2.0 Functions and identifications
Type plate
Maximum noise level < 70 dBA
Tel. +45 76 88 16 00 . info@logitrans.com . www.logitrans.com
Lifting / Lowering
Emergency stop
To release the brake
1. Pull
2. Push
Instrument board:
• Battery indicator
• Charging plug
• Plug for extra equipment,
Released
Braked position
(internal or external charger)
12V maximum 15 Amp
S612
5
