Sending A Job To The Fire Alarm Control Panel; Figure 4 Send Job; Figure 5 The Job You Are About To Overwrite On The Panel Is Not Backed Up On The Local Database - Mircom FleX-Net BBX-1024DS Application Manual

6. Click Panel > Connect.
You are now connected to the Fire Alarm Control Panel.
2.2

Sending a Job to the Fire Alarm Control Panel

Send a job
1. Click Job > Open Job and open the job that you want to send.
2. In the Configurator, click Panel > Connect.
3. Click Panel > Send Job.
4. Select the nodes that you want to send the job to.
Figure 4
A window appears warning you that the job you are about to overwrite on the panel is not
backed up on the local database. This message only applies if you are sending the same
version of a job that is already on the panel.
Figure 5
5. Click Yes.
16
Working with the Fire Alarm Control Panel and the Configurator
Send Job
The job you are about to overwrite on the panel is not backed up on
the local database
