC3 LAD0 IRQ_SERIAL LAD1 TPM_DET LAD2 No connect LAD3 LFRAME www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 35 PCIE wake up BT_Disable 3.3V WLAN_Disable 3.3V 3.3V Connector PN Vendor Pin No. Definition Pin No. Definition 2E0BC21-S85BE-7H FOXCONN 80152-8521 BELLWETHER PCIE_TXp PCIE_TXn CL_Reset www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 36 PCIE2 RXp Detect 3.3V 3.3V PCIE2 TXn 3.3V PCIE2 TXp PCIE1 RXn Connector PN Vendor PCIE1 RXp 80159-8521 BELLWETHER APCI0096-P002A LOTES PCIE1 TXn AS0BC21-S85BM-7H FOXCONN www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 37 2.2.15 PCIEX4 (PCIe x4 (Gen3 x4) Slot) PCIe x4 connector www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 38 * Below are the possible configurations : PCIe x16 connector code name PCIEX16_A PCIEX16_B Config. 1 Signal at x16 Config. 2 Signal at x8 Signal at x8 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 39 2.2.17 PCIEX1 (PCIe x1 (Gen3 x1) Slot) PCIe x1 connector www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 40 A0~A3 is odd channel 0~3, A4~A7 is even channel. Note: *The LVDS output connector of the unit is only intended to be connected to an UL/IEC/EN approval equipment with fire enclosure. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 41 1280 x 960 1600 x 1200 18bit 24bit 1280 x 1024 1920 x 1080 24bit 24bit 1366 x 768 1920 x 1200 18bit 24bit www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 42 2.2.20 BKL_CN (Backlight Control connector) PIN 1 Backlight control Connector Connector PN Vendor 721-81-05TW00 PINREX A2001WV-05P146 JOINT-TECH Pin No. Definition Backlight Enable www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 43 2.2.21 VGA (VGA connector) PIN 1 VGA Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Pin No. Definition VSYNC HSYNC Green DDCSCL Blue DDCSDA www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 44 2.2.22 ATX_12V (8 pin ATX 12V power connector (for CPU)) PIN 1 ATX 12V Connector Connector PN Vendor 740-41-08TWIB PINREX 25114A0800B3-9LF ATRC Pin No. Definition +12V +12V +12V +12V www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 45 2.2.23 DDR4_1, DDR4_2, DDR4_3, DDR4_4 (DDR4 DIMM Sockets) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 46 PINREX PH03N2-7BAN000 HORNGTONG Pin No. Definition ATX MODE Detect AT MODE Jumper setting 1-2 Close : ATX mode.(Default setting) 2-3 Close : AT mode. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 47 TX3n CLKn TX0n TX2n TX1p TX1p AUXp TX1n TX1n TX2p AUXn TX0p Hot Plug Detect Hot Plug TX0n TX2n 3.3V Detect TX3p 3.3V CLKp www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 48 TX4- State Description USB3_RX1n USB3_RX2n Orange On 1Gbps data rate USB3_RX1p USB3_RX2p Green On 100Mbps data rate USB3_TX1n USB3_TX2n 10Mbps data rate USB3_TX1p USB3_TX2p www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 49 2.2.27 USB20 (USB 2.0 Connector) USB 2.0 Connector Pin No. Definition www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 50 Chapter 3 Chapter 3 – BIOS www.gigaipc.com...
  • Page 51 Execute command or enter the submenu Increase the numeric value or make ＋ changes Decrease the numeric value or make – changes General Help Previous Values Load Optimized Defaults Settings Save changes & Exit the BIOS Setup program Exit the BIOS Setup program www.gigaipc.com...
  • Page 52 ME FW version Shows ME firmware version Set the Date for the system System Date (Format : Week - Month - Day - Year) Set the time for the system System Time (Format : Hour - Minute - Second) www.gigaipc.com...
  • Page 53 Advanced The Advanced menu is to configure the functions of hardware settings through submenu. Use arrow keys to move among the items, and press <Enter> to access into the related submenu. www.gigaipc.com...
  • Page 54 Security Device Enabled : Enables TPM feature (Default setting) Support Disabled : Disables TPM feature Pending None : No execution will be conducted (Default setting) operation TPM clear : Set to clear data on TPM Physical Presence Spec Version www.gigaipc.com...
  • Page 55 Enabled : Enables allows you to configure the serial port settings Serial Port 3 Configuration Disabled : if Disabled, displays no configuration for the serial port Serial Port 4 Configuration Device settings : Display the specified Serial Port base I/O address and IRQ www.gigaipc.com...
