Using the Console

Enter the
3.
backup switch
server and the full path and file name to the backup file. For example:
SmartSwitch # backup switch
ServerIP()
Path(public/Smart9A100.ztr)
SmartSwitch #
Depending upon whether your TFTP server is running in secure or non-secure
Note
mode, you may not need to specify
experience access violation errors, try leaving off
Note It's a good idea to backup the SmartSwitch 9A100 each time you make a
permanent or significant change to the switch's configuration.
Once the SmartSwitch 9A100 configuration is backed up, you can restore the configuration by entering the
command. For example:
switch
SmartSwitch # restore switch
ServerIP(206.61.237.40)
Path(tftpboot/backup/smart9A100.ztr)
Backup file is valid.
Restoring a backup file will completely replace any data stored in the flash, and requires a switch
reboot
Are you sure this is what you want to do?
Confirm(y/n)?:y
Restoration complete.
Rebooting is required to ensure correct operation,
Do you want to reboot now?
Confirm(y/n)?:y
3.2 USING THE CONSOLE
Use the SmartSwitch 9A100 console interface to configure and manage your switch. The following is a description of
the console interface and its operation.
3.2.1

Port Numbering

The SmartSwitch 9A100 is capable of containing both physical and virtual ports. The following conventions are used
for numbering ports on the SmartSwitch 9A100.
3-4 SmartSwitch 9A100 Installation and Setup Guide
command on the SmartSwitch 9A100. Specify the IP address of the TFTP
: 206.61.237.40
: /tftpboot/backup.ztr
: — Remembers last IP address entered
: — Remembers last path and file name entered
— Yes, restore the configuration
— Yes, reboot the switch
— IP address of the backup TFTP server
— full path and file name
in the path to the backup file. If you
/tftpboot
/tftpboot
Configuring the Switch
from the path.
restore
