11.7.9 Backboxes for the RAXN-LCD and RAXN-LCDG

Table 18 Backboxes for the RAXN-LCD(G)

Name Number of
annunciators and
audio modules it
holds
BB-1001D(R/S) 1
BB-1002D(R/S) 2
BB-1003D(R/S)
3
BB-1008D(R/S) 8
BB-1012D(R/S) 12
11.7.10 Weather-Protected Boxes

Table 19 Weather-Protected Boxes

Name Annunciators it
holds
BB-1001WP(R)A 1 RAM-1032TZDS-
CC
BB-1002WP(R)A 2 (RAM-1032TZDS-
CC and RAX-
1048TZDS-CC)
Dimensions
9"H x 12.75"W x 1.85"D
18"H x 12.75"W x 1.85"D
26.4"H x 12.75"W x
1.85"D
33"H x 22.5"W x 1.85"D
45"H x 22.5"W x 1.85"D
Dimensions
11 1/8"H x 12 15/16"W
x 3 1/2"D
17 15/16"H x 12 15/16"W
x 3 1/2"D
Hardware Layouts
Horizontal Vertical
distance distance
between between
mounting mounting
screws screws
9.95" 7.50"
9.95" 16.5"
9.95" 24.90"
20.9" 35.2"
20.9" 52.0"
Horizontal Vertical
distance distance
between between
mounting mounting
screws screws
11" 9 1/2"
11" 16 5/16"