  • Page 56 Normal : Fan speed set by BIOS default (Default setting) Control Full Speed : Set Fan operates at full speed System Shows current System temperature Temperature CPU Temperature Shows current CPU temperature CPU Fan Speed Shows current CPU fan Speed SYS Fan Speed Shows current System fan Speed www.gigaipc.com...
  • Page 57 Enable or Disable System to wake on a specific time. Wake system Disabled : Disables system to wake on a specific time (Default setting) from S5 Fixed Time : Enables system to wake on a specific time (Format : hr : min : sec) www.gigaipc.com...
  • Page 58 CPU P states Enabled : Enables CPU P states function Disabled : Disables CPU P states function (Default setting) To optimize CPU performance. Optimize Performance Enabled : Enables optimize performance function Disabled : Disables optimize performance function (Default setting) CFG Lock www.gigaipc.com...
  • Page 59 Item Description SATA Mode Set SATA controller to AHCI mode Selection M.2 SATA Port shows M.2 SSD information Serial ATA Port 2 Serial ATA Port 3 shows 2.5" SATA HDD/SSD information Serial ATA Port 4 Serial ATA Port 5 www.gigaipc.com...
  • Page 60 3.3.7 CSM Configuration Item Description When system is power on, install LAN driver under UEFI mode Network Stack Disabled : Disables UEFI Network Stack (Default setting) Enabled : Enables UEFI Network Stack www.gigaipc.com...
  • Page 61 3.3.8 AMI Graphic Output Protocol Policy Item Description Choose default monitor output when there are more than one monitor plugged Output Select on the motherboard. www.gigaipc.com...
  • Page 62 3.3.9 NVMe Configuration NVMe Configuration shows information when your M.2 NVMe PCIe SSD is installed. www.gigaipc.com...
  • Page 63 3.3.10 Offboard SATA Controller Configuration www.gigaipc.com...
  • Page 64 Enabled : If Digital IO Output value/level is modified in OS, they will be memorized and kept. SOGPO_1 (Pin 1) SOGPI_1 (Pin 2) SOGPO_2 (Pin 3) SOGPI_2 (Pin 4) Configure Digital IO Input or Output values for each pin. SOGPO_3 (Pin 5) SOGPI_3 (Pin 6) SOGPO_4 (Pin 7) SOGPI_4 (Pin 8) www.gigaipc.com...
  • Page 65 Enabled : Enables Above 4GB MMIO BIOS assignment function Disabled : Disables Above 4GB MMIO BIOS assignment function (Default setting) Enable/Disable onboard audio controller Onboard Audio Enabled : Enables onboard audio controller (Default setting) Disabled : Disables onboard audio controller www.gigaipc.com...
  • Page 66 Enable/Disable XHCI Hand-off function XHCI Hand-off Enabled : Enables XHCI Hand-off function (Default setting) Disabled : Disables XHCI Hand-off function Enable/Disable BIOS Lock function BIOS Lock Enabled : Enables BIOS Lock function (Default setting) Disabled : Disabled BIOS Lock funtion www.gigaipc.com...
  • Page 67 To set up Administrator's password Administrator Minimum length : 3 Password Maximum length : 20 To set up User's password User Password Minimum length : 3 Maximum length : 20 Secure Boot Press <Enter> to configure the advanced items www.gigaipc.com...
  • Page 68 No : Cancel to restore factory settings Reset To Setup Yes : Agree to setup mode Mode No : Cancel to setup mode Enables expert users to modify Secure boot policy variables without full Key Management authentication Press <Enter> to configure the advanced items www.gigaipc.com...
  • Page 69 'UEFI CA' from database from DB No : Cancel to remove 'UEFI CA' from database Restore DB variables to fac tor y Restore DB defaults defaults Yes : Agree to restore DB defaults No : Cancel to restore DB defaults www.gigaipc.com...
  • Page 70 Enabled : Enables Full screen LOGO Show on POST screen (Default setting) LOGO Show Disabled : Disables Full screen LOGO Show on POST screen Boot Option #1 Shows the information of the storage that be installed in the system Boot Option #2 Choose/set the boot priority www.gigaipc.com...
  • Page 71 Yes : Agree to load optimized defaults No : Cancel to load optimized defaults Enable/Disable Me FW image re-flash function Me FW Image Enabled : Enables Me FW image re-flash function Re-Flash Disabled : Disables Me FW image re-flash function (Default setting) www.gigaipc.com...
