5 SPECIFICATIONS
This chapter contains SmartSwitch 9A100 ATM switch module firmware, hardware, technical, and physical
specifications.
5.1
FRONT PANEL
This section describes the LEDs of the SmartSwitch 9A100 ATM switch module (see Table 5-1). Figure A-1 illustrates
the front panel of the SmartSwitch 9A100 module.
Figure 5-1 SmartSwitch 9A100 front panel
Ejector
Reset Button
Console Terminal
(RJ-45)
Ejector
FAIL
STATUS
POWER
RX DATA
TX DATA
DATA
NO SYNC
Ethernet Port
(10Base-T)
SmartSwitch 9A100 Installation and Setup Guide 5-1
