A.1
LAN1 / LAN2 pin definition with M12 connectors
LAN
M12-A-8P-F
LAN
A.2
RS-232 pin definition with M12 connector
RS-232
M12-A-8P-F
LAN
A.3
USB pin definition with M12 connector
USB
M12-A-8P-F
USB
SPC-XX40 User Manual
Pin Number
Signal
1
TX_D1+
2
TX_D1-
3
RX_D2+
4
BI_D3+
5
BI_D3-
6
RX_D2-
7
BI_D4+
8
BI_D4-
Pin Number
Signal
1
RXD
2
TXD
3
DTR
4
GND
5
DSR
6
RTS
7
CTS
8
Pin Number
Signal
1
6
3
5
Shielding
8
(Female)
CD
(Female)
Vcc
D-
D+
Vss
22
(Male)
