2.0 Functions and identifications
1. Handle
2. Lift/Lower
3. Emergency stop
4. Brake
5. User-Interface
6. Remote control
7. Box holder with clamps
8. Box holder without clamps
9. Name plate, serial number
10.Instrument board :
• Battery indicator
• Charging plug (internal or
external charger)
• Plug for extra equipment,
12V maximum 15 Amp
2
3
To release the brake:
1. Pull
2. Push
9
5
6
1
10
Released position
Braked position
4
7
8
5
