2.0 Functions and identifications
Clockwise/
counter-
clockwise
Lifting/Lowering
Emergency stop
To release the brake:
1. Pull
2. Push
Remote control
The remote control is used when:
• Rotating the forks
• Setting tilt stop in both directions: See paragraph 3.3.
• Setting rotation speed: See paragraph 3.4.
Released position
Braked position
Box holder
without clamps
Box holder with clamps
Instrument board
- Battery indicator
- Type plate
- Charging plug
(internal or external charger)
- Plug for extra equipment,
12V maximum 15 Amp
